Spacerails Level 7 Instruction Booklet page 8

G
ARM PLACEMENT - LEVEL 1A
Step 1: Place arms onto each shaft.
NOTE:
Shaft lengths and rotation arms are
not to scale in the illustration. Shafts
and arm placement at 1:1 scale are
shown in the tri-fold.
0
59mm
0
Page 8
0
0
102mm
0
55mm
0
51mm
0
0
105mm
Seaich Corporation, LLC. All rights reserved. www.seaich.com | Spacerails, LLC. www.spacerails.com
86mm
90mm 133mm
78mm 117mm
Rotation Arm A
Rotation Arm B
Rotation Arm C
272mm
144mm
264mm
F
200mm
G
200mm
B
300mm
K
200mm
L
200mm
O
200mm
P
200mm
M
300mm
