OWNER'S MANUAL
MOTORCYCLE
XSR900N/XSR900NC
LIT-11626-35-67
Read this manual carefully
before operating this vehicle.
BEA-28199-10
Location of important labels
Safety information
Description
Special features
Instrument and control functions
For your safety – pre-operation checks
Operation and important riding points
Periodic maintenance and adjustment
Motorcycle care and storage
Specifications
Consumer information
1
2
3
4
5
6
7
8
9
10
11
12
Index
