Voltage
Connection Frequency
(V)
208
3+PE
200
3+PE
200
3+PE
INSTALLATION MANUAL GETINGE WD15 CLARO
Power
Pre
fuse (A)
(Hz)
(kW)
(Curve C)
60
6.3
3 x 20
60
5.9
3 x 20
50
5.9
3 x 20
Voltage variations allowed:
short term from nominal voltage +- 10%.
2 INSTALLATION
Connection cable
Length
Area
(mm2)
(m)
4 x 12
3.0
(AWG)
4 x 4.0
3.0
4 x 4.0
3.0
Color code
L
=Red
1
L
=White
2
L
=Black
3
PE=Green/
Yellow
L
=Black
1
L
=Brown
2
L
=Gray
3
PE=Green/
Yellow
L
=Black
1
L
=Brown
2
L
=Gray
3
PE=Green/
Yellow
19 (48)
