Motorized Pinhole Wheel, Uncoated

Chapter 4 Getting Started

4.1.

Unpacking and Inspection

Open the package, and carefully remove the MPH16-UC and its accessories.
The table lists the standard accessories shipped with the device.
Name
Motorized Pinhole Wheel
USB Cable
Power Supply
Hex L-Key 1.5 mm
Socket Head Cap Screw (to Mount Cage Rods)
Dovetail Adapter for 30 mm Cage System Compatibility
User Guide
Inspect the device and its accessories for any missing parts or damage.
If there is any problem, please contact Thorlabs at Phone: 973-300-3000 or
Email: techsupport@thorlabs.com immediately. Please have the serial num-
ber (printed on the side of the unit) available while calling the technical support
team.
4.2.

Setting up MPH16-UC

4.2.1. Minimum Computer Requirements

Operating System
Driver
Other Software

4.2.2. Preparation

1.
Install the MPH16 software on your computer as described in the
Software Chapter on page 9.
2.
Mount the MPH16-UC unit on a breadboard or optical table.
3.
Remove the protective film from the unit.
4.
Connect the MPH16-UC to the computer via USB.
Page 6
64-bit, Windows 7 or 10 (Not Compatible with 32 bit)
Silicon Labs CP210x USB to UART Bridge
Visual C++ Redistributable Package (2012),
Microsoft .NET 4.5.2 or Later
Chapter 4: Getting Started
Quantity
1
1
1
1
4
1
1
