Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly. In
the event of product failure within its intended use over the course of the
first 3 years after date of purchase, we will remedy the problem as quickly
as possible once it has been brought to our attention. In the unlikely event
of such an occurrence, or if you require any information about the product,
please contact us via our helpline support services, details of which are to be
found both in this manual and on the product itself.
GB
IE
PRODUCED IN CHINA FOR:
ALDI STORES LTD. PO BOX 26, ATHERSTONE
WARWICKSHIRE, CV9 2SH
ALDI STORES (IRELAND) LTD.
PO BOX 726, NAAS, CO. KILDARE
Visit us at www.aldi.com
AFTER SALES SUPPORT
+44(0) 1904727501
+353(0) 19022605
GB
IE
support@coreservice.co.uk
MODEL:
GLM44A
3
814142
YEAR
WARRANTY
04/2022
User Manual
Electric lawn mower
GLM44A
Original User Manual
Advertisement
Table of Contents
Related Manuals for ALDI FERREX GLM44A
Summary of Contents for ALDI FERREX GLM44A
- Page 1 PRODUCED IN CHINA FOR: ALDI STORES LTD. PO BOX 26, ATHERSTONE WARWICKSHIRE, CV9 2SH ALDI STORES (IRELAND) LTD.
-
Page 4: Scope Of Delivery/Device Components
Scope of delivery/device components Scope of delivery/device components Handle grip (top) Pull relief (for the power cable) Quick-release lever (handle joint) Bottom part of handle Collecting bag Connecting piece (2x) Carry handle Cutting height lever Motor unit Connection cable Handle mount Quick-release lever (handle mount) Discharge flap Fill level indicator... -
Page 5: Table Of Contents
Table of content Table of content Overview........................2 Scope of delivery/device components..............4 General information....................6 Reading and storing the operating manual..............6 Proper use...........................6 Explanation of symbols...................6 Safety........................8 Before first use......................11 Check the device and scope of delivery.................11 Mounting the handle......................11 Preparing the collecting bag..................12 Operation....................... -
Page 6: General Information
General information General information Reading and storing the operating manual This operating manual is part of the electric lawn mower (hereinafter also called "device"). It contains important information on how to set up and use the product. Before using the device, read the operating manual carefully, in particular the safety instructions. - Page 7 Explanation of symbols This symbol indicates that the device complies with the protection class II. General warning sign. Caution! Discharge of cuttings or stones. Always keep the discharge flap closed. Warning! Rotating blade! Do not reach or step underneath the device. Warning! Electric voltage.
-
Page 8: Safety
Explanation of symbols Cutting width of the device. The symbol shows the maximum sound power level L IPX4 The device is protected from all sides against water splashes. Safety The following signal words are used in this operating manual. This signal symbol/word denotes a WARNING! hazard with an average risk level that could lead to death or severe injury if... - Page 9 Safety - In the case of a fault, immediately disconnect the device from the power cable and/or mains. - Do not connect the device if the device, power cable or a mains plug shows visible signs of damage. - Damaged power cords and devices must only be repaired by the manufacturer, their customer service or a qualified professional.
- Page 10 Safety older persons with reduced physical and mental capacities) or lack of experience and knowledge. Improper handling of the device can lead to severe injuries or damage to the device. - This lawn mower may be used by persons with impaired physical, sensory or mental capacities or those lacking experience and knowledge if they are supervised or have been instructed in how to safely use the lawn mower and...
-
Page 11: Before First Use
Safety - Do not work on areas with an inclination above 20 % as you might slip and lose control of the device. - Always keep the discharge flap closed and keep away from the discharge chute when working without a collecting bag. - Wait until the blade stands still before removing any blockage or clogging and carrying out any other work on the device. -
Page 12: Preparing The Collecting Bag
Before first use 3. Place the bottom part of the handle on the handle mount . Check whether the serrations of the locking washer engage correctly in the handle mount. The holes of the handle mount, the connecting pieces and the bottom part of the handle must point towards each other. -
Page 13: Operation
Before first use 1. Insert the collecting bag handle into the recesses on the top of the collecting 2. Pull the plastic rims of the collecting bag from the inside over the steel frame. 3. Check whether the plastic rims are properly in place on all sides. 4. -
Page 14: Adjusting The Handle Position
Operation Always keep the discharge flap closed when mulching. - Mow slowly and try not to use the entire cutting width to cut the grass evenly at high rotation speed. A high cutting load reduces the blade's rotation speed. - Remove any branches, pegs, stones, strings and mounds (molehills) before mowing to safeguard the device. -
Page 15: Turning The Motor On And Off
Operation Turning the motor on and off Caution! Blade keeps moving The motor is activated by means of a safety switch. When you let go of the safety bar, the motor stops. Only turn on the motor on the grass. 1. -
Page 16: Cleaning
Cleaning Cleaning WARNING! Risk of electric shock! Moisture in the device may cause a short circuit or electric shock. - Before cleaning, disconnect the power cable from the socket. - Make sure that no water or other liquid gets inside the housing. -
Page 17: Maintenance
Cleaning Do not operate the device with a damaged or worn blade! If necessary, have the blade sharpened or exchanged in a specialist workshop (for the blade type, see "Technical specifications"). 7. Set the device upright again. 8. Check all connections (handle, collecting bag) for tight fit. The device is ready for storage. -
Page 18: Transport Instructions
Storage Folding in the handle 1. Release the quick-release levers on the handle mount 2. Take the serrations of the locking washer out of the handle mount by lifting it slightly and then set down the handle on the device. 3. -
Page 19: Troubleshooting
Troubleshooting Troubleshooting Problem Possible cause Fault rectification Motor does not start up The mains plug is not Check that the mains plug is correctly plugged in. fitted properly. The socket does not supply Check the power cable for any power/the fuse has damage. -
Page 20: Technical Data
Technical data Technical data Model GLM44A Rated voltage/frequency: 230–240 V~/50 Hz Rated power: 1800 W Protection class: IP rating: IPX4 Max. rpm: 3500 min Weight (Net): 16.5 kg Dimensions (H x L x W) 1160 × 1180 × 475 mm Cutting width: 440 mm Mowing length setting:... -
Page 21: Declaration Of Conformity
Declaration of conformity Declaration of conformity Original EU Declara of Conformity MEROTEC GmbH O o-Brenner-Str. 8, 47877 Willich, Germany herewith declare under our own, sole responsibility that our product Electric lawnmower Model no. GLM44A complies with the following direc 2006/42/EC Machinery Direc 2014/30/EU EMC-Direc 2000/14/EC... -
Page 22: Disposal
Disposal Disposal Disposing of packaging Dispose of packaging according to type. Sort the paperboard and cardboard as waste paper and the film as recyclable material. Dispose of old electrical device This symbol indicates that this product may not be disposed of together with domestic waste in compliance with the (2012/19/EU) Regulation pertaining to waste electrical and electronic devices (WEEE).
