Installing the TEMPO/EXT
Diagram 5
STEP 4
Apply silicone (provided with TEMPO
TEMPO/PLUS control) to the hole in the wall
®
as required to create a moisture seal. Apply
silicone to the back of the switch as required
to seal grout lines or as required for additional
adhesion (Diagram 5).
IMPORTANT: Use care not to apply silicone to
the adhesive gasket.
STEP 5
Push cable and switch housing into the
hole firmly.
24
Control
®
STEP 6
or Firmly connect the Plug & Play connector to
®
the steam generator connector "B" as shown
in Diagram 6.
NOTE: The connector is keyed and will only
connect in one orientation.
TEMPO / TEMPO/PLUS / TEMPO/REMOTE
® ®
Diagram 6
/ TEMPO/EXT • Owner's Manual
® ®
