6540 Stationary Terminal

GETTING STARTED

GUIDE
PN: 961–047–127
Revision B
June 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6540 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intermec 6540

Summary of Contents for Intermec 6540

  • Page 1: Getting Started

    6540 Stationary Terminal GETTING STARTED GUIDE PN: 961–047–127 Revision B June 1999...
  • Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.

  • Page 3: Table Of Contents

    Table of Contents Section 1 Introduction to the 6540 Terminal ... 1-1 Section 2 Set Up ... 2-1 Unpacking ... 2-1 Powering on for the First Time ... 2-1 Section 3 Mounting and Adjusting... 3-1 Desktop Configuration without Mounting Bracket ... 3-1 Supplied Hardware ...
  • Page 4 Introduction Mini ROM DOS ... 5-4 Full ROM DOS ... 5-4 Section 6 Display and Keyboard... 6-1 Principle of Operation ... 6-1 Configuring the Display ... 6-1 Writing to the Display... 6-2 Simulating a Large Block Cursor ... 6-2 Writing Applications for the Display ... 6-2 Keyboard...
  • Page 5 I cannot get files to the 6540 Terminal...10-2 I cannot connect to the network ...10-3 Appendix A Network Drivers ...A-1 Appendix B Utility Disk...B-1 Appendix C Rear Panel Connector Pin Assignments ...C-1 Power Supply ...C-1 Laser Scanner Port...C-2 Bar Code Wand Port ...C-2 External Keyboard Port...C-2...
  • Page 6 Introduction...

  • Page 7: Introduction To The 6540 Terminal

    Introduction to the 6540 Terminal The 6540 Terminal is a rugged PC-based data collection terminal. In most respects it is like a DOS PC. Application developers can easily write custom applications for this terminal. Its Ethernet interface makes it easy for network administrators to manage.
  • Page 8 Section 1 Introduction to the 6540 Terminal Memory) drive. The SRAM drive is faster than the other models, but contents of its memory are lost if power fails. The DHB Model has a standard disk drive. In addition, its enclosure is specialized for the requirements of industrial environments. It is designed for permanent mounting to a desktop or wall.

  • Page 9: Set Up

    Unpacking Several different models are available, and each can be ordered with a range of options and accessories. When unpacking, check the packing list against your order, and ensure that all of the listed options and accessories are present. Accessories are all visible, and their presence is easy to verify. The connectors for optional add-on cards should be visible through the rear panel.
  • Page 10 Section 2 Set Up...

  • Page 11: Mounting And Adjusting

    Section 3 Mounting and Adjusting The terminal rests on desktop or is permanently mounted to a desktop or wall using its adjustable mounting bracket accessory. Its protective cable cover accessory attaches to the top panel of the unit, to provide environmental protection. Desktop Configuration without Mounting Bracket In the desktop configuration without the adjustable mounting bracket, the supplied feet should be attached as shown in Figure 3-1.
  • Page 12 Section 3 Mounting and Adjusting The following illustrations show how you can permanently attach the terminal to a desk or wall with the optional mounting bracket. Figure 3-2 Desktop Configuration with Adjustable Mounting Bracket Use the adjustable mounting bracket (part number 2-486015-20) for either surface. Once the bracket is installed, you can tilt the terminal from 0 to 15 degrees, by loosening the thumbscrews, tilting the unit, then retightening the screws.
  • Page 13 Section 3 Mounting and Adjusting Figure 3-3 Wall Mount Orientation Below Shoulder Level...
  • Page 14 Section 3 Mounting and Adjusting Figure 3-4 Wall Mount Orientation Above Shoulder Level...
  • Page 15 Section 3 Mounting and Adjusting 4”...

  • Page 16: Supplied Hardware

    Section 3 Mounting and Adjusting Supplied Hardware Item Mounting Bracket 12” x 6” x 2.5” (30 x 15 x 6 cm) J-Shaped Bracket 0.75” x 0.50” x 2.0” (2 x 1 x 5 cm) Pan Head Screw #10 - 32 x 0.375” Phillips Flat Washer #10 Vibration Damping Grommet Thumb Screw #10 - 32 x .0375”...

  • Page 17: Protective Cable Cover Assembly

    Badge Reader Attachment to Mounting Bracket The badge reader bracket can be installed on either side of the mounting bracket as shown. The badge reader includes two supplied screws (#4.40 x 0.250” L). Insert them as shown through the bracket and into the threaded inserts in the adjustable mounting bracket. Attach the badge reader to the badge reader bracket using screws supplied with that product.

  • Page 18: Supplied Hardware

    Section 3 Mounting and Adjusting LocalName is the name of the file, including path as it will be found on the hand held computer. Protective Cable Cover Assembly Supplied Hardware Item Protective Cover Platform #6-32 Phillips Head Screw (see Figure 3-9) Cable cover Platform Screw holes for securing front to back...
  • Page 19 Section 3 Cable exit edge Screw hole for clamping screw Clamping screw Figure 3-9 Final Assembly for Protective Cable Cover Mounting and Adjusting...
  • Page 20 Section 3 Mounting and Adjusting 3-10...

  • Page 21: Connecting To The Network

    Connecting to the Network The terminal includes drivers that let you connect it to all popular networks. In Models DFB and DSB, they are located on the FLASH (B:) drive of the terminal. In Model DHB they are located on the hard disk drive (C:). The network drivers are loaded on the terminal based on your order. All of the network configurations require adding, deleting, or modifying files on the B: or C: drives.
  • Page 22 Section 4 Connecting to the Network The terminal is configured so the following network drivers execute upon boot: USER.BAT and STARTNET.BAT. The contents of the USER.BAT and STARTNET.BAT files follow. USER.BAT (DFB AND DSB) SET PATH=B:\net;%PATH% cd net startnet.bat USER.BAT (DHB) SET PATH=C:\net;%path% cd net startnet.bat...

  • Page 23: Tcpip Network

    NET.CFG LINK SUPPORT [Do not modify] BUFFERS 8 1500 [Modify if needed] MEMPOOL 4096 [Modify if needed] MAX BOARDS 4 [Modify if needed] MAX STACKS 4 [Modify if needed] Link Driver EODIISA [Do not modify] port 300 [Do not modify] frame ethernet_II [Modify to Match your system] frame ethernet_802.2 [Modify to Match your system] protocol ipx e0 ethernet_802.2 [Modify to Match your system]...
  • Page 24 Section 4 Connecting to the Network The terminal is configured so that the following network drivers execute upon boot: USER.BAT and STARTNET.BAT. The contents of the USER.BAT and STARTNET.BAT are shown. USER.BAT (DFB AND DSB) SET PATH=B:\PCTCP;%PATH% b:\pctcp\epktisa.com 0x60 0x300 SET PCTCP=b:\pctcp\pctcp.ini b:\pctcp\ethdrv USER.BAT (DHB)

  • Page 25: Wireless Proxim Connection For The Terminal

    [pctcp general] user = [Place user name of person using this unit, else remove line] host-name = [Place name of machine on this line] domain = [List the name of the domain the unit is in, else remove the line] name-resolution = nis [pctcp kernel] interface = ifcust 0 [Do not change]...
  • Page 26 Section 4 Connecting to the Network NETX.EXE – Novell Netware communicator STARTNET.BAT – The batch file that loads the network drivers NET.CFG – Novell Network configuration file The terminal loads and executes the following network driver files upon boot up: USER.BAT and STARTNET.BAT.
  • Page 27 USERCONF.SYS (DSB) shell=b:\command.com /p USERCONF.SYS (DHB AND DFB) (not required) You must modify certain files to configure them for use with your network. To do this, edit the NET.CFG file. An example of this file follows. NET.CFG LINK SUPPORT [Do not modify] BUFFERS 8 1500 [Modify if needed] MEMPOOL 4096 [Modify if needed] MAX BOARDS 4 [Modify if needed]...

  • Page 28: Tcpip Network

    Section 4 Connecting to the Network Where open is away from the number, and closed is toward the number. TCPIP Network The network driver files installed on the terminal can be found at the following directories: Model The network files follow along with a brief description of their function. RL2ISA.DOS –...

  • Page 29: Network Configuration

    Section 4 Connecting to the Network device=c:\pctcp\dis_pkt.gup USER.BAT (DSB) set path=b:\pctcp;c:\;b:\;a:\ b:\pctcp\protman.exe b:\pctcp\netbind.com SET PCTCP=b:\pctcp\pctcp.ini b:\pctcp\ethdrv USER.BAT (DHB) set path=c:\pctcp;c:\;b:\;a:\ c:\pctcp\protman.exe c:\pctcp\netbind.com SET PCTCP=c:\pctcp\pctcp.ini c:\pctcp\ethdrv Network Configuration You must modify certain files to configure them for use with your network. You must edit the PROTOCOL.INI and PCTCP.INI files.
  • Page 30 Section 4 Connecting to the Network PEER_TO_PEER=Y [Modify for your network] [PKTDRV] DriverName=PKTDRV$ [Do not modify] intvec=0x60 [Do not modify] chainvec=0x62 [Do not modify] BINDINGS=RL2ISA [Do not modify] senddelay=0 [Modify if needed] PCTCP.INI [pctcp ifcust 0] ip-address = [Place unit’s IP address here] subnet-mask = [Place unit’s subnet mask here] router = [Place router's IP address here or remove line] router = [Place router's IP address here or remove line]...

  • Page 31: Token Ring Network Connection

    Jumper Settings: 1 – closed 2 – open 3 – open 4 – open 5 – closed 6 – closed 7 – open Where open is away from the number, and closed is toward the number. Token Ring Network Connection This section applies to the terminal with the Token Ring network connection.
  • Page 32 Section 4 Connecting to the Network USER.BAT (DFB AND DSB) SET PATH=B:\net;%PATH% cd net startnet.bat USER.BAT (DHB) SET PATH=C:\net;%path% cd net startnet.bat STARTNET.BAT (DSB AND DFB) b:\net\lsl b:\net\token b:\net\ipxodi b:\net\netx login STARTNET.BAT (DHB) c:\net\lsl c:\net\token c:\net\ipxodi c:\net\netx login. You must modify certain files to configure them for use with your network. For this configuration of the terminal, you must edit the net.cfg file.

  • Page 33: Configuration Of The Token Card

    LINK DRIVER TOKEN [Do not modify] Frame Token-Ring [Do not modify] MAX FRAME SIZE 4296 [Modify if needed] The wireless 900MHz Aeronet card requires some jumper settings and file manipulation. The following shows what the switches must be set at and what files need to be created Configuration of the Token Card You must modify the Token card.

  • Page 34: Tcpip Network

    Section 4 Connecting to the Network lanaidc /fast=isa16 lanaidc /io=a20 /config=legacy /int=9 /rom=d4000 /ram=d0000 TCPIP Network The network driver files that have been installed on the terminal can be found at the following directories: Model The network files are shown below along with a brief description of their function. IBMTOK.DOS –...
  • Page 35 Section 4 Connecting to the Network DEVICE=b:\PCTCP\DIS_PKT.GUP USER.BAT (DSB) SET PATH=b:\PCTCP;%PATH% SET PCTCP=b:\PCTCP\PCTCP.INI b:\pctcp\protman.exe b:\PCTCP\NETBIND.COM b:\PCTCP\TOKDRV.EXE -p 3 CONFIG.SYS (DHB) SHELL=c:\COMMAND.COM /P DEVICE=c:\PCTCP\PROTMAN.DOS /I:c:\PCTCP DEVICE=c:\PCTCP\IBMTOK.DOS DEVICE=c:\PCTCP\DIS_PKT.GUP AUTOEXEC.BAT (DHB) SET PATH=c:\;c:\PCTCP;c:\DOS;c:\config; SET PCTCP=c:\PCTCP\PCTCP.INI c:\pctcp\protman.exe c:\PCTCP\NETBIND.COM c:\PCTCP\TOKDRV.EXE -p 2 You must modify certain files to configure them for use with your network. For this configuration of the terminal, you must edit the PROTOCOL.INI and PCTCP.INI files.
  • Page 36 Section 4 Connecting to the Network chainvec=0x62 BINDINGS=TurboISA class=17 PCTCP.INI [pctcp ifcust 0] [Do not modify] ip-address = [Enter the IP address of the unit] subnet-mask = [Enter the subnet mask of the unit] router = interface-type = PKTDRV [Do not modify] frame-type = Token-Ring [Do not modify] [pctcp general] host-name = [Enter a host name or remove]...

  • Page 37: Storing Programs And Data

    Supply the drive letter where you want to add or modify files on the 6540 Terminal. On the PC you should see the drive of the 6540 Terminal as the drive reported by REMDISK. You can edit and copy files to this drive as you would a normal drive. For example, COPY C:\INTERMEC\6540\*.* D:\RAMDISK\UTILITY...

  • Page 38: Disk Drives

    Section 5 Storing Programs and Data TRANSFER<space>/COM1<space>/R<space>/B19200<space>[6540 destination drive][path]filename<enter> Example: TRANSFER /COM1 /R /B19200 B:\FILENAME.EXT <enter> This command starts the transfer program on the terminal allowing it to receive a file from your PC. You can specify a different name for the file on the terminal.

  • Page 39: Sram Disk-Model Dsb Only (Drive C:)

    SRAM Disk–Model DSB Only (Drive C:) The Model DSB can be configured with a 512KB or 1.5 MB SRAM disk (the C: drive, if present). It operates exactly as a conventional hard disk, with the exception that permanent data storage requires a battery backup.

  • Page 40: Config.sys

    Section 5 Storing Programs and Data 4. USER.BAT CONFIG.SYS The CONFIG.SYS file sets the necessary hardware device drivers for the system and contains the following statements: DEVICE=SSDRVE.SYS /f DEVICE=SSDRVE.SYS /s FILES=20 BUFFERS=5 NEWFILE=B:\USERCONF.SYS USERCONF.SYS You may edit the USERCONF.SYS file on the B: drive, incorporating additional lines of the main CONFIG.SYS file used to override CONFIG.SYS, e.g.
  • Page 41 Section 5 Storing Programs and Data If this solved the problems, make the change permanent by inserting the following line in the USERCONF.SYS file: SHELL=B:\COMMAND.COM /P While still in full ROM DOS, copy the COMMAND.COM file from A to B drive.
  • Page 42 Section 5 Storing Programs and Data...

  • Page 43: Display And Keyboard

    The terminal features a 4-line by 40-character "advanced supertwist" display that provides large, bright characters viewable from a wide angle, without requiring contrast or brightness adjustment. We offer an optional 8-line by 40-character display. The display can be described as a 4x40 or 8x40 window on a standard 25x80 monochrome PC display.

  • Page 44: Writing To The Display

    Section 6 Display and Keyboard Writing to the Display When writing to the display, the first 40 characters of any line are displayed as typed. The 41st to 80th characters cause the screen to "shift" one position to the right–as each additional character is displayed in the 40th position.
  • Page 45 Row/ Column Screen #1 (Home) Screen #3 Screen #5 Screen #7 Screen #9 Screen #11 Screen #13 [Bottom of Screen] <Ctrl>< >: <Ctrl>< >: <Ctrl>< >: <Ctrl>< >: <Ctrl><Tab>: <Ctrl><Delete>: <Esc>: For example, when at: Screen Section 6 Table 6-1 4x40 Display Windows 40 41 Screen #14 (End)
  • Page 46 Section 6 Display and Keyboard Row/ Column Screen #1 (Home) Screen #3 Screen #5 Screen #7 [Bottom of Screen] <Ctrl>< >: <Ctrl>< >: <Ctrl>< >: <Ctrl>< >: <Ctrl><Tab>: <Ctrl><Delete>: <Esc>: For example, when at: Screen Table 6-2 8x40 Display Windows 40 41 Screen #8 (End) [Bottom of Screen]...

  • Page 47: Keyboard

    The characters in this table are supported by the display. Upper 4-bits 0000 Lower 4-bits X X X X 0000 X X X X 0001 X X X X 0010 X X X X 0011 X X X X 0100 X X X X 0101 X X X X 0110 X X X X 0111...

  • Page 48: Using An External Keyboard

    Section 6 Display and Keyboard Figure 6-1 QWERTY Keyboard Layout Using an External Keyboard In addition to the built-in keyboard, you can connect any external keyboard with an AT-style interface. Both the internal and external keyboards are active. When programmers or system administrators want to work directly with the terminal, they may find this method more convenient.
  • Page 49 Section 6 Display and Keyboard computer. Figure 6-2 Reduced-Key Keyboard Layout Figure 6-3 No-Key Keyboard Layout...

  • Page 50: European Layout

    Section 6 Display and Keyboard European Layout Special keypads are available for European countries. An AZERTY version, used in France, is pictured in Figure 6-4. Please contact us for information on special keyboards for other countries. LocalName is the name of the file, including path as it will be found on the hand held computer.

  • Page 51: Inputs And Interfaces

    Connecting Bar Code Scanners and Magnetic Stripe Readers The terminal can accept input from up to three bar code scanners as shown in the following table. 6-PIN MODULAR PORT Wands or Wand SCANNERS Emulation Scanners ScanImage Hand- 0-00X911-00 Held Laser Scanner (Decoded) ScanPlus Hand-Held 0-3X0311-00*...

  • Page 52: Parallel Port

    Section 7 Inputs and Interfaces Parallel Port The standard LPT1 parallel port supports any PC-compatible printer.

  • Page 53: Rom-Dos For Models Dfb And Dsb

    ROM-DOS is included in ROM. The remainder is included in the 6540 utility disk. You can load what you need.(see Section 5). The large majority of programs, however, run with the DOS-subset loaded in the terminal. Appendix A contains a summary of the ROM-DOS commands.
  • Page 54 Section 8 ROM-DOS Models DFB and DSB ECHO Batch command. Turns on or off display of batch execution on the monitor. EXIT Exit "nested" running of ROM-DOS within another program. FCBS Sets the number of File Control Blocks (FCBS) open at one time. FILES Sets the maximum number of files that can be open at one time.
  • Page 55 SHELL Allows selections of an alternate boot program other than the default COMMAND.COM command processor. SHIFT Batch subcommand. Shifts replaceable parameters one position "to the left." STACKS Allows dynamic data stacks to handle interrupts. Note: ROM- DOS does not utilize this command. SUBMENU CONFIG.SYS menu configuration command.

  • Page 56: External Rom-Dos Commands

    Section 8 ROM-DOS Models DFB and DSB External ROM-DOS Commands The following commands are on the utility disk. You can copy them as described in Section 5. COMMAND ATTRIB Display or modify the attributes associated with a file. CHKDSK CHecK DiSK. Checks integrity of data on a disk. Displays information.

  • Page 57: Configuring The Bar Code Decoder

    Configuring the Bar Code You can configure the integrated bar code decoder with MAXICONF2, a menu-driven program on the utility diskette. MAXICONF2 runs on a PC and generates a file with a custom configuration that you load in the terminal. When you run the MAXILOAD program on the terminal, it loads the configuration file into the decoder, via a dedicated, internal COM3 connection.

  • Page 58: Section 9 Configuring The Bar Code Decoder

    Section 9 Configuring the Bar Code Decoder If you use an invalid file name, the program displays: FILE NOT FOUND CONFIGURATION PRESS ANY KEY TO CONTINUE You can maintain an unlimited number of configurations for individual terminals. Modify Parameters Selecting MODIFY_PARAMETERS from the program's command line, displays the Parameters menu.
  • Page 59 1: CONFIGURE MAXILAN 2: RETURN TO DEFAULT 3: QUIT Option 1 prompts for file name: ENTER THE FILE NAME: Do not enter a file extension as the program appends a CFG extension. The program finds the file, programs the bar code decoder, executes a beep sequence and returns to the DOS prompt.
  • Page 60 Section 9 Configuring the Bar Code Decoder...

  • Page 61: Troubleshooting

    Section 10 Troubleshooting The following questions or problems and the suggested actions help you resolve some common problems. Unit does not boot Is the power light lit? Is the unit plugged in? If yes, call help desk. If no, plug unit in. Is the switch turned to the “off”...

  • Page 62: Mini-Command Appears At Boot

    Mini-Command appears at boot This problem only shows up on the model DSB 6540 Terminals. To fix it, press the <Shift> key and the <Caps Lock> key repeatedly as soon as you turn the unit on. This should bring up a boot up option menu.

  • Page 63: I Cannot Connect To The Network

    I cannot connect to the network The unit is sent with either Novell or PCTCP files already installed. But the terminal must be configured for your particular network. Section 4 helps you configure the 6540 Terminal for your own network.
  • Page 64 Section 10 Troubleshooting 10-4...

  • Page 65: Appendix A Network Drivers

    Each 3.5 inch diskette contains the network driver files for wired connections: DIRECTORY FILENAME ROOT DIRECTORY !CS89XX.CFG DISK1 ENDS3ISA.VXD ENDS3ISA.SYS ENDS3ISA.386 NETCSC.INF OEMSETNT.INF OEMSETUP.INF README.EXE REL250 SETUP.EXE \BOOTPROM RBOOT.ROM \DMI CS89DMI.DLL CS89DMI.MIF CS89DMI.OVL \DOS ENDS2ISA.DOS ENDS2ISA.NIF EODIISA.COM EODIISA.INS PROTOCOL.INI \MSLANMAN.DOS\DRIVERS\ETHERNET\ENDS2ISA ENDS2ISA.DOS PROTOCOL.INI \MSLANMAN.DOS\DRIVERS\NIF...
  • Page 66 Appendix A Network Drivers DIRECTORY FILENAME NDS.MSG PROTOCOL.INI \MSLANMAN.OS2\DRIVERS\NIF ENDS2ISA.NIF \NETWARE EODIISA.LAN EODIISA.LDI \OS2 ENDS2ISA.OS2 ENDS2ISA.NIF EODIISA.SYS NDS.MSG PROTOCOL.INI \PCKTDRVR EPKTISA.COM SOURCE.ZIP COMMENTS Sample PROTOCOL.INI file. Used by LAN Manager setup utility. Novell server driver. Server driver installation file. NDIS 2.0.1 OS/2 driver. NDIS 2.0.1 installation file.

  • Page 67: Appendix B Utility Disk

    Each 3.5 inch disk contains the following utility files: DIRECTORY FILENAME ROOT COMMAND.COM DIRECTORY ROM-DOS.SYS SYS.COM \CONFIG MAXICONF.EXE CONF2.DOC TRANSFER.EXE MAXILOAD.EXE DEFAULT.DFG DEFAULT.CFG \6540 AUTOEXEC.BAT CONFIG.SYS COLOR.COM MONO.COM COMMAND.COM CURSOR.EXE LTDSPLY.COM RESET.COM SSDRIVE.EXE SSDRV.SYS TRANSFER.EXE \ROM-DOS All ROM-DOS Commands Appendix B...
  • Page 68 Appendix B Utility Disk...

  • Page 69: Rear Panel Connector Pin Assignments

    Rear Panel Connector Pin See Figure 2-1 on page 2-1 to identify individual connectors. Power Supply Connector Style 9-Pin Socket Pin # Assignments Figure C-1 Signal +5 v Appendix C...

  • Page 70: Laser Scanner Port

    Appendix C Real Panel Connector Pin Assignments Laser Scanner Port Connector Style 9-Pin Plug Pin # Bar Code Wand Port Connector PS/2 Style 6-Pin Modular Port Pin # External Keyboard Port Connector Style 6-Pin Mini-DIN Socket Pin # Laser Scanner Used As Wand Laser SOS Laser Data...

  • Page 71: Com1 And Com2 Ports

    COM1 and COM2 Ports Connector Style 9-Pin Plug Pin # LPT1 Port Connector Style 25-Pin Socket Pin # 18-25 Appendix C Real Panel Connector Pin Assignments Signals Signal STROBE DATA 0 DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 BUSY...

  • Page 72: 10Base-T Port

    Appendix C Real Panel Connector Pin Assignments 10BASE-T Port Connector Style RJ-45 8-Pin Modular Male Pin # 10BASE2 Port Connector Style BNC Connector Center Shield Signal Signal Data...
  • Page 73 You can configure the built-in bar code decoder in two ways: 1. Using MAXICONF2, a menu driven program; refer to Section 9 for more information, or 2. Using the configuration bar codes; use the following procedure for configuration. a) The terminal must be powered on to perform the configuration. b) From the Configuration Commands chart scan the command CONFIGURATION (if you intend to save your selections in the terminal’s permanent memory) or MODIFY PARAMETERS (if you are testing your selections).

  • Page 74: Appendix D Configuration Bar Codes

    Configuration Modify Parameters Store in Memory Recall Stored Parameters Return to Default Parameters Appendix D Configuration Bar Codes End Configuration End Modification...
  • Page 75 Select Family A Bar Code Reader Speaker Tone Seven different levels are available; the default level is 4. By scanning “Pitch Higher” or “Pitch Lower” successively, the pitch is raised or lowered one level until you reach the maximum or minimum level.
  • Page 76 Beeper Port Identification Speaker Tones To assign a two-beep tone sequence to a scanner port, first scan the bar code corresponding to the port to be identified, then the desired tone sequence for that port. Preamble Appendix D Configuration Bar Codes * All Ports RJ-12 Port Wand DB-9 Port (Wand)
  • Page 77 Postamble After Scanning each port selection for the preamble or postamble, scan one or more characters from the full ASCII chart on page D- 18, then scan End Selection. Note: To leave Family A after setting a preamble or postamble, you must scan the End Selection label a second time.
  • Page 78 Select Family B Read the bar code(s) corresponding to the code formats to be activated. Code 39 Standard 2 of 5 UPC/EAN Code 93 *Code39 + Codabar + UPC/EAN + Interleaved 2 of 5 + Code 128 Appendix D Configuration Bar Codes End Selection Interleaved 2 of 5 Codabar/Ames...
  • Page 79 Select Family C Character Set Start/Stop Check Digit Appendix D Configuration Bar Codes End Selection * Full ASCII Standard 43 Characters Transmitted * Not Transmitted Mod 43 calculated and transmitted Mod 43 calculated but not transmitted CIP transmitted CIP not transmitted...
  • Page 80 HIBC Format Multiread Full ASCII Control Codes Appendix D Configuration Bar Codes Italian transmitted Italian not transmitted * Not used Active * Not Active Activated by leading space Activated by user selected character Scan a character from the full ASCII test chart on page D-18.
  • Page 81 Select Family D Number of Characters Odd Number Suppressed Character Code Length Appendix D Configuration Bar Codes End Selection * Even Number Odd Number * First character suppressed Last character suppressed * Fixed for a single length; first read fixes length Fixed for two lengths;...
  • Page 82 If you selected one of the last three choices for code length, you must enter the length by scanning digits using the bar codes in the full ASCII chart on page D-18. Scan End Selection after each length. Length 1 Compose the desired length Length 2 Compose the desired length...
  • Page 83 Select Family G Select Formats Scan the bar code(s) for each format to be activated. Scan End Selection when all desired formats are specified. Add-on Digits Leading Digit UPC A Appendix D Configuration Bar Codes End Selection UPC A UPC E EAN 8 EAN 13 * All Formats...
  • Page 84 Check Digit UPC A Leading Digit UPC E Check Digit UPC E UPC E = UPC A UPC A = EAN 13 Appendix D Configuration Bar Codes * Transmitted Not transmitted * Transmitted Not transmitted Transmitted * Not Transmitted Active * Not Active Active * Not Active...
  • Page 85 Select Family G Select Formats Scan the bar code(s) for each format to activate. Scan End Selection when all desired formats are specified. Add-on Digits Leading Digit UPC A Check Digit UPC A Appendix D Configuration Bar Codes End Selection UPC A UPC E EAN 8...
  • Page 86 Leading Digit UPC E Check Digit UPC E UPC E = UPC A UPC A = EAN 13 Appendix D Configuration Bar Codes Not transmitted * Transmitted Not transmitted Transmitted * Not Transmitted Active * Not Active Active * Not Active D-14...
  • Page 87 Select Family H Code 128 Append Function (FNC 2) Check Digit Transmission of Check Digit Appendix D Configuration Bar Codes End Selection Active * Not Active * Modulo 10 Double Modulo 10 Modulo 11 Not Calculated * Transmitted Not transmitted D-15...
  • Page 88 Plessey Check Digit Code 93 Multiread Appendix D Configuration Bar Codes Transmitted * Not Transmitted Activated by leading space Activated by user selected character-- scan a character from the full ASCII test chart on page D-18. * Not Active D-16...
  • Page 89 Select Family I Code Type Identifier Scan a code format in Family B, then scan a single character from the full ASCII chart. The valid characters are A through O. Repeat this sequence for each code to be assigned an identifier. Scan End Selection after entering all desired code type identifiers.
  • Page 90 (HEX 00 - 2F) Appendix D Configuration Bar Codes “ & ‘ D-18...

  • Page 91: Full Ascii Bar Code Chart (Hex 00 - 2F

    Full ASCII Bar Code Chart (HEX 30-5F) < > Appendix D Configuration Bar Codes D-19...

  • Page 92: Full Ascii Bar Code Chart (Hex 30-5F

    Full ASCII Bar Code Chart (HEX 60-7F) Appendix D Configuration Bar Codes D-20...
