PROAIM P-OHCR-01 Assembly Manual

Clip-on overhead rig for dslr video camera setups

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

Clip-on Overhead Rig for DSLR Video

Camera Setups

A s s e m b l y M a n u a l

1 x Camera Mounting Plate

statutes or in writing by the Publisher.

(P-OHCR-01)

Rails

2 x Track Clamps

Table of Contents

Need help?

Do you have a question about the P-OHCR-01 and is the answer not in the manual?

Page 1 Clip-on Overhead Rig for DSLR Video Camera Setups (P-OHCR-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 Camera Setup • Loosen the track clamp's knob and mount it by inserting it into the baby pin. • Insert the track clamp into the baby pin and tighten it properly with the help of a knob. • Straighten the rails by opening them manually.
Page 3 • Insert the rail on to the top part of the track clamp. • Secure by tightening both the knobs together. • Loosen the 4 knobs of the camera mounting plate. • Loosen the mounting plate. • Then properly insert the rail in the camera mounting plate, As shown in the image.
Page 4 • After fixing the rail properly into the clamp, secure them by tightening both the knobs together. • As shown in the image, the Rails are now properly attached with the Track Clamp. • Attach the camera on the camera mounting plate with the help of camera bolt and secure it properly.
Page 5 YOUR PROAIM CLIP-ON OVERHEAD RIG FOR DSLR VIDEO CAMERA SETUPS ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
