Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
MTM850
BAE-F8199-EZ
[ENG (E)]
DIC183

Advertisement

Table of Contents
loading

Related Manuals for Yamaha XSR900 2019

Summary of Contents for Yamaha XSR900 2019

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MTM850 BAE-F8199-EZ [ENG (E)] DIC183...
  • Page 2 UBAEE0E0.book Page 1 Tuesday, December 10, 2019 2:42 PM EAU81560 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the MTM850, you are benefiting from Yamaha’s vast experience and newest technology regarding the de- sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 UBAEE0E0.book Page 1 Tuesday, December 10, 2019 2:42 PM Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 5 UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Important manual information EAU10201 MTM850 OWNER’S MANUAL ©2019 by Thai Yamaha Motor Co., Ltd. 1st edition, December 2019 All rights reserved. Any reprinting or unauthorized use without the written permission of Thai Yamaha Motor Co., Ltd.

  • Page 6: Table Of Contents

    UBAEE0E0.book Page 1 Tuesday, December 10, 2019 2:42 PM Table of contents Location of important labels... 1-1 Adjusting the front fork ....4-22 Why Yamalube......7-12 Adjusting the shock Coolant ......... 7-13 Safety information......2-1 absorber assembly ....4-24 Air filter element......7-14 Helmets ..........
  • Page 7 UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Table of contents Checking and lubricating Index ..........11-1 the sidestand ......7-26 Lubricating the swingarm pivots ...7-27 Checking the front fork....7-27 Checking the steering ....7-28 Checking the wheel bearings ..7-28 Battery ...........7-28 Replacing the fuses.......7-30 Replacing the headlight bulb..7-32 Replacing the auxiliary...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Location of important labels 100kPa=1bar kPa,psi kPa,psi 250,36 290,42 250,36 290,42...

  • Page 10: Safety Information

    UBAEE0E0.book Page 1 Tuesday, December 10, 2019 2:42 PM Safety information Never operate a motorcycle with- pears to be very effective in reduc- EAU1028C out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident.
  • Page 11 UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Safety information Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you.
  • Page 12 UBAEE0E0.book Page 3 Tuesday, December 10, 2019 2:42 PM Safety information Avoid Carbon Monoxide Poisoning Do not run engine outdoors where When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind: monoxide, a deadly gas.
  • Page 13 Yamaha accessories, which are avail- performed to your vehicle that change lightweight as possible and able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...

  • Page 14: Helmets

    UBAEE0E0.book Page 5 Tuesday, December 10, 2019 2:42 PM Safety information operator and may limit control Remove all loose items from the EAUU0033 Helmets ability, therefore, such accesso- motorcycle. Operating this vehicle without an ap- ries are not recommended. Check that the fuel cock (if proved motorcycle helmet increases Use caution when adding electri- equipped) is in the off position and...
  • Page 15 UBAEE0E0.book Page 6 Tuesday, December 10, 2019 2:42 PM Safety information Correct usage ZAUU0004 ZAUU0006 ZAUU0003 Full-type: use only for riding at low Wrong usage to mid-range speeds ZAUU0005 ZAUU0007 Types of helmets and their usage Full-face-type: use for riding at Half-type: use only for riding at low mid-range to high speeds speeds...

  • Page 16: Description

    UBAEE0E0.book Page 1 Tuesday, December 10, 2019 2:42 PM Description EAU10411 Left view 1. Spring preload adjuster (page 4-22) 2. Rebound damping force adjuster (page 4-24) 3. Seat (page 4-21) 4. Storage compartment (page 4-22) 5. Spring preload adjuster (page 4-24) 6.

  • Page 17: Right View

    UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Description EAU10421 Right view 3, 4 1. Fuses (page 7-30) 9. Brake pedal (page 4-15) 2. Fuel tank cap (page 4-18) 10.Rear brake fluid reservoir (page 7-20) 3. Spring preload adjuster (page 4-22) 4.

  • Page 18: Controls And Instruments

    UBAEE0E0.book Page 3 Tuesday, December 10, 2019 2:42 PM Description EAU10431 Controls and instruments 1. Clutch lever (page 4-14) 2. Left handlebar switches (page 4-13) 3. Main switch/steering lock (page 4-2) 4. Multi-function meter unit (page 4-6) 5. Front brake fluid reservoir (page 7-20) 6.

  • Page 19: Instrument And Control Functions

    When necessary, take the tire immobilizer system must be re- vehicle along with all three keys to a placed. Therefore, handle the keys Yamaha dealer to have them re-regis- carefully. tered. Do not submerse in water. Do not use the key with the red bow for Do not expose to high tempera- driving.

  • Page 20: Main Switch/Steering Lock

    UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Instrument and control functions EAU10474 EAU85040 EAU1068B Main switch/steering lock LOCK All electrical circuits are supplied with The steering is locked and all electrical power and the vehicle lights are turned systems are off.

  • Page 21: Indicator Lights And Warning Lights

    UBAEE0E0.book Page 3 Tuesday, December 10, 2019 2:42 PM Instrument and control functions ECA20760 EAU4939G Indicator lights and warning NOTICE If the steering will not lock, try turning lights Using the hazard or turn signal lights the handlebars back to the right slight- for an extended length of time may cause the battery to discharge.
  • Page 22 If this occurs, EAU11081 have a Yamaha dealer check the on- High beam indicator light “ ” EAU11449 board diagnostic system.
  • Page 23 If the indicator light does not come on (See page 4-17.) vehicle and all 3 keys to a Yamaha initially when the key is turned to “ON”, dealer to have the standard keys if the indicator light remains on, or if the re-registered.

  • Page 24: Multi-Function Meter Unit

    UBAEE0E0.book Page 6 Tuesday, December 10, 2019 2:42 PM Instrument and control functions a traction control system display EAU73257 Multi-function meter unit a multi-function display The “QS” icon does not function. The multi-function meter unit can be switched between kilometers and miles.
  • Page 25 If a problem is detected in the fuel tank acceleration. electrical circuit, the fuel level seg- Travel at a constant speed. ments, frame, and “ ” will flash re- Select the transmission gear that peatedly. Have a Yamaha dealer check is appropriate for the vehicle the vehicle. speed.
  • Page 26 UBAEE0E0.book Page 8 Tuesday, December 10, 2019 2:42 PM Instrument and control functions Transmission gear display This display indicates which drive Multi-function display mode has been selected: “STD”, “A” or “B”. For more details on the modes and on how to select them, see pages 4-12 and 4-14.
  • Page 27 UBAEE0E0.book Page 9 Tuesday, December 10, 2019 2:42 PM Instrument and control functions The tripmeters “TRIP” show the dis- Instantaneous fuel consumption ODO → TRIP 1 → TRIP 2 → (TRIP F) → tance traveled since they were last re- km/L or L/100 km →...
  • Page 28 UBAEE0E0.book Page 10 Tuesday, December 10, 2019 2:42 PM Instrument and control functions “AVE_ _._ MPG”: The average dis- Coolant temperature tance that can be traveled on If traveling at speeds under 20 km/h 1.0 Imp.gal of fuel. (12 mi/h), “_ _._” is displayed. To switch the average fuel consump- tion display settings, push the bottom Average fuel consumption...
  • Page 29 UBAEE0E0.book Page 11 Tuesday, December 10, 2019 2:42 PM Instrument and control functions Air temperature Clock 6. Push the top set button to set the minutes. 7. Push the bottom set button to confirm settings and start the clock. When setting the hours and minutes, push the top set button briefly to in- crease the increment value one by one, or push and hold the button to increase...

  • Page 30: D-Mode (Drive Mode)

    UBAEE0E0.book Page 12 Tuesday, December 10, 2019 2:42 PM Instrument and control functions To adjust the brightness This mode allows the rider to enjoy EAU47636 D-mode (drive mode) 1. Turn the main switch off. smooth and sporty drivability from the D-mode is an electronically controlled 2.

  • Page 31: Handlebar Switches

    UBAEE0E0.book Page 13 Tuesday, December 10, 2019 2:42 PM Instrument and control functions Right EAU1234M EAU12461 Handlebar switches Turn signal switch “ ” To signal a right-hand turn, push this Left switch to “ ”. To signal a left-hand turn, push this switch to “ ”.

  • Page 32: Clutch Lever

    UBAEE0E0.book Page 14 Tuesday, December 10, 2019 2:42 PM Instrument and control functions See page 4-17 for an explanation ECA10062 EAU12822 Clutch lever NOTICE of the traction control system and the TCS settings. Do not use the hazard lights for an extended length of time with the en- gine not running, otherwise the bat- EAU54212...

  • Page 33: Shift Pedal

    UBAEE0E0.book Page 15 Tuesday, December 10, 2019 2:42 PM Instrument and control functions EAU12876 EAU26826 EAU12944 Shift pedal Brake lever Brake pedal The brake lever is located on the right side of the handlebar. To apply the front brake, pull the lever toward the throttle grip.

  • Page 34: Abs

    UBAEE0E0.book Page 16 Tuesday, December 10, 2019 2:42 PM Instrument and control functions EAU63040 The ABS performs a self-diagno- The Yamaha ABS (Anti-lock Brake sis test each time the vehicle first System) features a dual electronic con- starts off after the key is turned to trol system, which acts on the front and “ON”...

  • Page 35: Traction Control System

    UBAEE0E0.book Page 17 Tuesday, December 10, 2019 2:42 PM Instrument and control functions The “ ” indicator light flashes when EAU74351 Traction control system traction control has engaged. You may Use the traction control switch The traction control system (TCS) notice slight changes in engine and ex- (page 4-13) to change TCS set- helps maintain traction when acceler-...

  • Page 36: Fuel Tank Cap

    Turn the er check the vehicle as soon as possi- key 1/4 turn counterclockwise, remove ble. it, and then close the lock cover. 4. Have a Yamaha dealer check the vehicle and turn off the “ ” warning light. 4-18...

  • Page 37: Fuel

    UBAEE0E0.book Page 19 Tuesday, December 10, 2019 2:42 PM Instrument and control functions ately. If gasoline spills on your skin, EAU13222 Fuel wash with soap and water. If gaso- Make sure there is sufficient gasoline in line spills on your clothing, change the tank.

  • Page 38: Fuel Tank Breather Hose And Overflow Hose

    Before operating the vehicle: the same identifier when fueling. check each hose connection. check each hose for damage. Re- Your Yamaha engine has been de- place if necessary. signed to use premium unleaded gas- confirm the end of each hose is oline with a research octane number of not blocked.

  • Page 39: Catalytic Converter

    UBAEE0E0.book Page 21 Tuesday, December 10, 2019 2:42 PM Instrument and control functions EAU13434 ECA10702 EAU57991 Catalytic converter Seat NOTICE This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. To remove the seat of leaded gasoline will cause unre- EWA10863 1.

  • Page 40: Storage Compartment

    UBAEE0E0.book Page 22 Tuesday, December 10, 2019 2:42 PM Instrument and control functions EAU58200 EAU62452 Storage compartment Adjusting the front fork EWA14671 WARNING Always adjust the spring preload on both fork legs equally, otherwise poor handling and loss of stability may result.
  • Page 41 UBAEE0E0.book Page 23 Tuesday, December 10, 2019 2:42 PM Instrument and control functions Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): Distance A = 19.0 mm (0.75 in) 12 click(s) in direction (b) Standard: Standard: Distance A = 16.0 mm (0.63 in) 7 click(s) in direction (b) Maximum (hard): Maximum (hard):...

  • Page 42: Adjusting The Shock Absorber Assembly

    UBAEE0E0.book Page 24 Tuesday, December 10, 2019 2:42 PM Instrument and control functions Rebound damping force EAU57943 Adjusting the shock absorber 3 2 1 To increase the rebound damping 7 6 5 4 assembly force and thereby harden the rebound This shock absorber assembly is damping, turn the adjusting screw in equipped with a spring preload adjust-...

  • Page 43: Luggage Strap Holders

    Although a damping force adjust- sembly yourself. Take the shock er may turn beyond the stated absorber assembly to a Yamaha minimum settings, such adjust- dealer for any service. ments are ineffective and may damage the suspension.

  • Page 44: Auxiliary Dc Connector

    EAU70641 EAU15306 Auxiliary DC connector Sidestand Yamaha dealer repair it if it does not This vehicle is equipped with an auxil- The sidestand is located on the left function properly. iary DC connector. Consult your side of the frame.

  • Page 45: Ignition Circuit Cut-Off System

    UBAEE0E0.book Page 27 Tuesday, December 10, 2019 2:42 PM Instrument and control functions EAU44895 Ignition circuit cut-off system This system prevents in-gear engine starts unless the clutch lever is pulled and the sidestand is up. Also, it will stop the running engine should the sidestand be lowered while the trans- mission is in gear.
  • Page 46 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 47: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-13 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 48 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-15, 7-25 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-24 •...
  • Page 49 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-26 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 50: Operation And Important Riding Points

    This sensor understand, ask your Yamaha dealer. The transmission is in the neutral stops the engine in case of a vehi- EWA10272 position.

  • Page 51: Shifting

    The neutral indi- The gear positions are shown in the il- cator light should come on. If not, lustration. ask a Yamaha dealer to check the electrical circuit. To shift the transmission into the neu- 3. Start the engine by sliding the...

  • Page 52: Tips For Reducing Fuel Consumption

    UBAEE0E0.book Page 3 Tuesday, December 10, 2019 2:42 PM Operation and important riding points ECA10261 EAU16811 EAU16842 Tips for reducing fuel con- Engine break-in NOTICE sumption There is never a more important period Even with the transmission in in the life of your engine than the period Fuel consumption depends largely on the neutral position, do not between 0 and 1600 km (1000 mi).

  • Page 53: Parking

    Yamaha dealer check the vehi- touch them and be burned. cle. Do not park on a slope or on soft...

  • Page 54: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 55: Tool Kit

    However, a torque wrench and other tools are necessary to perform certain maintenance work correctly. If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you.

  • Page 56: Periodic Maintenance Charts

    EAU71033 Periodic maintenance charts Items marked with an asterisk should be performed by your Yamaha dealer because these items require special tools, data, and technical skills. From 31000 km (20000 mi), repeat the maintenance intervals starting from 7000 km (4000 mi) or 6 months.
  • Page 57 UBAEE0E0.book Page 4 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment INITIAL ODOMETER READING 1000 km 7000 km 13000 km 19000 km 25000 km ANNUAL ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) CHECK 1 month 6 months 12 months...

  • Page 58: General Maintenance And Lubrication Chart

    • Perform dynamic inspection us- Diagnostic system √ √ √ √ √ √ ing Yamaha diagnostic tool. check • Check the error codes. 2 * Air filter element • Replace. Every 19000 km (12000 mi) • Check operation. √ √...
  • Page 59 UBAEE0E0.book Page 6 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment INITIAL ODOMETER READING 1000 km 7000 km 13000 km 19000 km 25000 km ANNUAL ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) CHECK 1 month 6 months 12 months...
  • Page 60 UBAEE0E0.book Page 7 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment INITIAL ODOMETER READING 1000 km 7000 km 13000 km 19000 km 25000 km ANNUAL ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) CHECK 1 month 6 months 12 months...
  • Page 61 UBAEE0E0.book Page 8 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment INITIAL ODOMETER READING 1000 km 7000 km 13000 km 19000 km 25000 km ANNUAL ITEM ROUTINE (600 mi) (4000 mi) (8000 mi) (12000 mi) (16000 mi) CHECK 1 month 6 months 12 months...

  • Page 62: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 63: Canister

    UBAEE0E0.book Page 10 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment To check the engine oil level EAU36112 EAU1990F Canister Engine oil 1. After warming up the engine, wait The engine oil level should be checked a few minutes for the oil level to regularly.
  • Page 64 An oil filter wrench is available at a oil filler cap and add oil. Yamaha dealer. 5. Check the engine oil filler cap O- 5. Apply a thin coat of clean engine ring. Replace if damaged.

  • Page 65: Why Yamalube

    9. After checking the engine oil filler EAU85450 Why Yamalube cap O-ring, install the filler cap. YAMALUBE oil is a Genuine YAMAHA Part born of the engineers’ passion Wipe off any spilled oil before starting and belief that engine oil is an impor- the engine.

  • Page 66: Coolant

    2. Maximum level mark soft tap water instead. Do not 3. Minimum level mark If genuine Yamaha coolant is not avail- use hard water or salt water 3. If the coolant is at or below the able, use an ethylene glycol antifreeze since it is harmful to the engine.

  • Page 67: Air Filter Element

    The coolant must be changed at the in- maintenance and lubrication chart. necessary, have it corrected by a tervals specified in the periodic main- Have a Yamaha dealer replace the air Yamaha dealer. tenance and lubrication chart. Have a filter element.

  • Page 68: Checking The Throttle Grip Free Play

    3.0–5.0 mm (0.12–0.20 in) proper tire pressure may cause se- Periodically check the throttle grip free vere injury or death from loss of play and, if necessary, have a Yamaha control. dealer adjust it. The tire air pressure must be checked and adjusted on cold tires (i.e., when the temperature...
  • Page 69 “broken combined weight of the rider, pas- wall is cracked, have a Yamaha dealer in” for it to develop its optimal senger, cargo, and any accessories. replace the tire immediately.
  • Page 70 1. Tire air valve ed below have been approved for this atively poor grip on certain road 2. Tire air valve core model by Yamaha. surfaces until they have been 3. Tire air valve cap with seal “broken in”. Therefore, it is ad-...

  • Page 71: Cast Wheels

    Measure the clutch lever free play as clutch does not operate correctly, have note the following points regarding the shown. a Yamaha dealer check the internal specified wheels. clutch mechanism. wheel rims should...

  • Page 72: Checking The Brake Lever Free Play

    Yamaha dealer. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 73: Checking The Front And Rear Brake Pads

    EAU22393 EAU40262 Checking the front and rear Checking the brake fluid level Yamaha dealer replace the brake pads brake pads Before riding, check that the brake fluid as a set. is above the minimum level mark.
  • Page 74 UBAEE0E0.book Page 21 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment Rear brake Use only the specified brake flu- fluid level goes down suddenly, have a Yamaha dealer check the cause before id; otherwise, the rubber seals further riding. may deteriorate, causing leak- age.

  • Page 75: Changing The Brake Fluid

    Drive chain slack: Changing the brake fluid Drive chain slack 5.0–15.0 mm (0.20–0.59 in) Have a Yamaha dealer change the The drive chain slack should be brake fluid every 2 years. In addition, checked before each ride and adjusted 4. If the drive chain slack is incorrect, have the seals of the master cylinders if necessary.
  • Page 76 UBAEE0E0.book Page 23 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment 1. Axle nut 1. Drive chain slack adjusting bolt 1. Notch 2. Locknut 2. Alignment marks 3. Drive chain puller 2. To tighten the drive chain, turn the Using the alignment marks and notch 3.

  • Page 77: Cleaning And Lubricating The Drive Chain

    If a cable is wet areas. Service the drive chain as damaged or does not move smoothly, follows. have a Yamaha dealer check or re- place it. WARNING! Damage to the ECA10584 NOTICE outer housing of cables may result...

  • Page 78: Checking And Lubricating The Throttle Grip And Cable

    In pedals should be checked before each addition, the cable should be lubricat- ride, and the pedal pivots should be lu- ed by a Yamaha dealer at the intervals bricated if necessary. specified in the periodic maintenance Brake pedal chart.

  • Page 79: Checking And Lubricating The Brake And Clutch Levers

    EWA10732 Clutch lever WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.

  • Page 80: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- face and hold it in an upright posi- fork does not operate smoothly, ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, have a Yamaha dealer check or re- specified in the periodic maintenance securely support the vehicle so pair it.

  • Page 81: Checking The Steering

    If any free This model is equipped with a VRLA smoothly, have a Yamaha dealer play can be felt, have a Yamaha (Valve Regulated Lead Acid) battery. check the wheel bearings. dealer check or repair the steer- There is no need to check the electro- ing.
  • Page 82 To charge the battery 3. Fully charge the battery before in- stallation. NOTICE: When install- Have a Yamaha dealer charge the bat- tery as soon as possible if it seems to ing the battery, be sure to turn have discharged. Keep in mind that the...

  • Page 83: Replacing The Fuses

    UBAEE0E0.book Page 30 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment EAU73340 Replacing the fuses Fuse box 1 is located behind the right side panel. To access fuse box 1, remove and in- stall the right side panel and rubber cover as follows.
  • Page 84 UBAEE0E0.book Page 31 Tuesday, December 10, 2019 2:42 PM Periodic maintenance and adjustment Specified fuses: Main fuse: To access the fuel injection system 50.0 A fuse, remove the starter relay cover by Headlight fuse: pulling it upward. 15.0 A Signaling system fuse: 7.5 A Ignition fuse: 15.0 A...

  • Page 85: Replacing The Headlight Bulb

    Periodic maintenance and adjustment 4. If the fuse immediately blows EAU34386 Replacing the headlight bulb again, have a Yamaha dealer This model is equipped with a halogen check the electrical system. bulb headlight. If the headlight bulb burns out, replace it as follows.

  • Page 86: Replacing The Auxiliary Light Bulb

    6. Install the headlight unit by install- page 7-32.) ing the bolts. 2. Remove the auxiliary light bulb 7. Have a Yamaha dealer adjust the socket (together with the bulb) by headlight beam if necessary. pulling it out. 1. Headlight bulb cover 2.

  • Page 87: Brake/Tail Light

    1. Remove the turn signal light lens If the brake/tail light does not come on, by removing the screw. have a Yamaha dealer check it. 1. Auxiliary light bulb 4. Insert a new bulb into the socket. 5. Install the socket (together with the bulb) by pushing it in.

  • Page 88: License Plate Light

    License plate light Supporting the motorcycle If the license plate light does not come on, have a Yamaha dealer check the electrical circuit or replace the bulb. 1. Turn signal light bulb 3. Insert a new bulb into the socket, 1.

  • Page 89: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 90: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 91 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 92: Motorcycle Care And Storage

    Be performance and extend the useful life high-pressure washers sure to consult a Yamaha dealer for of many components. Washing, clean- steam-jet cleaners. Excessive advice on what products to use be- ing, and polishing will also give you a water pressure may cause wa- fore cleaning the vehicle.
  • Page 93 UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Motorcycle care and storage chemicals such as, solvents, Washing plastic may scratch the wind- 1. Rinse off any degreaser and spray gasoline, rust removers, brake shield, so be sure to test all down the vehicle with a garden fluid, or antifreeze, etc.

  • Page 94: Storage

    UBAEE0E0.book Page 3 Tuesday, December 10, 2019 2:42 PM Motorcycle care and storage will become slippery, which Do not use abrasive polishing EAU83472 Storage could cause loss of control. compounds as they will wear Always store the vehicle in a cool, dry Thoroughly clean the surfaces away the paint.
  • Page 95 UBAEE0E0.book Page 4 Tuesday, December 10, 2019 2:42 PM Motorcycle care and storage 1. Make all necessary repairs and b. Pour a teaspoonful of engine wheels a little once a month in or- perform any outstanding mainte- oil into the spark plug bore. der to prevent the tires from be- nance.

  • Page 96: Specifications

    UBAEE0E0.book Page 1 Tuesday, December 10, 2019 2:42 PM Specifications Dimensions: Fuel injection: Starting system: Electric starter Overall length: Throttle body: Engine oil: 2075 mm (81.7 in) ID mark: Overall width: Recommended brand: B901 00 815 mm (32.1 in) Drivetrain: Overall height: Gear ratio: 1140 mm (44.9 in)
  • Page 97 UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Specifications Loading: Front turn signal light: 10.0 W Maximum load: Rear turn signal light: 170 kg (375 lb) 10.0 W (Total weight of rider, passenger, cargo Auxiliary light: and accessories) 5.0 W Front brake: License plate light: Type:...

  • Page 98: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number The vehicle identification number is The engine serial number is stamped stamped into the steering head pipe.

  • Page 99: Diagnostic Connector

    The diagnostic connector is located as ed data shown. This data will be uploaded only when a special Yamaha diagnostic tool is at- tached to the vehicle, such as when maintenance checks or service proce- dures are performed. Vehicle data uploaded will be handled appropriately according to the follow- ing Privacy Policy.
  • Page 100 UBAEE0E0.book Page 3 Tuesday, December 10, 2019 2:42 PM Consumer information Yamaha will not disclose this data to a third party except in the following cas- es. In addition, Yamaha may provide vehicle data to a contractor in order to outsource services related to the han- dling of vehicle data.
  • Page 101 UBAEE0E0.book Page 1 Tuesday, December 10, 2019 2:42 PM Index Drive chain slack ........7-22 ABS............4-16 Main switch/steering lock....... 4-2 ABS warning light ........4-4 Engine break-in ........6-3 Maintenance and lubrication, periodic ... 7-5 Air filter element........7-14 Engine idling speed, checking .....
  • Page 102 UBAEE0E0.book Page 2 Tuesday, December 10, 2019 2:42 PM Index Throttle grip and cable, checking and lubricating ....7-25 Throttle grip free play, checking ...7-15 Tires ............7-15 Tool kit ............7-2 Traction control system ......4-17 Traction control system indicator light ...4-5 Traction control system switch.....4-13 Troubleshooting ........7-36 Troubleshooting charts......7-37 Turn signal indicator lights......4-3...
  • Page 103 UBAEE0E0.book Page 3 Tuesday, December 10, 2019 2:42 PM...
  • Page 104 Original instructions PRINTED ON RECYCLED PAPER PRINTED IN THAILAND 2019.12-0.1 x 1 (E) DIC183...
