Installation Instructions for TEMPO
Step 6
Run a bead of silicone (provided) as shown to
the C shaped groove as shown in Diagram 5.
Diagram 5
IMPORTANT: Do not apply excessive amounts
of silicone. DO NOT APPLY SILICONE TO ANY
OTHER PARTS OF THE CONTROL INCLUDING
THE ADHESIVE GASKET.
8
Step 7
Insure the mounting surface is clean and dry
as required for good adhesion. Apply silicone
into the hole in the wall as required to create a
moisture seal.
Hold the control with the LED display in the
12 o'clock position and press the control
against the wall until the adhesive sticks and
holds firmly as shown in Diagram 6.
IMPORTANT: Two registration marks are pro-
vided to facilitate level installation. The marks
are located at the 3 o'clock and 6 o'clock po-
sitions on the back side of the control. Use a
level as required.
TEMPO / TEMPO/PLUS / TEMPO/REMOTE
® ®
& TEMPO/PLUS
®
Diagram 6
