    Introduction This document is one of four that will help operators to use their robots safely and effectively: ▪ ExR-1 Robot Operator Operating Instructions ▪ ExR-2 and Docking Station Operating Instructions ▪ Robot System Operating Guide. ▪ Robot System Deployment Guide.

  • Page 7: Robots

    Once deployed, users will have little reason to interact with robots. However, the major components are shown on the drawings below. Robot specifications are included in Section 9. ExR-1 Robot Platform ExR-2 Robot Platform The only controls mounted on each robot are the red emergency stop switch and the black on/off switch.
  • Page 8 Owner: Date: Robot System 20190122IP1 Page 7 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.

  • Page 9: Control Stations

    Once the induction charger is connected, the “Wireless Charger” and “Charging” boxes on the cloud software will be checked. Hovering the cursor over the charging box will reveal the charging current. It takes approximately 6 hours to recharge fully an empty ExR-1 battery pack and 12 hours for an ExR-2 battery pack.

  • Page 10: Cloud Software

    Owner: Date: Robot System 20190122IP1 Page 9 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.

  • Page 11: Driver Screen

    Owner: Date: Robot System 20190122IP1 Page 10 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.
  • Page 12 Owner: Date: Robot System 20190122IP1 Page 11 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.
  • Page 13 Owner: Date: Robot System 20190122IP1 Page 12 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.

  • Page 14: Mission Editor

    ▪ Zoom in with the mouse wheel or by left-clicking and dragging. ▪ Pan by using the shift key, left-clicking and dragging. 5.5. Engineer Screen This screen is used by ExRobotics and Energy Robotics and will not usually be used by customers. ExRobotics B.V. Document No.: Owner:...

  • Page 15: Autonomous Missions

    Owner: Date: Robot System 20190122IP1 Page 14 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.

  • Page 16: Line Following Navigation

    Owner: Date: Robot System 20190122IP1 Page 15 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.

  • Page 17: Full 3D Navigation

    Owner: Date: Robot System 20190122IP1 Page 16 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.
  • Page 18 Owner: Date: Robot System 20190122IP1 Page 17 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.
  • Page 19 Owner: Date: Robot System 20190122IP1 Page 18 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.
  • Page 20 Owner: Date: Robot System 20190122IP1 Page 19 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.

  • Page 21: Operating Robots

    ▪ The robot isn’t designed to climb stairs or gradients above 30 degrees. It may topple over. It can however cross steps up to 20cm (ExR-1) and up to 10cm (ExR-2). Approach them perpendicularly. ▪ The downward facing camera can enable precise positioning.

  • Page 22: Authorisation And Authentication

    Google Chrome: https://login.energy-robotics.com. 7.3. Customer support Every customer will have an ExRobotics account manager that will: ▪ Agree the specifications for each robot and the associated support package. ▪ Organise robot deliveries and deployment support until a customer has sufficient experience to be independent.

  • Page 23: Software Releases

    ▪ The robot will be inspected for visible damage. In particular, if the wire antennas are too bent they should be replaced. New wires must be sourced from ExRobotics to maintain the robot’s Ex status. They screw onto their bases.

  • Page 24: Calibrating Gas Detectors

    They’re available in the resources section of the ExRobotics’ website. ExR-1 gas sensors can be accessed via the hatch between the tracks on the left hand side of robots which is secured with two hexagonal socket-head screws (see picture). ExR-2 gas sensors are accessed by removing the upper cladding.

  • Page 25: Changing Exr-2 Sim Cards

    Also ensure that the O Ring is correctly seated. ▪ Re-torque the bolts securing the front to the back enclosures to 7 Nm with a calibrated torque wrench. ExRobotics will provide remote support the first time a customer performs this task. 7.10. Security Robots are fitted with security features: ▪...

  • Page 26: Questions And Answers

    8.2. Why can’t I connect to a robot? ExRobotics check whether each robot connects to the server before it’s deployed. Therefore connection issues are often because the control station hasn’t connected to the server. The most common reason is that a customer firewall has blocked access.

  • Page 27: Why Doesn't My Controller Work

    In operation this depends on usage and the age of the batteries. However, the life of a full battery pack will usually lie between: ▪ 90 minutes (ExR-1) or 150 minutes (ExR-2) if a robot’s driven continuously. ▪ 7 hours if it’s static with its sensors on (but no lights).

  • Page 28: How Do I Refresh My Control Screen

    Owner: Date: Robot System 20190122IP1 Page 27 of 30 Operating Guide Version No.: 12 Ian Peerless 2021-07-20 This document is considered an uncontrolled copy when printed. Always ensure that you print and use a current version. Copyright 2021 ExRobotics B.V.

  • Page 29: Robot And Docking Station Specifications

    Robot and Docking Station Specifications 9.1. Worksite and Climate: ExR-1 Robot Description Specification Operating Temp. -20C to +50C Range Equip. Protection Gb (Zone 1) Level Explosion Group IIB (ethylene) Temperature Class T4 (maximum surface temperature 135C) Ingress Protection Equivalent to IP54 (dust protected, splashing water resistant).

  • Page 30: Standard Exr-1 Specifications

    9.3. Standard ExR-1 Specifications Description Specification Max. width 690 mm Max. length 950 mm Max. height 560mm, including antennas Min. ground 40 mm clearance Robot Weight Less than 100kg Speed Proportionally controllable speed up to 2 km/hour. Driver can switch...

  • Page 31: Standard Exr-2 Specifications
