Device Type: Bacnet Explorer Ng - MSA Grid RESTful API Startup Manual

2.3.4

Device Type: BACnet Explorer NG

Please note that the 'BACnet Explorer NG' product is obsolete. Contact support to upgrade
your product to a 'BACnet IoT Gateway' – see Section
GetDeviceData (BACnet Explorer NG)
Description: Retrieve the data available under the specified device and data path.
HTTP Verb: POST
URL:
/rest/method/fieldpop-api/getDeviceData
Query String Parameters:
•
happn_token - token obtained from the login request.
HTTP Headers:
•
Content-Type -
application/json
Body Parameters (JSON):
•
parameters - object containing the following fields:
o
deviceID - the IIoT gateway ID (see Section 3.1.1)
o
path - the path of the value to get (must be 3 levels deep:
"deviceInstance/objectType:objectInstance/propertyIdentifier"
o
options - object containing the following fields:
▪
asn1 - must be set to true since default representation might change in the future
Example Body Parameters:
{
"parameters": {
"deviceID": "bigelf_rkr",
"path": "200/analog-value:0/present-value",
"options": {
"asn1": true
}
}
}
Example JSON Response:
{
"message": "Call successful",
"data": {
"value": 28,
"type": "REAL"
},
"error": null
}
2.3.5.
Grid RESTful API Start-up Guide
Install OpenVPN Client
)
20
