Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly. In
the event of product failure within its intended use over the course of the
first 3 years after date of purchase, we will remedy the problem as quickly
as possible once it has been brought to our attention. In the unlikely event
of such an occurrence, or if you require any information about the product,
please contact us via our helpline support services, details of which are to be
found both in this manual and on the product itself.
GB
IE
PRODUCED IN CHINA FOR:
ALDI STORES LTD. PO BOX 26, ATHERSTONE
WARWICKSHIRE, CV9 2SH
ALDI STORES (IRELAND) LTD.
PO BOX 726, NAAS, CO. KILDARE
Visit us at www.aldi.com
AFTER SALES SUPPORT
03456939277
1890882374
GB
IE
customerservice@b-gr8.co.uk
MODEL:
FS-ARM 4037
3
823925
YEAR
WARRANTY
04/2023
User Manual
CORDLESS LAWNMOWER
Original User Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ALDI FERREX FS-ARM 4037
Summary of Contents for ALDI FERREX FS-ARM 4037
- Page 1 PRODUCED IN CHINA FOR: ALDI STORES LTD. PO BOX 26, ATHERSTONE WARWICKSHIRE, CV9 2SH ALDI STORES (IRELAND) LTD.
-
Page 4: Included In Delivery/Device Parts
Included in delivery/Device parts Included in delivery/Device parts Safety bar Guide shaft Fill level indicator Cover (grass collection box) Grass collection box Safety flap Cutting height adjuster Protective cover Guide bar frame Cable Quick-release fastener, 4× Cable clamp, 2× Safety button Safety key Washer (quick-release fastener), 4×... -
Page 5: Table Of Contents
Table of content Table of content Overview........................2 Included in delivery/Device parts................4 General information....................6 Reading and storing the user manual................6 Proper use...........................6 Explanation of symbols...................6 Safety........................8 Safety notes........................8 Residual risks........................14 Before first use....................... 15 Check the device and scope of delivery................ 15 Assembling the lawnmower...................15 Folding up the guide bar.................... -
Page 6: General Information
General information General information Reading and storing the user manual These operating instructions belong to this cordless lawnmower (hereinafter only referred to as "lawnmower" or "device"). They contain important information on commissioning and handling. Before using the device, read the operating manual carefully, in particular the safety instructions. - Page 7 Explanation of symbols This symbol provides you with useful additional information on handling and use. The UK Conformity Assessed (UKCA) seal states that the product meets all legal requirements in the UK and that the corresponding conformity assessments were successfully completed. Declaration of conformity (see chapter “Declaration of conformity”): Products marked with this symbol meet all the applicable Community regulations of the European Economic Area.
-
Page 8: Safety
Explanation of symbols Caution! The cutting blade is sharp. The cutting blades continue to rotate after the motor has been switched off. Wait until all rotating parts have come to a standstill. Do not expose the device to rain or other weather influences and do not operate it in a wet or damp environment. - Page 9 Safety - When adjusting the lawnmower, ensure that your fingers cannot be trapped between moving cutting blades and fixed parts. - Do not remove the grass collection box when the lawnmower is operating. - Always wear sturdy shoes and long trousers when using the lawnmower.
- Page 10 Safety - Ensure that the lawnmower is stable, particularly on slopes. Do not mow on excessively steep slopes. Take particular care when changing direction on slopes. - Mow across the slope and never upwards or downwards. - Carefully check the surface on which you wish to use the lawnmower and remove any objects that could be caught and ejected (e.g.
- Page 11 Safety WARNING! Risk of electric shock! Faulty electric installation or excess mains voltage can cause an electric shock. - Do not open the device. Leave repairs to a qualified service technician. Contact the service address indicated on the warranty card. Liability and warranty claims are excluded if you carry out repairs yourself, improperly connect the device to the power supply or operate it incorrectly.
- Page 12 Safety - The device must not be used by persons with reduced physical, sensory or mental capacities or persons not familiar with or experienced in the handling of such devices, unless: • they are supervised or instructed by a person responsible for them; •...
- Page 13 Safety - Carefully check the surface on which you wish to use the lawnmower and remove any objects that could damage the lawnmower and the cutting tools, fasteners or the entire cutting unit in particular. - Ensure that the cutting blades do not come into contact with the ground on uneven surfaces.
-
Page 14: Residual Risks
Safety - Stop the lawnmower, remove the safety key and ensure that all moving parts have come to a complete standstill and have cooled down: • whenever you are not using the lawnmower, • to clear a blocked cutting blade, •... -
Page 15: Before First Use
Before first use Before first use Check the device and scope of delivery WARNING! Danger of suffocation! Children may become tangled up in the packaging film when playing with it and suffocate. - Do not let children play with the packaging film. NOTE! Risk of damage! If opening the packaging with a sharp knife or other pointed... -
Page 16: Folding Up The Guide Bar
Before first use 6. Insert the quick-release levers from the outside through the holes in the guide bar and guide bar frame (see Fig. 3). 7. Insert the bolts from the inside onto the threads of the quick-release levers and turn in the quick-release levers until they can be secured by closing them. 8. -
Page 17: Adjust Cutting Height
Operation Objects that are picked up and flung around by the lawn mower can also cause injuries. - When adjusting the device, make sure that your fingers do not get stuck between moving blades and stationary parts. - Do not open the safety flap if you are operating the device without the grass collector. -
Page 18: Using The Grass Collection Box
Operation 4. Lift the safety bar The motor starts and the cutting blades begin to rotate. The motor runs and the cutting blades rotate as long as the lock bar is raised. You can let go of the lock button as soon as the motor is running. 5. -
Page 19: Use Mulch Kit
Operation Use mulch kit The mulch insert prevents the grass from being discharged to the rear by blocking the collection chute. This results in the cut grass being distributed over the lawn again during mowing. 1. Open the rear protective cover , hold it in this position and slide the mulch into the rear discharge chute. -
Page 20: Repair Service
Cleaning and maintenance - Take out the battery before cleaning the device. - Clean the housing and the grass discharge thoroughly after each use and allow all parts to dry properly. Otherwise, damp grass residues may harden or start to get mouldy and are then difficult to remove. -
Page 21: Transport And Storage
Cleaning and maintenance 4. Use a screwdriver to unscrew the fastening screw and remove it together with the washer (see Fig. 6). 5. Remove the cutting blade 6. Place a new cutting blade on the drive plate . 7. Place the washer and fastening screw back onto the cutting blade and tighten them. -
Page 22: Troubleshooting
Transport and storage - Make sure that all parts are completely dry before transport and storage. - If necessary, undo the quick snaps and carefully fold the guide bar and the guide bar assembly - Always store the lawn mower and the battery in a dry place. - Keep the lawn mower and the battery away from direct sunlight. -
Page 23: Technical Data
Troubleshooting Fault Possible cause Rectification The mowing The cutting blade is Replace the cutting blade (see performance is blunt. “Replacing the cutting blade”). poor The rechargeable Replace the rechargeable battery. battery is faulty. To do this, contact the manufacturer at the service address specified on the guarantee card. -
Page 24: Battery And Charger Information (Not Included In The Scope Of Delivery)
Technical data Sound pressure level L 79,8 dB (A); K=3,0 dB(A) Vibration a (EN 60335): 0,48 m/s ; K=1,5 m/s Protection class: Battery and charger information (not included in the scope of delivery) Only use the device with Active Energy® batteries and chargers that meet the following technical specifications: Suitable for Active Energy®... -
Page 25: Spare Parts List
Technical data Keep noise emissions and vibrations to a minimum! - Only use perfectly functioning devices. - Clean and service the device regularly. - Adapt your way of working to the device. - Do not overload the device. - Have the device checked, if necessary. - Switch the device off when it is not in use. -
Page 26: Declaration Of Conformity
Declaration of conformity Declaration of conformity EC Declaration of Conformity We, Mogatec GmbH, Im Grund14, D-09430 Drebach, Germany hereby declare that the product Cordless lawnmower FS-ARM 4037 Ferrex 40 V DC / cutting width 370 mm to which this declaration refers, complies with the relevant essential health and safety requirements of the EC Directive 2006/42/EC (Machinery Directive), 2000/14/EC+2005/88 EC (Noise Directive), 2014/30/EU (EMC Directive), 2011/65/EC amended by (EU) 2015/863 (RoHS Directive) as well as the requirements of the other relevant EC Directives and their... -
Page 27: Disposal
Disposal Disposal Disposing of packaging Dispose of packaging according to type. Sort the paperboard and cardboard as waste paper and the film as recyclable material. Recycle Dispose of old electrical device Applicable in the European Union and other European countries with systems for separate collections of recyclable waste.
Need help?
Do you have a question about the FERREX FS-ARM 4037 and is the answer not in the manual?
Questions and answers
My ferrex starts but after 3 seconds stops. What could be the problem? Last week it worked properly. But after i charge the battery, it's starts but after 3 seconds stops. Please help!
If the ALDI Ferrex FS-ARM 4037 lawnmower starts but stops after 3 seconds, possible problems could include:
1. Battery issue: The battery may not be fully charged or may not meet the required specifications (20/40 V 90 Wh Li-ion Active Energy® type). Only use the recommended battery models.
2. Safety key not properly inserted: Ensure the safety key is correctly in place.
3. Fault or blockage: There may be a blockage in the cutting blade or discharge channel. Stop the mower, remove the safety key, and inspect for obstructions.
4. Overload or fault condition: The mower may detect a fault or overload, causing it to shut down. Check for damage and ensure all parts are functioning before restarting.
Only resume operation once all faults are resolved and the mower is safe to use.
This answer is automatically generated
ou mettre la piece 18 ? comment l'inserrer
Part 18, the mulch kit, should be inserted into the rear discharge of the ALDI FERREX FS-ARM 4037. To do this, open the rear protective cover, hold it in position, and slide the mulch kit into the rear discharge.
This answer is automatically generated
