Appendix A: Drawing List
List of Drawings for LV1
The following drawings are included on the manual CD.
LV1 Drawing #
801.00115
801.00429
801.00114
LV1-UL
801.00456
B-11028
LV1
801.00085
801.13470
Options Drawing #
801.00431
801.00432
801.00433
801.00116
a-LV-1-6 8/3/11
Appendix A: Drawing List
Description
Inlet Outlet Piping Assembly LV1
Liquid End Pump Assembly
Outlet Valve Assembly
Machine Outline
Wiring Diagram LV1-UL
Coned and Threaded Connection
Machine Order
Label Assembly
Bearing Retainer Tool
Description
Cooling Option – 12 inches
Cooling Option – 36 inches
Cooling Option – 120 inches
Assembly Fan Option LV1
LV1 User Manual
