TABLE OF CONTENTS Rear brake ......................9 Introduction .......................1 Replaceable Rear Derailleur mount ...............10 Features diagram .....................2 Using your Cervélo Light-Transit bag ............10 Getting started ....................3 Fork .......................3 Derailleur cables ....................3 INTRODUCTION Congratulations on your purchase of the fastest R-Series bicycle Cervélo has ever engineered. True to our mantra of Uncompromised Engineering, the R represents all that our Project California division stands for: the drive to create the ultimate road bicycle. -
Page 3: Features Diagram
FEATURES DIAGRAM A guide to your Cervélo R Rear dropout cable exit Down tube internal cable ports Electric front derailleur wire exit hole Mechanical front derailleur Battery wire hole cable exit hole Single bend cable guide... -
Page 4: Getting Started
GETTING STARTED Fork Because your R fork is engineered with the advanced Integran/PowerMetal Nanovate nickel coating on the steerer tube, Cervélo recommends using a saw designed for use on metal, with at least 32tpi to ensure an accurate end cut. Please refer to Cervélo’s fork installation manual in the Support section of our website, www.cervelo.com, before proceeding. - Page 5 Hydraulic hose click-in guide Mechanical shifting and Rubber blanking plug for brake click-in cable stops down tube access port Rubber electric wire guide Single-Bend cable guide for down tube access port Rubber blanking plug for FD wire hole Rubber electric wire guide for rear drop out Press-In cable stop for Rubber blanking plug...
- Page 6 Mechanical Front and rear derailleur cables may be assembled in the traditional method with the cable routed to the cable port on the same side as the shifter, or crossing to the opposite side; the unique design of the Single Bend bottom bracket cable guide anticipates either. Whether cables cross or not, they will not touch inside the down tube.
- Page 7 Route cables through BB guide. Front cable crosses the Route cables out of front derailleur and rear valley. Feed cables in direction of seat tube and chain stay. dropout exit holes. Snap BB guide into frame. Install chain stay housing stop. Housing stop is about 8cm farther back, so use about 8cm shorter housing than normal.
- Page 8 Electrical Note: these instructions and pictures are for assembling the Shimano and Campagnolo electronic shifting systems on the Cervélo R , and are intended as a supplement to the manufacturer’s installation instructions only. Please refer to www.shimano.com, www.campagnolo.com and www.cervelo.com for additional information. Shimano external battery Campagnolo...
- Page 9 Insert the rubber parts as shown. Shimano internal battery Close the bottom bracket with the Cervélo cover.
-
Page 10: Rear Brake
REAR BRAKE Install the front click-in cable housing stop. Route the brake cable in and out of the top tube. Install the rear click-in housing stop. For hydraulic brakes, substitute the appropriate click-in hose Install the rear housing and adjust brake as usual. guides. -
Page 11: Replaceable Rear Derailleur Mount
REPLACEABLE REAR DERAILLEUR MOUNT Your R Cervélo recommends authentic R replacement parts be used. Parts Required: Cervélo rear derailleur mount Cervélo ® Threadlocker 242 Instructions: 1. Inspect the frame for damage and ensure the frame is clear of any debris. 2. - Page 12 www.cervelo.com...
