Echo Curve - ICON Level Pro ProScan Getting Started

ProScan
®
Installing Sensor
ProScan ® measures the distance between the bottom of sensor face and the liquid surface requirements:
Ensure that there are no protrusions or obstructions between the tip of the Sensors Antenna and the Liquid Surface below.
Note: The ProScan ® should have a clear unobstructed path to the liquid level. The ProScan
readings if ladders, pipes, mixers, pumps, floats or irregular shapes walls are present.
Note: Additionally, when the sensor transmits a microwave pulse, the RF signal spreads in a conical shape (determined by its
beam angle) over distance. Refer to the Beam Angle Chart to determine, what if any, additional measurement space is required to
be free of such obstacles. If such items are present, then a False Echo Curve configuration must be done.

Echo Curve

The Echo Curve is a diagnostic tool that is employed
to review situations where the ProScan
filters or modification to the current installation
Contact Technical Support for On-Line Assistance with
the Echo Curve
Quick-Start
® is subject to Incorrect or unreliable
requires
®
Echo Curve
3.4
+02.375
02.384
10.0
ft(d)
X-Axis
12
