D User Set Mode - Icom IC-F510 Instruction Manual

D User set mode

User set mode is accessed at power ON and allows you to
set seldom-changed settings. In this case you can "cus-
tomize" transceiver operation to suit your preferences and
operating style.
Entering the user set mode:
qWhile pushing and holding [
to enter user set mode ON, allowing you to set seldom-
changed settings.
wPush and hold [P0] to enter user set mode. Push [P0]
momentarily to select the item.
Then push [ ] and [ ] to set the desired level/condition.
Available set mode functions:
• Backlight :AUTO, DIM, OFF or ON
• Beep :ON or OFF
• Beep Level :1 to 5 or Link
• SQL Level :0 to 255
• AF Min level :0 to 255
• Audio Filter :3000, 3400, 0 or 300
• Mic Gain :1 to 5
ePush [POWER] (or push and hold [P0]) again to exit set
mode.
User set mode also available via the programmable key.
Please refer p. 6 [SET] section.
] and [ ], push [POWER]
(links to audio output level)
2
OPERATION
10
