Icom IC-2720 User Reference Manual

To enter different modes:
To enter set-up mode:
MAIN*BAND for desired band
Select
Push SET to enter set mode
Push LOW PRIO to select item
Rotate DIAL for value/condition
Push TONE DTMF to exit
To enter the memory banks:
10 banks (A to J) vs. Regular memory 000 to 199
- Push desired band [M/CALL●MW] several times till
you see Bank initial appear e.g. "A"
- Push [MAIN●BAND] for 1 sec. Till bank initial blinks
- Rotate the same band's [DIAL] to select the desired bank,
A to J. Banks that have no programing are skipped.
- Push the [MAIN●BAND] to set the bank (initial stopes
blinking)
- Rotate [DIAL] to select the contets in the bank
- Push [MAIN BAND] for 1sec, then momentarirly again
to set the change and treturn to regular memory.
Manually Entering Repeater values
Selecting the frequency:
Push [V/Mhz●SCAN] till you see the frequency with
dashes like: 146._ _ _ and multiple times to see select which
digit to change. The use [DIAL] to select the frequency.
Then [V/Mhz●SCAN] for 'setting the frequncy'.
[Note: US version may auto set the correct offset & tone,
if not continue.]
Selecting the +, -, or no Offset:
Press [DIP * MON] to switch between – offset "Dup-" &
plus offset, "Dup" and no offset (no Dup showing)
Setting the Offset Frequency:
Push [SET ,-o ] several times till you see "Dup"
blinking in the upper lf. & current offset freq.
Rotate [DIAL] to desired offset
Press [TONE * DTMF] to set & exit
Selecting Tone:
Push [TONE * DTMF] till "T" appears to turn on the tone
(it defaults to 88.5).
Setting the Tone value:
Press [SET ,-o ] several times till you see the current tone
and "rE" (lower Rt. Corner) . Then rotate band [DIAL] to
the desired tone. Push [TONE * DTMF] to exit & set the
new tone.
US Models only
To Use Cross Band Repeat Mode:
- Set the frequencies on both bands
(Receive on VHF on left e.g. 146.550,
Send UHF on right e.g. 444.525)
* Press and hold LOW and DUP on the faceplate,
then quickly press SET (above the right-side
volume knob)
for two seconds, then let go of all 3 buttons
- Two flashing Ls will appear on the display --
(the Ls must be flashing)
* To exit this function: press SET for two seconds
Turning on & off the Weather Report
* Press [M/CALL*MW] till you see a rCH-1 or 2 or...
in the display. Then rotate the [DIAL] to select the
weather channel appropriate to your area.
USA & General version Frequency Bands
Frequency Left band
127 Available
222 Available
375 Available
500 Available
900 Not-Available
Call Channel Selection
Push [M/CALL●MW] till you see 'C1' or 'C2'
select [DIAL] select call channel
Enter / Program call Channel
Select the frequency & settings
Push [M/CALL●MW] for 1 sec.
Rotate [DIAL] to select the desired call channel
"C1" or "C2" blink.
Push [M/CALL●MW] for 1 sec. To program
(3 beeps sound & eht unite retursn to VFO mode.)
Standard 2 Meter & 70 Cm bands
2 Meters: 144.0-148.0 MHz
70 CM : 420.0-450.0 MHz
Right band
Available
Not-Available
Available
Available
Available
Compiled by Martin Brossman
KI4CFS can be reached at
KI4CFS@toinquire.com
IC-2720
User
Reference
Guide
version: 3.0
Produced by Ham's for
Hams! For personal use only
& not associated with ICOM
in any way. Just "Ham's
helping Ham's"
Photo from ICOM website
