49 ¾"
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
Greenport Collection
Full Bed
REV - 04/2025
Assembly Instructions
support@grainwoodfurniture.com
Made in Brazil
2-person assembly
Model #
Finish
GP0203
Brushed White
Brushed Walnut
GP0205
Brushed Driftwood
GP0216
Brushed Grey
GP0240
PH #2
page 1/11
Advertisement
Related Manuals for GrainWood GP0205
Summary of Contents for GrainWood GP0205
- Page 1 PH #2 Model # Finish GP0203 Brushed White Brushed Walnut GP0205 Brushed Driftwood GP0216 Brushed Grey GP0240 Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
-
Page 3: Hardware List
HARDWARE LIST 10 + 1 3,5x16 12 + 1 3,5x35 16 + 1 1/4" 7,0x50 1/4"x100 7,0x70 16 + 1 10x50 30x30x3 18 + 6 ATTENTION Before starting assembly please verify the hardware set is complete. For missing hardware please contact us at grainwoodfurniture.com/help WARNING:... - Page 4 BOX A - 1 of 2 BOX B - 2 of 2 Qty. Description Description Qty. Part # Part # Right headboard post Footboard cross piece Left headboard post Headboard Right footboard post Headboard cross piece Left footboard post Slat roll Side rail Center rail Center support...
- Page 5 Tip : Use a hammer in case dowels are hard to install by hand. 10x50 page 5/11...
- Page 6 B12+G8 B12+G8 B12+G8 G8+B12 G8+B12 G8+B12 1/4" Do not use a powerdrill as you could break the B5 nut. 1/4"x100 Flip the assembled headboard UPSIDE DOWN to install support D43 upper side 3,5x16 30x30 page 6/11...
- Page 7 Do not use a powerdrill as B12+G8 you could break the B5 nut. G8+B12 upper side upper side 1/4" 1/4"x100 upper side 3,5x16 30x30 page 7/11...
- Page 8 û û ü G8+B12 G8+B12 G8+B12 G8+B12 B12+G8 B12+G8 B12+G8 B12+G8 1/4" Do not use a powerdrill as you could break the B5 nut. 1/4"x100 page 8/11...
- Page 9 G8+B8 G8+B8 G8+B8 G8+B8 G8+B8 G8+B8 7,0x50 G8+B19 G8+B19 G8+B19 G8+B19 G8+B19 G8+B19 7,0x70 30x30 page 9/11...
- Page 10 Attention: There are no predrilled holes for the A9 screws on part 09. 3,5x16 Attention: There are no predrilled holes for the A14 screws on parts 08 and 09. 3,5x35 page 10/11...
- Page 11 Tip - Do not install wood caps in the back of the headboard posts. Instead save these 4 caps for eventual future use. The wood caps should be flush with the post surface Tip - Use a rubber mallet or a piece of wood to protect the finish when hammering the wood cap page 11/11...
