Intermec CK60 User Manual

Mobile computer with windowsr ce
Hide thumbs Also See for CK60:
Table of Contents

Advertisement

Quick Links

See also: Instructions , User Manual
User's Manual
CK60 Mobile
Computer with
Windowsr CE

Advertisement

Table of Contents
loading

Related Manuals for Intermec CK60

Summary of Contents for Intermec CK60

  • Page 1 User's Manual CK60 Mobile Computer with Windowsr CE...
  • Page 2 The information contained herein is provided solely for the purpose of allowing customers to operate and ser- vice Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec Technologies Corporation.
  • Page 3 Document Change Record This page records changes to this document. The document was originally released as Revision A. Revision Letter CK60 Mobile Computer with Windows CE User’s Manual Date Description of Change 12/2006 Replaced Audio Devices applet information with Bluetooth Audio applet information.
  • Page 4 CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 5: Table Of Contents

    Introducing the CK60 Mobile Computer ........
  • Page 6 Developing Applications for the Computer ........36 Converting Older Computer Applications to CK60 Applications ....36 Packaging Applications for the Computer .
  • Page 7 Configuring the Computer With Intermec Settings ..... . . 48 To access the Intermec Settings applet: ......48 Synchronizing the Computer System Time with a Time Server .
  • Page 8 Troubleshooting Your Computer ......... . . 68 Cleaning the Scanner Window and CK60 Screen ....... 72 Network Support .
  • Page 9 ............... . 103 CK60 Mobile Computer with Windows CE User’s Manual...
  • Page 10 Contents CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 11: Before You Begin

    Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at Global Sales & Service page appears. From the Service & Support menu, move your pointer over Support, and then click Warranty.

  • Page 12: Who Should Read This Manual

    This document provides you with information about the features of the CK60, and how to install, configure, operate, maintain, and troubleshoot. Before you work with the CK60, you should be familiar with your network and general networking terms, such as IP address.

  • Page 13: Patent Information

    2 Click Service & Support > Manuals. 3 In the Select a Product field, choose the product whose documentation you want to download. To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. Patent Information 4,882,476;...
  • Page 14 Before You Begin CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 15: Using The Computer

    This chapter introduces the CK60 Mobile Computer, developed by Intermec Technologies Corporation to enhance wireless connectivity needs and contains hardware and software configuration information to assist you in making the most out of your CK60. Note: Desktop and applet icons are shown to the left. Any place that Start is mentioned, tap the following Windows icon in the bottom, left corner of your CK60 desktop.

  • Page 16: Introducing The Ck60 Mobile Computer

    Chapter 1 — Using the Computer Introducing the CK60 Mobile Computer The Intermec CK60 Mobile Computer is an ergonomically designed handheld computer built on the Microsoftr Windowsr CE operating system. It is a lightweight, easy-to-use, reliable computer that runs client/ server applications, terminal emulation applications, as well as browser- based applications.

  • Page 17: Learning Software Build Versions

    PSM region. To check to see if your CK60 has the latest PSM build or the latest operating system build, double-tap the Internet Explorer icon from the desktop, then see the information under CK60 Version Information.

  • Page 18: Clean Boot Process

    The CK60 supports the scanning of 2D images. Plus, if you are using an integrated handle or a tethered scanner, the way you scan bar codes is different.

  • Page 19: Scanning With The 2D Area Imager

    Applet” on page Scanning with the 2D Area Imager The CK60 has the 2D area imager, which provides the ability to scan 2D bar code symbologies and supports omni-directional (360°) scanning where you can position the CK60 in any orientation to scan a bar code label.

  • Page 20: Supported Devices

    Using the Battery The CK60 uses a 17.3 Watt-hour, 7.2V, replaceable Lithium-Ion (Li-ion) battery. Fully charge the battery before using the CK60. When changing the battery, a backup battery (super capacitor) maintains your state, memory, and real-time clock for at least 10 minutes.

  • Page 21: Charging And Installing The Battery

    To charge the battery • Either insert the battery into the quad battery charger, • or place the CK60 with battery installed in a single dock, a single dock with modem, or a multidock. The battery charge time is four hours or less on any of these docks if the temperature is within the battery charging range.

  • Page 22: Checking The Battery Status

    Checking the Battery Status The battery status LED above your CK60 keypad, as shown in the following illustration, indicates the status of your battery. See the following table to understand the meanings of the lights emitted from the LED.

  • Page 23: Adjusting The Beeper

    To enable the beeper 1 Tap Start > Settings > Control Panel, then double-tap the Volume 2 Check for which features the CK60 should enable sounds, then tap To disable the beeper 1 Tap Start > Settings > Control Panel, then double-tap the Volume 2 Clear the options to disable their sounds, then tap OK to close.

  • Page 24: Using The Intermec Settings Applet

    1 Tap Start > Settings > Control Panel. 2 Double-tap the Intermec Settings icon to access the applet. Using the Keypad Your CK60 has one of the following keypad overlay options: a 32-key large numeric keypad or a 58-key full alphanumeric keypad. 32-Key Large Numeric Keypad This keypad is for applications that enter mainly numeric data (0-9).

  • Page 25: 58-Key Full Alphanumeric Keypad

    You press and release the first key, then press and release the second key to access the color-coded character or function printed above a key. Note that there are several hidden characters (such as < or >) on each CK60 keypad that require using the color-coded keys to access them.

  • Page 26: Turning On The Keypad Backlight

    The Start screen has two distinct areas: the desktop and the taskbar. The desktop displays shortcuts to some of the applications installed on the CK60. The taskbar displays the Start menu, the time, the onscreen keyboard icon, and the desktop icon.

  • Page 27: Using Software Tools

    Your CK60 has a stylus for selecting items and entering information. Use the stylus in place of a mouse. Things You Can Do with a Stylus Action Double-tap Drag Tap and hold Using Software Tools The following Intermec software tools are available as free downloads: SmartSystems Foundation Console (www.intermec.com/SmartSystems)

  • Page 28: Using The Speakers

    Chapter 1 — Using the Computer Using the Speakers The high-volume speaker on the back of the CK60 is capable of variable volume levels. This speaker is capable of reproducing voice and WAV files, and is used primarily to convey status tones. There is a separate volume control in the Intermec Settings and Volume &...
  • Page 29 To disable the speaker, tap the Soft button to drag the slider all the way to the left. To adjust the volume using the Intermec Settings applet 1 Tap Start > Settings > Control Panel. 2 Double-tap the Intermec Settings icon.

  • Page 30: Using The Status Indicators

    CK60. Use a SanDisk Secure Digital card to increase file storage and install software. Its card slot is on the top of the CK60 just above the scanner window. Do the following to insert a card in the CK60: You can corrupt your Secure Digital card if you do not follow these installation and removal procedures exactly.

  • Page 31: Physical And Environmental Specifications

    Physical and Environmental Specifications Use this section to locate technical information about the CK60 and its available features and options. Physical Dimensions Length: Width: Height: Weight: Hardware Microprocessor: Memory: Flash ROM: Persistent Storage: Removable Storage: Keypad: Operating System Microsoft Windows CE 5.0 Software Development Environments:Embedded Visual C++ 4.0,...
  • Page 32 11 to 28 VDC @ 1.5 A max. (18 W max.) -20° to 50°C (-4° to 122°F) -30° to 70°C (-22° to 158°F) 5% to 95% noncondensing +8kV Contact Discharge; +15kV Discharge Multiple 6 ft (1.8 m) drops to steel or concrete CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 33: Accessories For The Computer

    CK60 with or without a handle. You can only use this with a CK60 that has either the 1D linear imager or the 2D imager.
  • Page 34 Chapter 1 — Using the Computer CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 35: Windows Ce

    This chapter introduces Microsoftr Windowsr CE 5.0. While using your CK60 Mobile Computer, keep this key point in mind: • Tap Start on the task bar, located at the bottom, left corner of the screen, to quickly move to programs, files, and settings. Use the task bar at the bottom of the screen to perform tasks in programs.

  • Page 36: Software Builds

    Where to Find Information This chapter describes your CK60 hardware, provides an overview of the programs on your CK60, and explains how to connect your CK60 to a desktop, a network, or the Internet. For instructions on setting up your CK60 and installing ActiveSync, see the Quick Start Guide.

  • Page 37: Desktop Screen

    Desktop Screen When you turn on your CK60 for the first time each day, you see the Desktop screen. To customize what is displayed on the Desktop screen, including the background image, tap Start > Settings > Control Panel, then double-tap the Display icon.

  • Page 38: Notifications

    Options, then select Large keys. Tap OK, then OK again to close. Below are the “soft” keyboards. Using the input panel, enter typed text into the CK60. Do this by tapping keys on the onscreen keyboard or by using handwriting recognition software.

  • Page 39: Typing With The Onscreen Keyboard

    You can cut, copy, and paste text by tapping and holding the selected words and then tapping an editing command on the pop-up menu, or by tapping the command on the Edit menu. CK60 Mobile Computer with Windows CE User’s Manual Chapter 2 — Windows CE Input Panel icon...

  • Page 40: Finding And Organizing Information

    Chapter 2 — Windows CE Finding and Organizing Information Use the Windows Explorer to find and organize files on your CK60. Tap Start > Programs > Windows Explorer. Customizing Your Computer You can customize your CK60 by adjusting settings and installing additional software.

  • Page 41: Adding Or Removing Programs

    Only Memory). You cannot remove this software, and you cannot accidentally lose ROM contents. You can install any program created for your CK60, as long as your CK60 has enough memory. The most popular place to find software for your CK60 is on the Windows CE .NET web site...
  • Page 42 Adding a Program Directly from the Internet Install the appropriate software for your CK60 on your PC before installing it on your CK60. Once installation is complete, tap Start > Programs, then the program icon to switch to it. 1 Determine your CK60 and processor type so that you know which version of the software to install.

  • Page 43: Microsoft Activesync

    After installation is complete, the ActiveSync Setup Wizard helps you connect your CK60 to your PC or set up a partnership so you can browse for or move data between your CK60 and your PC. Note: While ActiveSync does synchronize files between your PC and your CK60, the Windows CE operating system does not include Calendar, Contacts, Tasks, Inbox, Channels, and Pocket Access applications.

  • Page 44: Typing Mode

    Word (.DOC) or Rich Text Format (.RTF). Windows Explorer contains a list of files stored on your CK60. Double-tap a file to open it. To delete, make copies of, and rename files, tap and hold a file in the list, then, select the action on the pop-up menu.

  • Page 45: Writing Mode

    For information on synchronization or file conversion, see ActiveSync Help on the desktop. Note: When you delete a file on either your desktop or your CK60, the file is deleted in the other location when you synchronize. CK60 Mobile Computer with Windows CE User’s Manual Chapter 2 —...

  • Page 46: Internet Explorer

    Use Microsoft Internet Explorer to view web sites. To do this, create the connection first via an ISP or network page To switch to Internet Explorer on your CK60, double-tap the Internet Explorer icon on your desktop. Viewing Mobile Favorites and Channels Tap Favorites from the tool menu to display your list of favorites, then tap the page you want to view.

  • Page 47: Media Player

    • Tap the drop-down arrow to select from previously entered addresses. Note: To add a favorite link while using the CK60, go to the page you want to add, then select Favorites > Add to Favorites. Media Player To switch to this application, tap Start > Programs > Media Player, or double-tap the Media Player icon on the desktop.
  • Page 48 Chapter 2 — Windows CE CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 49: Configuring The Computer

    Use this chapter to understand how to install applications onto your CK60 Mobile Computer and how to configure the CK60 to communicate in your network. Note: Desktop and applet icons are shown to the left. Any place that Start is mentioned, tap the following Windows icon in the bottom, left corner of your CK60 desktop.

  • Page 50: Developing Applications For The Computer

    • Microsoft Mouse or compatible pointing device Converting Older Computer Applications to CK60 Applications If you have an existing application that you would like to run on the CK60, you can use the Migration Resource Kit to convert that application. The kit has a set of libraries and tools to convert your existing “C”...

  • Page 51: Packaging Applications For The Computer

    Consider any of the following when choosing a location into which to store your application: • In the basic CK60, there are two built-in storage options: the Object Store and the Flash File Store. The Object Store is a Disk on Chip (DOC) Flash that looks like a disk.

  • Page 52: Installing Applications On The Computer

    PC and is up and running. If not, go to for an URL from which to download the latest application. 1 Connect the CK60 to a PC using a USB or serial cable. You may have to detach, then reattach the cable to “wake” the connection.

  • Page 53: Using A Secure Digital Card

    Using a Secure Digital Card If you have a Secure Digital card for your CK60, this is the best place for you to install applications. 1 If you are using a Secure Digital card reader, suspend the CK60, remove its Secure Digital card, and place it in the reader.

  • Page 54: Using The Smartsystems Console

    [HKLM\System\StorageManager\Profiles\TRUEFFS_DOC] “Folder”=“DiskOnChip” Note: On standard CK60 builds, this is mapped to Object Store and does not appear as an actual device to which you can navigate. If any are mapped as Object Store, they are not addressable via the defined folders.

  • Page 55: Preshell

    AutoExec is reserved for Intermec use to configure Intermec-specific applications. It launches the CAB installer, AutoCab.exe, to install platform .cab files to the system, such as Intermec Data Collection. CK60 Mobile Computer with Windows CE User’s Manual Chapter 3 — Configuring the Computer...

  • Page 56: Autoexec

    AutoExec data file (AuotExec.dat). This script file must be in the same folder as the program. Note: Intermec considers the usage of the AutoExec data file as “Intermec Private.” AutoExec installs Intermec applications such as Data Collection, Security Supplicants, Intermec Management, applets, and shortcuts from components found in the Flash File System.

  • Page 57: Autorun

    AutoRun.dat. Note: If you need to add steps at boot time, add them to AutoUser.dat, not to AutoRun.dat. AutoRun.dat is provided by Intermec and is subject to change. AutoUser.dat is the designated place for the end user to add steps to the boot time process.

  • Page 58: Autocopy

    Processes a specified file of commands and does not return. Loads a specified program and executes it. Loads a specified program and executes it. “Flash File Store\Apps\some.exe” arg1, arg2, arg3 “Flash File Store\SYSTEM\usercmds.dat” CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 59: Autocab

    AutoCab preserves the .cab file after installation if the ReadOnly attribute is set. If not set, the .cab file is deleted automatically after installation. Usage: AutoCab [-ChkRst=][-File=][-Force][-Log=][-Move=][-Quiet=][-Show=][-Signal=] CK60 Mobile Computer with Windows CE User’s Manual Chapter 3 — Configuring the Computer...

  • Page 60: Customizing How Applications Load On The Computer

    Set to 0 to prevent showing any installation progress interfaces. Also prevents user from canceling installation. Set to 1 to show normal installation. Set to 2 to show Intermec installation progress interface (user can see what is installing but cannot cancel it). Default is 1 (show normal).

  • Page 61: Configuring Ck60 Parameters

    CK60 operates. Configuring with the Setup Assistant When first setting up the CK60, use the Setup Assistant to set or enable basic network parameters and connect your CK60 to the network. The...

  • Page 62: Configuring The Computer With Intermec Settings

    The default reference time server is the USNO (tock.usno.navy.mil). To synchronize the CK60 time with this time server, have a valid connection to the Internet. You can also synchronize the CK60 system time with a corporate network server within your firewall that is SNTP-capable.

  • Page 63: Configuring The Computer In A Tcp/Ip Direct Connect Network

    • Cs - Configuration Set response sent from the CK60 to the host computer. commands Reader and configuration commands to set on the CK60 or current values to retrieve from the CK60. To save configuration changes in flash memory, send .+1 reader command as last command. For list of all commands, see Intermec Computer Command Reference Manual.

  • Page 64: Configuring The Computer In A Udp Plus Network

    • Cs - Configuration Set response sent from the CK60 to the host computer. commands Reader and configuration commands to set on the CK60 or current values to retrieve from the CK60. To save configuration changes in flash memory, send .+1 reader command as last command. See Intermec Computer Command Reference Manual for list of supported commands.

  • Page 65: Implementation

    These are the registry entries (which are arrays of 128 WORDs) you need to modify to remap your keypad. Programming the Keypad Do the following to change a single key on the CK60 keypad. You can change more than one key, if desired. 1 Identify your keypad Read the four bytes of text stored in the registry entry.

  • Page 66: Alphanumeric Scan Codes

    5 Signal the keypad to reload Open the “ITC_KEYBOARD_CHANGE” named event and call SetEvent() to signal the keypad to reload. Alphanumeric Scan Codes Orange key Numeric Scan Codes Orange key Green key Green key CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 67: Configuring The Sf51 Cordless Scanner

    Configuring the SF51 Cordless Scanner The following information pertains to configuring the SF51 Cordless Scanner to work with your CK60. These instructions assume you have EasySet version 5.4 or later installed on your desktop or laptop. EasySet is available at no charge from the Intermec web site at www.intermec.com.

  • Page 68: Creating An Sf51 Connection Label

    CK60 to be undiscoverable as it does not offer any incoming services out of the box. Connectable Check this to allow other Bluetooth devices to connect to your CK60. The default is for the CK60 to be unconnectable as it does not offer any incoming services out of the box.

  • Page 69: Viewing Sf51 Scanner Information From Your Computer

    6 When connected, the blue Intermec Ready-to-Work indicator assumes a steady blue. Viewing SF51 Scanner Information from Your Computer Note in the CK60, the Intermec Settings applet can display up to seven separate SF51 connections. The following illustration shows such connections under the Data Collection option.

  • Page 70: Configuring Bluetooth Communications For Wireless Scanners

    Bluetooth radio. The Bluetooth technology uses short-range radio links and allows for communications over a 10 m (32.8 ft) range. Enabling Bluetooth On the CK60, use the Intermec Settings applet to enable Bluetooth communications before you configure the wireless scanner. See Bluetooth” on page 53 To allow incoming connections from wireless scanners 1 In the Intermec Settings applet, tap (+) to expand Communications >...

  • Page 71: Connecting To The Wireless Scanners

    Quick Connect bar code scan, or choose from previously used devices. To connect to a wireless scanner 1 From the CK60, select Start > Programs > Windows Explorer. 2 Browse to the “\Program Files\Intermec\Network\Bluetooth” folder. 3 Double-tap the BluetoothScannerWizard icon.
  • Page 72 “0000,” then tap OK. The passcode is provided by the manufacturer of your Bluetooth audio device. You can usually find your passcode in the user manual that came with the Bluetooth device. 4 Tap Finish to save your discovery and close the wizard. CK60 Mobile Computer with Windows CE User’s Manual...
  • Page 73 3 When you set your scanner manually, your device does not receive the scanner name. Therefore, “-unknown-” is displayed unless you enter the correct value in to the registry in some other way. CK60 Mobile Computer with Windows CE User’s Manual Chapter 3 — Configuring the Computer...

  • Page 74: Disconnecting A Wireless Scanner

    Chapter 3 — Configuring the Computer Quick Connect (Incoming) This feature allows you to take your scanner and attach it to the CK60 by scanning a bar code provided by the wizard. To do a quick connection 1 Select Quick Connect (Incoming).

  • Page 75: Using Configuration Parameters

    Using Configuration Parameters A configuration parameter changes the way the CK60 operates, such as configuring a parameter to have the CK60 emit a very loud beep in a noisy environment. Use either of these methods to execute configuration parameters:...
  • Page 76 Chapter 3 — Configuring the Computer CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 77: Maintaining The Computer

    Note: Desktop and applet icons are shown to the left. Any place that Start is mentioned, tap the following Windows icon in the bottom, left corner of your CK60 desktop. CK60 Mobile Computer with Windows CE User’s Manual Maintaining the Computer...

  • Page 78: Upgrading The Operating System On Your Computer

    There are two ways to upgrade the CK60: • You can use a Secure Digital card to upgrade the CK60. For help, see “Using a Secure Digital Card to Upgrade the Computer” on page •...

  • Page 79: Using A Secure Digital Card To Upgrade The Computer

    PSM. You will need this information later. 6 Click the link and download the .zip file to your PC. 7 If you are using a Secure Digital card to upgrade the CK60, see below. If you are using the SmartSystems Console to upgrade the CK60, see “Using the SmartSystems Console to Upgrade the Computer”...

  • Page 80: Upgrading The Operating System

    Chapter 4 — Maintaining the Computer When the CK60 finishes rebooting, you may use it. You have reset the CK60 to its default configuration. You need to set the date and time and to set its network communications parameters to reestablish communications with the other devices in the wireless network.

  • Page 81: Using The Smartsystems Console To Upgrade The Computer

    Note: The upgrade will fail if the CK60 is not connected to external power. For help, see the accessories list in puter” on page 3 Insert the Secure Digital card in the CK60. For help, see Secure Digital Card” on page 4 Using a stylus, press the Reset button inside the battery cavity.

  • Page 82: Troubleshooting Your Computer

    Once the upgrade is done downloading, your CK60 replaces the operating system, then automatically performs a cold boot. The SmartSystems Console shows the CK60 as offline (via a red stop sign) until the CK60 reboots and reconnects to the system.
  • Page 83 You may have locked a modifier key on the keypad. Check the CK60 toolbar to see if it contains an icon with a locked symbol. Press the necessary key sequence to unlock the key. “Using the Keypad” on page...

  • Page 84: Problems With Wireless Connectivity

    If you are having problems sending or receiving data through the integrated serial port on the CK60, check these possible problems: • Make sure the CK60 is connected to the PC, host computer, or RS-232 serial device using the appropriate cable adapter and null modem cable.

  • Page 85: Problems While Scanning Bar Codes

    When you release the Scan button or handle trigger, the Good Read light does not turn off. The input device attached to the CK60 does not work well or read bar code labels very quickly. The scanner will not read the bar code label.

  • Page 86: Cleaning The Scanner Window And Ck60 Screen

    Chapter 4 — Maintaining the Computer Cleaning the Scanner Window and CK60 Screen To keep the CK60 in good working order, you may need to clean both the scanner window and the CK60 screen. Clean the scanner window and CK60 screen as often as needed for the environment in which you are using the CK60.

  • Page 87: Network Support

    The CK60 Mobile Computer automatically installs the appropriate software for radio use when the computer is turned on. It provides wireless connectivity via the Wireless Local Area Network (WLAN) using a radio option that provides up to 54 Mbps. Note: Desktop and applet icons are shown to the left. Any place that Start is mentioned, tap the following Windows icon in the bottom, left corner of your CK60 desktop.

  • Page 88: Personal Area Networks

    Bluetooth management items not relevant to this task. Wireless Printing has a concept of the “current wireless printer.” This printer is the one to which the CK60 makes a connection when the wireless printing COM port is opened. If there is no current wireless printer, there is no wireless printing COM port.

  • Page 89: Searching For Bluetooth Devices

    OK. 3 If you do not see your preferred device, make sure this device is powered on and set to discovery, then tap Search again. CK60 Mobile Computer with Windows CE User’s Manual Chapter 5 — Network Support (page...

  • Page 90: Entering The Remote Bluetooth Device Address

    Setting a Different Printer Use this feature to move from the selected printer to another printer that was previously found. CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 91: Connecting To The Network Via Bluetooth Dun

    Nokia 3650 for example purposes. Before you connect to the network, make sure Bluetooth is enabled on your CK60 so you can find and connect to remote devices. Bluetooth is required for the SF51 Cordless Scanner. See enable Bluetooth.
  • Page 92 Once connected, you should be able to browse Internet websites and use other online resources from your CK60. To establish a Bluetooth connection between your CK60 and your mobile phone 1 Tap Start > Settings > Network and Dial-up Connections, then double-tap Make New Connection.
  • Page 93 “0060573ee7ba channel 1 is running on BSP1:” 8 Tap Exit to complete the search and bonding of your device, tap Next, enter the phone number for your connection, then tap Finish. CK60 Mobile Computer with Windows CE User’s Manual Chapter 5 — Network Support...

  • Page 94: Connecting To Bluetooth Audio Devices

    Bluetooth audio device (if the connected device has these capabilities). To access the Bluetooth Audio applet 1 From the CK60 desktop, select Start > Settings > Control Panel. 2 Double-tap the Bluetooth Audio icon. Searching for Bluetooth Headsets To find a Bluetooth headset with either a “headset”...
  • Page 95 Bluetooth Audio Device Status Icons Icon Description CK60 Mobile Computer with Windows CE User’s Manual Your CK60 and your Bluetooth audio device are not connected. Note the red diag- onal bar. Your CK60 and your Bluetooth audio device are connected.

  • Page 96: Connecting To A Bluetooth Headset

    Delete to remove a device from the list. 3 If the activated device has a “hands-free” profile, press a button on the device to establish an audio connection between the CK60 and the activated device. See the user manual for the Bluetooth device for information on what button to press.

  • Page 97: Local Area Networks

    Ethernet, or Bluetootht radio. Configuring Serial Communications The CK60 has a serial port to transfer data to and receive data from another device via RS-232 communications. You can also insert the CK60 into a communications dock to transmit data to and receive data from a host computer or PC using RS-232 communications.

  • Page 98: Configuring The Network Parameters For A Udp Plus Network

    3 Tap ok. 4 Perform a warm-boot for the new setting to take effect. Your CK60 may be capable of using both bands or just the B/G band. The BandEnable applet can enable or mask usage of any band the CK60 is capable of using.

  • Page 99: Configuring Ethernet Communications

    Configuring Ethernet Communications You can use the CK60 directly in an Ethernet network if you have ordered the Ethernet option on your CK60 and you insert it into a dock. The communications dock as an Ethernet connector makes it possible for the CK60 to communicate with your Ethernet network.

  • Page 100: Wide Area Networks

    Internet Explorer. The communication software for creating an ISP connection is already installed on your CK60. Your service provider may provide the software needed to install other services, such as paging and fax services.
  • Page 101 4 Enter the phone number, then tap Finish. 5 Double-tap the new My Connection icon, then enter the user name, password, and domain (if provided by an ISP or your network administrator). CK60 Mobile Computer with Windows CE User’s Manual Chapter 5 — Network Support...

  • Page 102: Direct Connection

    To view additional information for any screen in the wizard or while changing settings, tap Help in the upper-right corner. 1 Tap Start > Settings > Network and Dial-up Connections, then double- tap Make New Connection. “Internet Explorer” on page 32 CK60 Mobile Computer with Windows CE User’s Manual for information.

  • Page 103: Iconnect

    CK60, the iConnect application restores your network interfaces to what they were before the warm-boot was performed. See the Developer’s Support area of the Intermec web site for the latest information on network adapters for your unit. CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 104: Ethernet Communications

    DHCP is selected as the default. When you select Enable > Ethernet from the iConnect menu, the Ethernet icon (shown to the left) appears in the toolbar as circled in the illustration. iConnect icon CK60 Mobile Computer with Windows CE User’s Manual...

  • Page 105: No Networking

    Wireless Communications When you select Enable > Wireless from the iConnect menu, the Wireless icon (shown to the left) appears in the toolbar. CK60 Mobile Computer with Windows CE User’s Manual Chapter 5 — Network Support...

  • Page 106: Pinging Your Gateway Or Dhcp Server

    • Select Status > Wireless from the iConnect menu to view the status. Tap Try Again to check the status after you make changes to the connection. Pinging Your Gateway or DHCP Server Use the Ping Test feature to test your CK60 connection against your network. To ping your gateway or DHCP Server 1 Select Tools >...

  • Page 107: Configuring Security

    Loading Certificates If you choose to use Transport Layer Security (TLS) with WPA or 802.1x security, you need to have a unique client certificate on the CK60 and a trusted root certificate authority (CA) certificate. If you choose to use PEAP, you need to load a root CA certificate.
  • Page 108 WEP keys also authenticate the CK60 to the access Privacy) point - unless the CK60 can prove it knows the WEP key, it is not allowed onto the network. WEP encryption keys are only needed if they are expected by your clients. There are two types available: 64-bit (5- character strings, 12345) (default) and 128-bit (13-character strings, 1234567890123).

  • Page 109: Choosing Between Microsoft And Funk Security

    WPA and WPA2 would be the Pre-Shared Key (PSK). Choosing Between Microsoft and Funk Security Before you can implement a security solution on the CK60, you need to choose between Microsoft and Funk security: • By default, Funk security is enabled. It provides everything you get with Microsoft security plus the addition of Cisco Compatible Extensions features.
  • Page 110 Chapter 5 — Network Support To configure Funk Security 1 Select Start > Settings > Control Panel, then double-tap the Intermec Settings icon. 2 Tap (+) to expand Communications > 802.11 Radio > Funk Security. 3 Select an active profile, then configure its security settings.
  • Page 111 Select User Password, type a user password, then press Enter. c For Validate Server Certificate, select “Yes,” then press Enter. Note that you must have the date on the CK60 set correctly when you enable Validate Server Certificate. d You must enter a User Name and Subject Name. You can also enter a Server 1 Common name or Server 2 Common name if you want to increase your level of security.
  • Page 112 Chapter 5 — Network Support Configuring WPA-PSK Security With Funk Security Use this procedure to set WPA-PSK security on your CK60 with Funk security. 1 Make sure you have configured the communications and radio parameters on your CK60 and that Funk is your security choice.
  • Page 113 Select User Password, type a user password, then press Enter. c For Validate Server Certificate, select “Yes,” then press Enter. Note that you must have the date on the CK60 set correctly when you enable Validate Server Certificate. d Enter a User Name and Subject Name. You can also enter a Server 1 Common name or Server 2 Common name to increase security.

  • Page 114: Configuring Microsoft Security

    Chapter 5 — Network Support Using Static WEP Security The CK60 uses the Wired Equivalent Privacy (WEP) protocol to add security to your wireless network based on the 802.11b/g standard. To use WEP security, you need an access point with an 802.11b/g radio.
  • Page 115 4 Select “Microsoft Security” from the drop-down list, then press Enter. 5 Tap Yes or press Esc to clear the alert box. 6 Tap File > Save Settings to save your settings. 7 Perform a clean-boot on the CK60. See “Resetting Your Computer” on page 3 for more information.

  • Page 116: Smartsystems™ Foundation

    Chapter 5 — Network Support SmartSystems™ Foundation Use the SmartSystems Foundation (www.intermec.com/SmartSystems) to configure and manage your network. You can also contact your Intermec representative for support. This tool, available as a free download from Intermec, includes a management console that provides a default method to configure and manage Intermec devices “out-of-the-box,”...

  • Page 117: Index

    Index CK60 Mobile Computer with Windows CE User’s Manual...
  • Page 118 Browsing the Internet Internet Explorer, Build information CE, 3, PSM, 3, CAB files packaging applications, Capacitor internal super, Caps Lock, Charging the battery, Cisco Key Integrity Protocol, CKIP (Cisco Key Integrity Protocol), CK60 Mobile Computer with Windows CE User’s Manual...
  • Page 119 Direct connection, Disk On Chip application storage, registry keys, RunAutoRun component, Display cleaning, desktop, CK60 Mobile Computer with Windows CE User’s Manual entering information, using, Display applet desktop, DRAM low battery shutdown, Dynamic Random Access Memory, EAP (Extensible Authentication Protocol),...
  • Page 120 Numeric scan codes, Object Store packaging applications, Omni-directional scanning, Operating system builds, upgrading, Operating the CK60 troubleshooting, Orange key, Orange shift plane, Packaging applications, CAB files, Secure Digital cards, Parameters, configuring, Passcodes, CK60 Mobile Computer with Windows CE User’s Manual...
  • Page 121 Resource Kits Migration, Resource kits Bluetooth, 74, data collection, developing applications, smartsystems, URL, RunAutoRun, CK60 Mobile Computer with Windows CE User’s Manual Scan codes keypad alphanumeric, numeric, Scanner window cleaning, Scanners supported models, Scanning bar codes, troubleshooting, Screen...
  • Page 122 Wireless network security, Wireless Printing applet, WordPad, creating a document, WPA (Wi-Fi Protected Access), WPA security Funk, WPA2 (Wi-Fi Protected Access), Writing mode Pocket Word, Writing on the screen Pocket Word, CK60 Mobile Computer with Windows CE User’s Manual...
