Intermec CK60 Quick Start Manual

Physical Dimensions
Length: 8.75 in (222 mm)
Width: 3.55 in (90 mm)
Height at Top/Keypad: 2.08 in / 1.4 in (53/36 mm)
Weight: 24.8 oz. (704 g)
Power Specifications
Operating: Rechargeable 17.3 watt hours lithium–ion battery.
Charging time: Less than 4 hours; External charge voltage: 11 to 28 VDC @ 1.5 A max.
Backup: Super Cap supplies 10 minutes bridge time while replacing main battery
Environmental Specifications
Rain and Dust Resistance: IP64 compliant
Drop Survival: Multiple 6 ft. (1.8 m) drops to steel or concrete
Temperature and Humidity Specifications
Operating temperature: -20°C to 50°C (-4°F to 122°F)
Operating humidity 10 to 90% non-condensing
Storage temperature: -20°C to 70°C (-4°F to 158°F)
Humidity: 0 to 95% humidity, non–condensing
Specifications
Additional information to use the computer in your data collection system is available
from the following sources:
Document Available:
CK60 Handheld Computer with Windows Mobile CE (p/n 961-
054-037) or Windows Mobile 5.0 User's Manual (p/n 935-000-
001)
Intermec Developer's Toolkit (includes SDK)
Knowledge Central (http://intermec.custhelp.com)
Go to the Intermec web site at www.intermec.com to find the manuals in PDF format. If you
experience any problems, please visit our product support web site at
intermec.custhelp.com to search for product specific information. To order accessories and
printed documentation, contact your local Intermec sales representative.
Patent: This product is protected by one or more patents. Refer to the CK60 Handheld
Computer Windows CE or Windows Mobile 5.0 User's Manual for the list of patents.
CK60 Handheld Computer Quick Start Guide
*962-054-115C*
P/N 962-054-115C
For More Information
on Web in Print on CD
X X
X
X
Corporate Headquarters
6001 36th Avenue West
Everett, Washington 98203 U.S.A.
tel 425.348.2600
www.intermec.com
© 2005 Intermec Technologies
Corporation. All rights reserved.
Quick Start Guide
CK60 Handheld Computer
