Model LV1 Microfluidizer Processor Data Sheet

Serial #:
Customer:
Intensifier
Ratio:
Process Piston Diameter:
Stroke Length:
Volume/Stroke:
Process Piston Seal:
Gasket/O-rings:

Interaction Chamber

Style:
Serial #:

Model Specifications

Model Number
Approximate Process Discharge Flow
Maximum Product Processing Pressure
Product Inlet Pressure
Inlet Reservoir Size
Maximum Operating Hydraulic Pressure
Maximum Hydraulic Oil Temperature
Process Fluid Cooling Water
Required to cool from 161°F (72°C) to
70°F (21°C) [process temperature rises
approximately 3°F (1.7°C) per 1,000 psi
(69 bar) applied pressure]
Intensifier Stroke Length
Approximate Stroke Displacement
Approximate Strokes per Minute
F-LV-1-5 8/3/2011
Model LV1 Microfluidizer Data Sheet
21:1 (Hydraulic Pressure: Process Pressure)
0.437 in. (11.1 mm)
2.50 in. (63.5 mm)
3
0.375 in. (6 ml)
UHMWPE (Ultra High Molecular Weight)
Viton (standard)
LV1
6 ml/stroke at full 2.5 inch per stroke
2069 bar (30,000 psi)
Gravity feed
10 ml (0.61 cu-in)
124 bar (1,800 psi)
140°F (60°C)
Ice Water or Dry Ice used with optional cooling coil and tray
assembly
63.5 mm (2.50 inches)
3
6 ml (.375 in )
Approximately 2 per minute (operator dependent) (see Chapter 3)
LV1 User Manual F-1
