CCU/232-NIM Install Instructions
This equipment is designed to be installed and serviced by fully qualified field engineers. No user
serviceable or installation parts inside.
Supplied:
1
x
CCU/232 board with firmware for NIM (FSI) Interface
1
x
Mounting Bracket
1
x
Power connector for CCU/232
1
x
Supervision relay connector for CCU/232
You will need:
1
x
cable from MXL-CZM (24V) & Batt. to CCU/232. Connector supplied.
1
x
interface cable from NIM-1R to CCU/232 (see later for wiring information)
1
x
(Optional) MXL-MPFO Adaptor plate (MXL installations)
Power Requirements:
Typical:
Voltage Input:
Installation of CCU/232 (MXL Fire indicator Panel):
1
200mA at 24VDC
20-30 VDC
of 6
REF: CCU232-NIM.DOC REV: B August 6, 1998
Southgate Corporate Park
CANNON HILL
4170
AUSTRALIA
Tel: +61 7 3318 6900
Fax: +61 7 3318 6905
Part #: CCU/232-NIM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tyco CCU/232-NIM
Summary of Contents for Tyco CCU/232-NIM
- Page 1 4170 AUSTRALIA Tel: +61 7 3318 6900 Fax: +61 7 3318 6905 CCU/232-NIM Install Instructions Part #: CCU/232-NIM This equipment is designed to be installed and serviced by fully qualified field engineers. No user serviceable or installation parts inside. Supplied:...
- Page 2 P2 Battery CZM-1 Pwr TB5 Pin 12 TB5 Pin 10 MMB-1 NIM-1R BATTERY BATTERY 13 14 16 12 BAT+ CHN_B COM- 24V+ CCU/232 CHN_C CHN_A RELAY Programming Laptop CHN_C CCU/232 Mounting Bracket MXL-MPFO (or SYS3-MPFO) Adaptor Plate The CCU/232 is designed to mount on the MXL-MPFO adaptor plate for the MOM-4 position, occupying one D2300CP position (MXL Only).
- Page 3 CCU/232 TB5 (CZM) Pin 12 TB5 (CZM) Pin 10 Battery 24V Operation of LEDs: • Each port has a Green and a Yellow LED. Green means the port is operating OK. Yellow means that the port is not operating OK, or there has been supervision failure on this port. of 6 REF: CCU232-NIM.DOC REV: B August 6, 1998...
- Page 4 Connecting CCU/232 RS232 Ports A and B to the CCU network: • First Determine which two ports you are connecting using the following table: CCU BOARD PORT A PORT B PORTC CCU/232 CCU/M CCU/F CCU/422 • Connecting a DTE to DCE uses a straight through cable. Connecting a DTE-DTE or DCE-DCE requires a null modem cable (pins 2 and 3 swapped on a D9 connector).
- Page 5 Configuration of CCU/232: • If your network has less than 256 CCU nodes, you can use the jumpers (IN1 to IN8) on the CCU/232 to configure the CCU Network address. Each CCU Node must have a unique address. Address 0 CANNOT BE USED. The jumpers represent a BINARY address. Example: Addr SHORT SHORT...
- Page 6 Configuration of NIM-1R: The NIM-1R must be programmed as an FSI. Consult the NIM-1R installation sheet for instructions on setting dip switches. Using CSGM, the NIM-1R(FSI) Should be set for the following communications options: Supervised Operation 9600 Baud 7 bits EVEN Parity (NOTE: The CSGM parity setting must be EVEN) 1 stop bit...
