- Page 1 ASSEMBLY INSTRUCTIONS Description : LIBRARY END TABLE ROUND Item No. : OT-47ER ITEM NO.: OT-47ER Printed in Vietnam ISSUED MAR 09, 2021 - 1 -...
- Page 2 Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: OT-47ER Printed in Vietnam ISSUED MAR 09, 2021 - 2 -...
- Page 3 (M6 x 40mm) Lock Washer Flat Washer (6.5 x11mm) (6.5 x13mm) Flat Washer Long Screw (6.5 x19mm) (M4 x 35mm) Allen Key (M4 x 30mm x 110mm) ITEM NO.: OT-47ER Printed in Vietnam ISSUED MAR 09, 2021 - 3 -...
- Page 4 Insert shelves (B) into vertical panels (C) and attach with screws (6) as shown below. Tighten with a screwdriver. STEP 2 Attach vertical panels (C) and shelves (B) to vertical panel (D) with screws (6) as shown below. Tighten with a screwdriver. ITEM NO.: OT-47ER Printed in Vietnam ISSUED MAR 09, 2021 - 4 -...
- Page 5 Attach bottom shelf (E) to vertical panels (C) and (D) with bolts (2), and washers (3) and (5) as shown below. Tighten with Allen key (7). Adjust the levelers to the appropriate height to level the unit. STEP 3 ITEM NO.: OT-47ER Printed in Vietnam ISSUED MAR 09, 2021 - 5 -...
