5
CONVENTIONAL OPERATION

■ User set mode

User set mode is accessed at power ON and allows you to
set seldom-changed settings. In this case you can "cus-
tomize" the transceiver operation to suit your preferences and
operating style.
Entering the user set mode:
q While pushing and holding [P1] and [P2], rotate [VOL] to
turn the power ON. Then, push and hold [P0] to enter user
set mode.
w Push [P0] several times to select the appropriate item.
Then push [Side2] or [Side3] to set the desired level/con-
dition.
• Available set mode functions are Backlight, LCD contrast,
Beep, Beep Level, Ringer Level, SQL Level, AF Min Level,
Mic Gain, VOX Gain, VOX Delay, Battery Voltage and Signal
Moni.
e Rotate [VOL] to turn the power OFF to exit user set mode.
NOTE: User set mode is also available via a programma-
ble key. Please refer to ((☞ p. 9)) [User Set Mode] section.
16

■ Emergency transmission

When [Emergency Single] or [Emergency Repeat] is pushed,
an emergency signal is automatically transmitted for the spec-
ified time period.
When [Emergency] is pushed, the DTMF emergency signal
is transmitted on the priority channel.
When [Emergency Single] or [Emergency Repeat] is pushed
for the specified time period, the DTMF emergency signal is
transmitted once or repeatedly on the emergency channel.
However, when no emergency channel is specified, the signal
is transmitted on the previously selected channel.

■ Scrambler function

The voice scrambler function provides private communication
between stations. The frequency inversion type is equipped
to all versions, moreover, the optional Rolling or Non-rolling
type can be available.
q Push [Scrambler] to turn the scrambler function ON.
• " " appears.
w Push [Scrambler] again to turn the scrambler function
OFF.
• " " disappears.
