- Page 1 Installation, Operation & Maintenance Manual iSteam 2.0 Control ® steam Feel Good Inc. ®...
-
Page 2: Important Safety Instructions
When installing and using this electrical equipment, basic safety precautions R E A D M E F I R S T ! should always be followed, including the following: WARNING As you follow these instruc- IMPORTATN SAFETY INSTRUCTIONS tions, you will notice warning and caution READ AND FOLLOW ALL INSTRUCTIONS symbols. -
Page 3: Table Of Contents
Table of Contents: Box Contents: Important Safety Instructions ......2 • iSteam 2.0 Control ® Installation Template ........2 • Control Cable (30 ft.) • Steamhead Box Content ..........3 • Tube of Silicone Dimensional Information ......3 Sealant Before Installing ..........4 •... -
Page 4: Before Installing
Mr. Steam products including the steam generator with the Mr.Steam control’s intended use and function. or iSteam 2.0 control. Doing so may result in an inopera- tive or hazardous installation and will void the warranty. CAUTION •... -
Page 5: Locating The Control
Installation with Optional Rough-In Box A rough-in box is supplied with iSteam 2.0 for new construction. The rough-in box will allow precise location of the iSteam 2.0 control and provide a secure and easily identifiable place for the cables while the steam room is being constructed. -
Page 6: Installation Without Rough-In Box
steam ® Controls __________________________________________________________________ Installation with Optional Rough-In Box (cont.) IMPORTANT NOTE: Be careful not to strain, staple, pinch or otherwise damage the cables. Route cables as required to permit replacement. Do not route cables inside conduit together with power lines or close to hot water or steam piping. - Page 7 steam ® Controls __________________________________________________________________ Installation Instructions for iSteam 2.0 ® STEP 1 PLUG the 30’ control cable into the iSteam 2.0 See the AudioWizard Installation Operation and control pigtail (1a). The iSteam 2.0 pigtail is the Maintenance Manual (PUR 100478) for complete longer cable with the ID Tag.
-
Page 8: Installation
Peel the double stick adhesive off the back of the iSteam 2.0 control (2a). Apply a bead of silicone around the rear of the iSteam 2.0 control to create a moisture seal (2b). Carefully feed the cables into the rough-in box and secure the control to the wall. Care must be taken to not pinch the cables. -
Page 9: Operating Instructions
Touch to wake up Monday Stand-By Screen Touch anywhere on the display to wake up the iSteam 2.0 Control Start Screen 8:19 AM Press the START button to turn the steam gen- erator ON and to display the Dashboard screen. -
Page 10: Set Temperature, User Preferences
steam ® Controls __________________________________________________________________ Set Temperature Screen 8:19 AM Press the TEMPERATURE button on the Dashboard SET TEMPERATURE USER 1 to access the SET TEMPERATURE screen. Temperature The control is preset and will display a temperature set- (swipe area) 99˚ F ting of 110 F (default setting). -
Page 11: Optional Accessories
CANCEL HOME SAVE steam ® Controls ˚F / ˚C TOGGLE __________________________________________________________________ TEMP Optional Accessories Screen 8:19 AM Press the ACCESSORIES button on the START ACCESSORIES screen to access the optional ChromaSteam ® AudioWizard accessories when a steambath is not ™ in session. -
Page 12: Settings > Passcode
steam ® Controls __________________________________________________________________ Settings > Passcode The Passcode feature can help prevent unintentional use of the steambath. Please refer to the steam generator 8:19 AM PASSCODE Installation, Operation and Maintenance manual (PN 100472) before using the steam bath. The Passcode feature cannot insure uninten- 1 2 3 4 5 Enter your Passcode tional use of the steambath. -
Page 13: Isteam 2.0 App
The wireless router can be moved tor ON and to display the closer to the iSteam 2.0 control, or a wireless repeater Dashboard screen. Steam can be installed near the iSteam 2.0 control. - Page 14 steam ® Controls __________________________________________________________________ User Settings Set Temperature Screen Pressing the USER 1, Press the temperature USER 2 or USER 3 but- on the Dashboard to ac- ton before pressing the cess the Set Temperature START button will auto- screen. Swipe your finger matically load the user to select the desired tem- settings.
-
Page 15: Care Tips, Safety & Operating Info
CAUTION If an iSteam 2.0 control is installed outside the steam room a Remote Temperature Probe (PN iMSTS) must be installed inside the steam room per installation instructions supplied with the Remote Temperature Probe. - Page 16 steam ® Feel Good Inc. www.mrsteam.com Products, information and specifications are subject to change without notice. For more information call Sales & Support at 1.800.76.STEAM (East Coast) or 1.800.72.STEAM (West Coast) for more information. steam Sussman-Automatic Corporation I hello@mrsteam.com I www.mrsteam.com ®...
