8x6x8
Tools Needed:
(included)
Drill
6mm Allen Key
Driver Bit
NOTE: Anchoring to floor or wall may require additional tools and hardware. See your building's facility manager for proper installation.
Components:
A
B
C
D
E
F
G
17-TYP014
Page 1 of 3
5mm & 4mm
Box Level
Allen Keys
Model
A
17-2112B
B
17-2448BL
C
17-2472BL
17-17572EC
D
17-17596EC
D
E
17-17597CP
F
17-LEVKIT
G
17-12MMBOLTKIT
Square One
Ladder
Tape
Measure
Description
Single Block, 24"x12"
Assembled Block, 24"x28"
Assembled Block, 24"x72"
End Cap, 72"
End Cap, 96"
Corner Post, 97-3/4"
Leveler Kit, 2 Levelers
12mm Bolt Kit, qty 8
17-TYP014
2 to 3
Installers
17-TYP014
Quantity
8
1
10
2
(used horizontally)
5
(used horizontally)
4
10
3
800.422.5727
www.IndianaFurniture.com
33
Advertisement
Table of Contents
Related Manuals for Indiana Furniture Square One 17-TYP014
Summary of Contents for Indiana Furniture Square One 17-TYP014
- Page 1 Square One Assembly Instructions 8x6x8 17-TYP014 Tools Needed: (included) Drill 6mm Allen Key Ladder 2 to 3 5mm & 4mm Box Level Tape Driver Bit Installers Allen Keys Measure NOTE: Anchoring to floor or wall may require additional tools and hardware. See your building’s facility manager for proper installation. Components: 17-TYP014 Model...
- Page 2 Square One Assembly Instructions 8x6x8 17-TYP014 Plan adequate space for the configuration layout and an area to sub-assemble square blocks. There will be pre-assembled sections to assist during installation. Arrange the “3 High” sections on the floor in an area where the configuration will be installed. Begin by aligning holes in blocks on a horizontal surface.
- Page 3 Square One Assembly Instructions 8x6x8 17-TYP014 Now attach the “3 High” sections in a horizontal manner as shown in the illustration. Complete the block sections of the typical by attaching the single blocks. Next step is to connect the remaining Corner Posts using the 60mm bolts and nuts (included) in the blind threaded inserts.
