Summary of Contents for ICON Level Pro ProScan
- Page 1 ProScan Getting Started Quick Start ProScan Radar Sensor...
-
Page 2: Quick Start
ProScan Quick-Start ® WARNING! Read the user's manual carefully before starting to use the unit or software. Producer reserves the right to implement changes without prior notice. Where personal safety or significant property damage can occur due to a spill, the installation must have a redundant fail-safe backup system installed which accounts for sensor and/or power failure. -
Page 3: Safety Information
ProScan Quick-Start ® Safety Information 1. De-pressurize and Vent System Prior to Installation or Removal. 2. Confirm Chemical Compatibility Before Use. 3. DO NOT Exceed Maximum Temperature or Pressure Specifications. 4. ALWAYS Wear Safety Goggles or Face-Shield During Installation and/or Service. 5. -
Page 4: Programming Display
ProScan Quick-Start ProScan Radar Sensor ® The ProScan is two-wire, pulse radar level transmitter that provides a continuous 4-20mA current output. This output ® is directly proportional to the liquid level in a sump or a tank. ProScan Radar Sensor ®... -
Page 5: Power Supply
ProScan Quick-Start ® Power Supply The sensor power supply and current signal share the same two-wire shielded cable. The sensor supply voltage should never exceed 24 VDC. Always provide complete electrical and physical separation between the sensor supply circuit and the main circuit. Note: Remember that the output voltage of the power supply can be lower under nominal load (with a sensor current of 20.5 mA or 22 mA) and/or with the addition of other instruments placed within the circuit. -
Page 6: Tank Installation
ProScan Quick-Start ® Tank Installation Below are some considerations with respect to how the sensor can be installed on top of a tank. ProScan ® has a dead band that extends out from the measurement transducer of the sensor. As a result, the height of the sensor above or below the top of the tank will affect the dead band and 20mA settings. -
Page 7: Menu Introduction
ProScan Quick-Start ® Menu Introduction Min Configuration Basic Settings Max Configuration Display Medium | Default is Liquid Diagnostics False Echo Memory Damping | Default is 5s Service Current Output = 4-20 Range Info Dead-Band* | Default is 12" Reset Units of Measurement Sensory Tag Power On Sensor * Dead-Band = Near Blanking... -
Page 8: Units Of Measurement
ProScan Quick-Start ® Programming Units of Measurement Factory Default is Ft This function sets the units for all measurement values to be entered into the sensor. The choices for units are feet and meters. The unit is shipped with a Factory Default Setting of feet. Basic Settings False Echo Memory Display... - Page 9 ProScan Quick-Start ® Program Low or Empty Min Adjustment = 4mA Set-Point Basic Settings Display Measurement Point Enter this Measurement for Diagnostic Your Min Service Empty Information Min Fill Height = Distance from Tip of Sensor to Bottom of Tank 28.00 1.
- Page 10 ProScan Quick-Start ® Program Max Fill Height 20mA Basic Settings Min Adjustment Enter this Measurement for Your Max Display Max Adjustment 20mA 100% Measurement Diagnostic Location Max Fill Height is the Distance from the Tip of the Sensor to the Highest Liquid Level Max Adjustment is the 20mA Set-Point Service Info...
-
Page 11: Max Range
ProScan Quick-Start ® Program Max Range This function sets the Maximum Operational Range for the sensor. This setting defines the maximum distance that the sensor will detect valid echo returns. Basic Settings Min Adjustment Display Max Adjustment Point of Measurement Overall Fill Range Empty to Full Diagnostic... - Page 12 ProScan Quick-Start ® Programming Dead Band This setting defines the minimum distance that the sensor will detect valid echo returns. Note : If the Dead Band* setting is placed below the "Max Full Setting" setting, then the sensor will not measure above the Dead Band. Extended Fitting Dead Band Measurement...
- Page 13 ProScan Quick-Start ® Installing Sensor Beam Angle 22° Beam Angle 22° Height Dia. Height Dia. 3.89' 1.94m 7.78' 3.89m 11.66' The sensor must be installed with the antenna perpendicular to the surface of the liquid. The sensor must be installed with a distance > 17.8" | 450mm from the side wall of the tank. The liquid level must not be allowed to enter into the Dead Band of the sensor.
-
Page 14: Echo Curve
ProScan Quick-Start ® Installing Sensor ProScan ® measures the distance between the bottom of sensor face and the liquid surface requirements: Ensure that there are no protrusions or obstructions between the tip of the Sensors Antenna and the Liquid Surface below. Note: The ProScan ®... - Page 15 ProScan Quick-Start ® Diagnostics Menu } Sub Menus Basic Settings Peak Values Display Meas. Status Basic Settings Display Diagnostics Service Information Diagnostics Choose Curve Service Echo Curve Info Simulation Service Menu } Sub Menus Basic Settings False Echo Memory Display Current Output Basic Settings Diagnostics...
- Page 16 ProScan Quick-Start ® Basic Settings } Sub Menus 12.34 Levelpro Temp Basic Settings Min Adjustment | 4mA Basic Settings Display Diagnostics Service Display Max Adjustment | 20mA Info Medium | Liquid | Solid | Micro DK* Diagnostics Service Damping | Seconds Info Range | Overall Distance Dead Band...
- Page 17 ProScan Quick-Start ® Service Menu } Sub Menus Previous Page Basic Settings Display Distance ADJ Diagnostic Basic Settings Threshold Display Diagnostics Service Information Service Autogain Info Relay Set Info Menu } Sub Menus Basic Settings Display Diagnostic Service Basic Settings Display Diagnostics Service...
- Page 18 (MRA) request form and follow the instructions therein. All warranty and non-warranty product returns to Icon Process Controls must be shipped prepaid and insured. Icon will not be responsible for any products lost or damaged in shipment.
- Page 19 ProScan Quick-Start ® support@iconprocon.com or visit www.iconprocon.com or contact us at 905.469.9283 © Icon Process Controls Ltd. All Rights Reserved...
- Page 20 MENU ENTER Flow Meter TK3P Na0CL NaOH...
