Model Number
Oil Reservoir Capacity (Approximate)
Motor Horse Power
Motor Data
Approximate Unit Dimensions (WxDxH)
Approximate Gross Weight (with oil)
Piston Seal Assembly
Coned and Threaded Fittings Torque
Nitrogen Volume/Charge Pressure for the
Accumulator
Noise level less than 77 dBA.
F-LV-1-5 8/3/2011
Model LV1 Microfluidizer Data Sheet
LV1
2.5 liters (0.7 gallon)
0.37 kw (1/2 hp)
RPM Voltage
1800 RPM 110V
1800 RPM 208 -
230VAC
1400 RPM 208 to
230VAC
51.0 x 65.0 x 60.2 cm
(20.0" x 25.8" x 23.7")
109 kg (240 lbs.)
UHMWPE & PEEK
10 Nm (8.5 Ft-lb)
1 liter / 96.5 bar (1,400 psi)
LV1 User Manual
Amperage Phase
10A 1 Phase
5A 1 Phase
5A 1 Phase
Frequency
60 Hz
60 Hz
50 Hz
