Specifications And Options; I Specifications - Icom IC-2720H Instruction Manual

13

SPECIFICATIONS AND OPTIONS

I Specifications
D D GENERAL
• Frequency coverage
Version Left Band
USA, Rx: 118–549.995*
General Tx: 144–148, 430–450*
Rx: 136–173.995,*
Asia
Tx: 144–148, 430–440
Australia
Taiwan,
Korea
* 1 Guaranteed: 144–148 MHz range only.; *
430–440 MHz for the General version; *
869.010 to 893.990 MHz ranges are inhibited for USA version and not guaranteed.
• Type of emission
• Number of memory channels
• Frequency resolution
• Operating temperature range
• Frequency stability
• Power supply requirement
• Current drain
(at 13.8 V DC: approx.)
Transmit
Receive
(simultaneous receive)
• Antenna connector
• Dimensions
(proj. not included)
Main Unit
Remote controller
• Weight
(approx.)
Main unit
(incl. separation cable)
Remote controller
75
: (unit: MHz)
Right Band
Rx: 118–173.995* 1 , 375–549.995,*
1
810–999.99* 4
2
Tx: 144–148, 430–450*
1 430–440 Rx: 136–173.995,* 1 430–440
Tx: 144–148, 430–440
Tx/Rx: 144–148, 430–440
Tx/Rx: 144–146, 430–440
2 Guaranteed: 440–450 MHz range for the USA,
3 Not guaranteed; * 4 824.010 to 848.990 and
: FM, AM
(Receive only)
: 212 (incl. 10 scan edges and 2 calls)
: 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
: –10°C to +60°C; +14˚F to +140˚F
: ±10 ppm
(–10°C to +60°C)
: 13.8 V DC ±15%
:
at 50 W 12 A
standby 1.2 A
max. audio 1.8 A
(50 Ω)
: SO-239
:
140(W) × 40(H) × 187(D) mm
5 1 ⁄ (W)×1 9 ⁄ (H)×7 3 ⁄ (D) in
2 16 8
140(W) × 50(H) × 24.5(D) mm
5 1 ⁄ (W)×1 31 ⁄ (H)× 31 ⁄ (D) in
2 32 32
:
1.25 kg; 2 lb 12 oz
150 g; 5.3 oz
D D TRANSMITTER
• Modulation system
• Output power
• Max. frequency deviation
3
• Spurious emissions
2
• Microphone connector
D D RECEIVER
• Receive system
• Intermediate frequencies
Left band
Right band
• Sensitivity
(FM: at 12 dB SINAD/AM: at 10 dB S/N)
Frequency range
118–159.995 MHz
160–173.995 MHz
174–179.995 MHz
180–219.995 MHz
220–259.995 MHz
260–349.995 MHz
350–374.995 MHz
375–399.995 MHz
400–429.995 MHz
430–450 MHz
450.005–499.995 MHz
500–549.995 MHz
810–879.990 MHz
880–999.990 MHz
: Variable reactance frequency modulation
: VHF 50/15/5 W*
(approx.)
UHF 35/15/5 W*
(approx.)
*25/15/5 W only for the Taiwan version.
: ±5.0 kHz
(wide)
±2.5 kHz
(narrow: Left band only)
: Less than –60 dB
(600 Ω)
: 8-pin modular
: Double-conversion superheterodyne
:
1st: 38.85 MHz, 2nd: 450 kHz
1st: 46.05 MHz, 2nd: 455 kHz
:
Left band (µV) Right band (µV)
0.18/0.45
0.32/— 0.2/—
0.32/— N/A
3.5/— N/A
0.32/0.79 N/A
3.2/5.6 N/A
0.32/1.0 N/A
0.22/0.63
0.22/—
0.18/—
0.22/—
0.32/— 0.22/—
N/A 0.45/—
N/A 1.0/—
