Summary of Contents for Cervélo SOLOIST
- Page 1 SOLOIST RETAILER ASSEMBLY MANUAL...
-
Page 2: Table Of Contents
Bicycle workstand (types which Soloist Parts List....Di2 Battery Installation....21 these adjustments. -
Page 3: Soloist Parts List
SOLOIST PARTS LIST SMALL PARTS Item Description Cervélo Part No. Item Description Cervélo Part No. Item Description Cervélo Part No. Soloist Seatpost Soloist Headset SPC-STA Soloist Chainstay Clamp Assembly Bearing Cap Kit BC-STA PRO-CS-ASP Protector Derailleur (30mm) Soloist Seatpost Hanger Fixing... -
Page 4: Small Parts
SMALL PARTS AB07 HANDLEBAR 80mm SP27 Seatpost Battery Mount Accessory Mount Accessory Mount BTM-596 Kit-Rear Kit-Front 128mm MT-LM-R-003 MT-LM-F-004 380mm 400mm 420mm Cervélo AB07 440mm Handlebar (Aluminum) 38cm HB-AB07-38 40cm HB-AB07-40 42cm HB-AB07-42 44cm HB-AB07-44 Brake hoses and shifter cable housing run in the channels on underside of... -
Page 5: St36 Stem
ST36 STEM FRAME & COMPONENT PREPARATION Cervélo ST36 Stem (Aluminum) 80mm ST-A027-80* To mount a cycling 90mm ST-A036-90 computer or NOTE: Non-use of the 100mm ST-A036-100 Seatpost Clamp Cover accessory such as a 110mm ST-A036-110 may result in seatpost light or camera, use 120mm ST-A036-120 binding due to Accessory Mount Kit... - Page 6 FRAME & COMPONENT PREPARATION Ensure the Chainstay Guard wraps around the inside of the chainstay. To install Accessory Mount - Front (MT- LM-F-004), angle mount into ST36 stem faceplate and torque to 2Nm. Clean the chainstay using isopropyl alcohol. DRH-WMN112 DRH-SDM Install the Chainstay Guard (PRO-CS-ASP) by removing adhesive backing, and fixing the guard...
-
Page 7: Fork Preparation & Installation
FORK PREPARATION & INSTALLATION Preload 1st Mark Do not torque Compression Plug past Fixing the recommended 8Nm maximum. If the 1. Apply grease to the bearing pockets and install 10. Install the Stem Top Cap and Preload Fixing Screw Compression Plug requires tightening past the upper and lower headset bearings into the Screw into the stem. -
Page 8: Brake Hose Routing
BRAKE HOSE ROUTING Route hydraulic brake hose through the frame and fork with These routing illustrations are intended as a supplement to Route rear brake the Disc Hose Guide (CBG-DBH). Install and adjust calipers as the manufacturer’s installation instructions only. For both hose around drive side of fork per manufacturer’s instructions. -
Page 9: Electric Wire Routing & Installation
ELECTRIC WIRE ROUTING & INSTALLATION These routing illustrations are intended as a supplement to the manufacturer’s installation instructions only. Please refer to the component manufacturer’s service center or website for further information. Brake E-Wire(SD300) 800mm E-Wire 1200mm For wired shifting E-Wire systems install the Shimano EW-... -
Page 10: Mechanical Housing Routing & Installation
Brakes hoses and shifter housing route through the ST36 Stem Cable Guide,Bearing Top Cap and Split Ring into the frame. The Cervélo Soloist requires the use of full length shifter housing for With all housing routed, cap the mechanical front Bottom Bracket Cable Port with the and rear shifting. -
Page 11: Seatpost Assembly
SEATPOST ASSEMBLY SEATPOST CUTTING INSTRUCTIONS M5 Seatpost Fixing Screws Ensure Loctite 242 is applied to threads Note: It is essential that all Cervélo Aero Seatposts have a 45 Actual Size degree chamfer cut on the rear trailing edge of the post. If trimming below the head of the 50mm button head is required after fitting, the following method is recommended. -
Page 12: Di2 Battery Installation
DI2 BATTERY INSTALLATION TIRE/RIM CLEARANCE The battery for your Shimano Di2 system mounts inside the Your Cervélo bicycle complies with the ISO 4210-2:4.10.2 standard for tire clearance. In order to comply with these safety standards and seat tube using the SP27 Seatpost Internal Battery Mount (BTM-596). As this is maintain your Limited Lifetime Warranty, a minimum of 4mm of clearance must remain between the tire and any frame element. -
Page 13: Aero Thru-Axle Installation
AERO THRU-AXLE INSTALLATION To secure wheels, install the greased axle, through the drop out and the wheel hub, aligning the threaded end of the axle with the threaded insert. Once aligned and engaged, thread the axle (clock-wise) into the threaded component of the insert until the axle is secured tightly. -
Page 14: Intended Use Of The Soloist Bicycle
INTENDED USE OF THE SOLOIST BICYCLE SOLOIST TORQUE SPECIFICATIONS Maximum Weight Limit - Cervélo Soloist Correct tightening torque of threaded fasteners is It is recommended that you permit your retailer to to frame, the stem to fork, and the handlebar to crucial to your safety. -
Page 15: Soloist Frame Details
SOLOIST TORQUE SPECIFICATIONS SOLOIST FRAME DETAILS Component Torque(Nm) Notes Soloist (FM151) Soloist (FM151) Fork Bike Name Soloist Upper Headset Bearing Dimensions 1-1/4", 34 x 46.8 x 7 , 45°x45° Fork steerer compression plug 8 Nm Lightly grease the fixing screw and tighten to the recommended torque. -
Page 16: Soloist Frame Geometry
SOLOIST FRAME GEOMETRY CERVÉLO CUSTOMER SUPPORT Contacting Customer Support Soloist (FM151) 48cm 51cm 54cm 56cm 58cm 61cm Visit www.cervelo.com/contact-us to submit a question to Cervélo. Reach 365 mm 374 mm 383 mm 392 mm 401 mm 410 mm Product Registration... - Page 17 SOLOIST RETAILER ASSEMBLY MANUAL www.cervelo.com CER-STA-V1 2022-02-14...
