OWNER'S MANUAL
MOTORCYCLE
MTM890N (XSR900)
Read this manual carefully
before operating this vehicle.
BEA-28199-20
Location of important labels
Safety information
Description
Special features
Instrument and control functions
For your safety – pre-operation checks
Operation and important riding points
Periodic maintenance and adjustment
Motorcycle care and storage
Specifications
Consumer information
1
2
3
4
5
6
7
8
9
10
11
12
Index

Advertisement

Table of Contents
loading

Related Manuals for Yamaha XSR900

Summary of Contents for Yamaha XSR900

  • Page 1 Location of important labels OWNER’S MANUAL Safety information Description Special features Instrument and control functions For your safety – pre-operation checks Operation and important riding points Periodic maintenance and adjustment Motorcycle care and storage MOTORCYCLE Specifications MTM890N (XSR900) Consumer information Index BEA-28199-20...
  • Page 2 EAU81565 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the MTM890N, you are benefiting from Yamaha’s vast experience and newest technology regarding the de- sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10202 MTM890N OWNER’S MANUAL ©2022 by Yamaha Motor Co., Ltd. 1st edition, December 2021 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Location of important labels... 1-1 Fuel tank overflow hose ....5-24 General maintenance and Catalytic converter ....... 5-24 lubrication chart ......8-4 Safety information ......2-1 Seat..........5-25 Side cover........8-8 Rider footrest position ....5-25 Checking the spark plugs .... 8-11 Description ........
  • Page 7 Table of contents Checking and lubricating the Index ..........12-1 brake and shift pedals....8-27 Checking and lubricating the brake and clutch levers ..... 8-28 Checking and lubricating the sidestand........8-29 Lubricating the swingarm pivots ... 8-29 Checking the front fork ....8-29 Checking the steering....

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. 2, 3...
  • Page 9 HELMET, eye protection, and protective clothing. 1TP-2118K-A2 4AA-22259-40 STATIONARY NOISE TEST INFORMATION Use PREMIUM unleaded gasoline with min. 95 octane (RON). TESTED 95 dB(A) 5000 r/min 2S3-2817K-11 SILENCING SYSTEM : YAMAHA IDENTIFICATION : B7N BEA-2118G-10 28R-00 6270 39R-01 10013 100kPa=1bar kPa,psi kPa,psi 41R-04...

  • Page 10: Safety Information

    Safety information EAU1028C Take a training course. Beginners • Use extra caution when you are should receive training from a cer- approaching passing tified instructor. Contact an autho- through intersections, since in- Be a Responsible Owner rized motorcycle dealer to find out tersections are the most likely As the vehicle’s owner, you are respon- about the training courses nearest...
  • Page 11 Safety information tice riding your motorcycle with both hands and keep both control levers, footrests, or wheels where there is no traffic until you feet on the passenger footrests. and cause injury or an accident.  have become thoroughly famil- Never carry a passenger unless Always wear protective clothing iar with the motorcycle and all of...
  • Page 12 Yamaha accessories, which are avail- to minimize imbalance or instabili- of the motorcycle is changed. To avoid able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved ...
  • Page 13 Yamaha, even if sold and limit suspension travel, steering not recommended.  installed by a Yamaha dealer.
  • Page 14 Safety information  Check that the fuel cock (if equipped) is in the off position and that there are no fuel leaks.  Shift the transmission into gear (for models with a manual transmis- sion).  Secure motorcycle with tie-downs or suitable straps that are attached to solid parts of the motorcycle, such as the frame or upper front fork triple clamp (and...

  • Page 15: Description

    Description EAU10411 Left view 1, 2 1. Spring preload adjuster (page 5-26) 2. Compression damping force adjuster (page 5-26) 3. Battery (page 8-31) 4. Seat (page 5-25) 5. Rebound damping force adjuster (page 5-28) 6. Spring preload adjuster (page 5-28) 7.

  • Page 16: Right View

    Description EAU10421 Right view 3, 4 1. Fuses (page 8-33) 9. Rear brake fluid reservoir (page 8-22) 2. Fuel tank cap (page 5-22) 3. Spring preload adjuster (page 5-26) 4. Rebound damping force adjuster (page 5-26) 5. Coolant reservoir (page 8-15) 6.

  • Page 17: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 5-19) 2. Left handlebar switches (page 5-3) 3. Main switch/steering lock (page 5-2) 4. Instrument panel (page 5-5, 5-8) 5. Front brake fluid reservoir (page 8-22) 6. Right handlebar switches (page 5-3) 7.

  • Page 18: Special Features

    Special features EAU91733 switch “ ” located on the left han- Cruise control system dlebar. The cruise control system This model is equipped with a cruise indicator light “ ” will come on. control system designed to maintain a 2. Press the “SET–” side of the cruise set cruising speed.
  • Page 19 Special features  new cruising speed by pressing the Shift gears set cruising speed. You will not be able “SET–” side of the setting switch. If you Press the power switch to turn off the to use the resume function until a new do not set a new cruising speed, when cruise control system.

  • Page 20: D-Mode

    Special features 4 seconds, and then go off. the set cruising speed. If this oc- EAU91323 “D-MODE” When not traveling with a set cruising curs, the setting switch cannot be “D-MODE” is an electronically con- speed, if the start/engine stop switch is used to adjust the set cruising trolled engine performance system.

  • Page 21: Tcs-Mode

    Special features MODE switches, see page 5-4 for EAU91434 This traction control system automati- “TCS-MODE” more information. cally adjusts according to the vehicle’s This model is equipped with the traction lean angle. To maximize acceleration, control system, the slide control system when the vehicle is upright a lesser (SCS), and the lift control system (LIF).
  • Page 22 Special features more information starts or out-of-corner exits. When “TCS-MODE”. front-wheel lift is detected, engine pow- Set “TCS-MODE” to “OFF” to help free  When “TCS-MODE” has been set er is regulated to slow front-wheel lift the rear wheel if the motorcycle gets to “OFF”, the traction control sys- while still providing good acceleration.

  • Page 23: Quick Shifter

    Special features EAU91341 Downshifting conditions EAU91350 Quick shifter  Vehicle speed of at least 20 km/h The quick shifter allows for clutch le- The brake control system regulates hy- (12 mi/h) ver-less, electronically-assisted shift- draulic brake pressure for the front and ...
  • Page 24 Special features ing and braking techniques. The brake control system cannot pre- vent all loss of traction due to over-braking from excessive speed, or lateral wheel slip when braking on slippery surfaces.

  • Page 25: Instrument And Control Functions

    Do not expose to high tempera- any remaining standard keys to a tures.  Yamaha dealer to have them re-regis- Do not place near magnets.  tered. Do not place near items that transmit electrical signals.

  • Page 26: Main Switch/Steering Lock

    Instrument and control functions EAU10474 on. The engine can be started. The key To lock the steering Main switch/steering lock cannot be removed.  The headlight(s) will turn on when the engine is started.  To prevent battery drain, do not leave the key in the “ON”...

  • Page 27: Handlebar Switches

    Instrument and control functions To unlock the steering EAU66057 Right Handlebar switches Left 1 1 1 1. Stop/Run/Start switch “ ” 1. Push. 2. Wheel switch “ ” 2. Turn. 1. “MODE” switch Push the key in and turn it to “OFF”. EAU91630 2.
  • Page 28 Instrument and control functions position. To cancel the turn signal off only when the key is in the “ON” po- toggle left to right between “D-MODE” lights, push the switch in after it has re- sition. You can turn the main switch to and “TCS-MODE”.

  • Page 29: Indicator Lights And Warning Lights

    Instrument and control functions  on “TCS-MODE”. For items that can be reset, leave EAU4939X Indicator lights and warning  See page 4-3 for more information the cursor over the item, press and lights on “D-MODE”. hold the switch to reset. ...
  • Page 30 If this oc- 2.7 L (0.71 US gal, 0.59 Imp.gal). When gency braking. curs, have a Yamaha dealer check the this occurs, refuel as soon as possible.  Have a Yamaha dealer check the on-board diagnostic system.
  • Page 31 30 seconds have passed, the indicator do not start the engine, take the can initialize. light will flash steadily to indicate the im- vehicle and all 3 keys to a Yamaha mobilizer system is enabled. After 24 dealer to have the standard keys EAU88362 hours have passed, the indicator light re-registered.

  • Page 32: Display

    When the vehicle is turned on, this light 6. Settings MENU icon “ ” should come on for a few seconds and 7. Grip warmer indicator (option) then go off. Otherwise, have a Yamaha 8. Brake control icon “BC” dealer check the vehicle. 9. Clock 10.MODE display 11.Lap timer...
  • Page 33 Instrument and control functions  speed, as measured by the rotational F.AVE: average fuel economy  velocity of the crankshaft, in revolutions F.CRNT: instantaneous fuel econ- This model uses a thin-film-transistor per minute (r/min). liquid-crystal display (TFT LCD) for  A.TEMP: air temperature ECA10032 good contrast and readability in various...
  • Page 34 Instrument and control functions Odometer: TRIP1 and TRIP2 show the distance page 5-17. traveled since they were last set to ze-  If traveling at speeds under 10 km/h, “--.-” will be displayed.  The odometer shows the total distance TRIP1 and TRIP2 will reset to 0 and be- The instantaneous fuel economy traveled by the vehicle.
  • Page 35 Instrument and control functions Coolant temperature: Fuel consumption trip meter: Transmission gear display This shows which gear the transmis- sion is in. This model has 6 gears and a neutral position. The neutral position is indicated by the neutral indicator light The coolant temperature is displayed Displays how much fuel has been con- “...
  • Page 36 Instrument and control functions Clock the engine is running. There are 10 The clock uses a 12-hour time system. temperature levels. When activated,  When the engine trouble warning See page 5-18 to set the clock. the indicator will display the tempera- light “...
  • Page 37 Instrument and control functions ing and holding the wheel switch inward start the lap timer.  while the grip warmer indicator is high- The headlight will flash when the lighted by the cursor. dimmer/pass switch is pressed.  In this mode, the temperature levels Whenever the lap timer is paused, can be instantly adjusted by rotating the it can be resumed using the dim-...

  • Page 38: Settings Menu

    ABS may not function properly. EAU9145B Settings MENU Use extra care when braking and have If a malfunction is detected, the oil pres- a Yamaha dealer check the vehicle im- sure warning icon will flash repeatedly. MENU mediately. ECA26410...
  • Page 39 Instrument and control functions each menu via the triangle mark (if “Manual TCS Setting” Set fuel consumption and “Unit” measurement units displayed). Exiting the settings “Brightness” Adjust screen brightness menu by pressing and holding the Manual TCS Setting “Clock” Adjust the clock wheel switch may not save set- Return all settings to “All Reset”...
  • Page 40 Instrument and control functions “Vehicle Setting” BC2 to have the brake control system further regulate brake pressure while  The traction control system can cornering to suppress lateral wheel slip. Vehicle Setting only be turned on or off via the main screen using the MODE BC Setting switches.
  • Page 41 Instrument and control functions OFF turns the respective upshift or “IND Start” - the r/min at which the in- other items of your choice (use INTER- downshift function off, and the clutch le- dicator starts flashing can be chosen. VAL 1 and INTERVAL 2). ver must then be used when shifting in Once selected, rotate the wheel To reset a maintenance trip meter, se-...
  • Page 42 Instrument and control functions tween Celsius and Fahrenheit. “Clock” “All Reset” “Brightness” Clock All Reset Brightness km/h km/h This module allows you to set the clock. This module resets all settings items km/h When the clock module is selected, the (except the odometer and clock) to their This module allows you to adjust the hours will be highlighted.

  • Page 43: Clutch Lever

    Instrument and control functions EAU12823 EAU83692 shifter is programmed to ignore unclear Clutch lever Shift pedal input signals. Therefore, be sure to shift using quick and sufficiently forceful in- 1 1 1 puts. 1 1 1 1 1. Clutch lever 1.

  • Page 44: Brake Lever

    Instrument and control functions EAU93080 EAU12944 EAU91461 Brake lever Brake pedal Brake control system (BC) The brake control system regulates hy- draulic brake pressure for the front and 1 1 1 rear wheels independently when the brakes are applied and wheel lock is detected.
  • Page 45 Instrument and control functions EWA16051 test when the vehicle is started and WARNING reaches a speed of 5 km/h (3 mi/h). During this test, a clicking noise may be Always keep a sufficient distance audible from the hydraulic control unit, from the vehicle ahead to match the and a vibration may be felt at the brake riding speed even with ABS.

  • Page 46: Fuel Tank Cap

    Instrument and control functions EAU13077 the key cannot be removed if the cap is EAU13222 Fuel tank cap Fuel not properly closed and locked. Make sure there is sufficient gasoline in EWA11092 the tank. WARNING EWA10882 Make sure that the fuel tank cap is WARNING properly closed after filling fuel.
  • Page 47 Use only unleaded gasoline. The use EAU86081 of leaded gasoline will cause severe damage to internal engine parts, Your Yamaha engine was designed to use unleaded gasoline with a research such as the valves and piston rings, 1. Fuel tank filler tube as well as to the exhaust system.

  • Page 48: Fuel Tank Overflow Hose

    Instrument and control functions EAU86160 EAU13435 Fuel tank overflow hose Catalytic converter See page 8-12 for canister information. The exhaust system contains catalytic converter(s) to reduce harmful exhaust emissions. EWA10863 1 1 1 WARNING The exhaust system is hot after op- eration.

  • Page 49: Seat

    1. Open the seat lock cover, insert the footrests are in the low position. the key into the seat lock, and then Have a Yamaha dealer adjust the posi- turn the key counterclockwise. tions of the rider footrests. 2 2 2 1.

  • Page 50: Handlebar Position

    The handlebar can be adjusted to one EWA14671 WARNING of two positions to suit the rider’s pref- erence. Have a Yamaha dealer adjust Always adjust the spring preload on the position of the handlebar. both fork legs equally, otherwise poor handling and loss of stability may result.
  • Page 51 Instrument and control functions suspension. Spring preload setting: Minimum (soft): 1 1 1 Distance A = 19.0 mm (0.75 in) Compression damping force Standard: The compression damping force is ad- Distance A = 14.0 mm (0.55 in) justed on the left fork leg only. Maximum (hard): Distance A = 4.0 mm (0.16 in) Turn the adjusting screw in direction (a)

  • Page 52: Adjusting The Shock Absorber

    Instrument and control functions effective and may damage the EAU94912 Adjusting the shock absorber suspension. 1 1 1 assembly This shock absorber assembly is equipped with a spring preload adjust- ing ring and a rebound damping force adjusting screw. ECA10102 NOTICE To avoid damaging the mechanism, 1.
  • Page 53 Instrument and control functions Rebound damping force 1. Remove the cap. 7 6 5 4 3 2 2 3 3 1 1 1 1 (a) 1 1 1 1. Spring preload adjusting ring 1. Rebound damping force adjusting screw 2. Extension bar Rebound damping setting: 3.

  • Page 54: Auxiliary Dc Connectors

    DC connector and a grip warmer DC of the frame. Raise the sidestand or the shock absorber assembly. connector. Consult your Yamaha deal- lower it with your foot while holding the  Do not tamper with or attempt to er before installing any accessories.

  • Page 55: Ignition Circuit Cut-Off System

    Instrument and control functions Yamaha dealer repair it if it does not EAU57952 Ignition circuit cut-off system function properly. This system prevents in-gear engine starts unless the clutch lever is pulled and the sidestand is up. Also, it will stop...
  • Page 56 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 57: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 8-15 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 58 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 5-30 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 59: Operation And Important Riding Points

    The vehicle can now be operated nor- there is a control or function you do not between 0 and 1600 km (1000 mi). For mally. understand, ask your Yamaha dealer. this reason, you should read the follow- ECA10311 NOTICE EWA10272 ing material carefully.

  • Page 60: Starting The Engine

    1 1 1 Yamaha dealer check the vehicle.  the transmission is in gear, the sid- estand is up, and the clutch lever is 3. Shift the transmission into the neu- pulled.

  • Page 61: Shifting

    Operation and important riding points EAU68221 EAU91542 ECA22523 Shifting NOTICE  When shifting, press the shift pedal firmly until you feel the This model is equipped with:  gear shift is complete. inertial measurement unit  Even with the transmission in (IMU).

  • Page 62: Tips For Reducing Fuel Consumption

    Operation and important riding points lever slowly. and then the clutch lever can be EAU16811 Tips for reducing fuel 4. After starting out, close the throttle, released. consumption and at the same time, quickly pull EWA17380 WARNING the clutch lever in. Fuel consumption depends largely on ...

  • Page 63: Parking

    Operation and important riding points EAU17214 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10312 WARNING  Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 64: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-2 for more in- graphical location, and individual use, dealers are trained and equipped to...

  • Page 65: Tool Kit

    However, a torque wrench and other tools are necessary to perform certain maintenance work correctly. If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you.

  • Page 66: Periodic Maintenance Charts

    EAU71033 Periodic maintenance charts  Items marked with an asterisk should be performed by your Yamaha dealer because these items require special tools, data, and technical skills.  From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).

  • Page 67: General Maintenance And Lubrication Chart

    (24000 mi) • Perform dynamic inspection using Diagnostic system       Yamaha diagnostic tool. check • Check the error codes. 2 * Air filter element • Replace. Every 40000 km (24000 mi) • Check operation.  ...
  • Page 68 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check chain slack, alignment and condition. Every 1000 km (600 mi) and after washing the motorcycle, riding in the rain or Drive chain •...
  • Page 69 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Rear suspension relay arm and   ...
  • Page 70 Periodic maintenance and adjustment EAU72800  Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...

  • Page 71: Side Cover

    Periodic maintenance and adjustment EAU94891 1 1 1 Side cover The covers shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a cover needs to 1 1 1 be removed and installed.
  • Page 72 Periodic maintenance and adjustment To install the cover 1. Install the cover B. Remove the quick fastener C while Turn the ring clockwise while pushing it, turning the ring counterclockwise. and then install the quick fastener C. 1 1 1 1.
  • Page 73 Periodic maintenance and adjustment pushing the center pin flush with the fastener head. 1 1 1 1. Quick fastener (before installation) 1. Quick fastener C 2. Quick fastener (after installation) 2. Quick fastener B 3. Install the cover A. 5. Install the quick fastener A. 1 1 1 1 1 1 1.

  • Page 74: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. If a spark plug shows signs of electrode Tightening torque: Spark plug: erosion and excessive carbon or other 13 N·m (1.3 kgf·m, 9.6 lb·ft)

  • Page 75: Canister

    Periodic maintenance and adjustment EAU36113 EAU1990G To check the engine oil level Canister Engine oil 1. After warming up the engine, wait The engine oil level should be checked a few minutes for the oil level to regularly. In addition, the oil must be settle for an accurate reading.
  • Page 76 Skip steps 4–6 if the oil filter cartridge is An oil filter wrench is available at a 1. Engine oil filler cap not being replaced. Yamaha dealer. 2. O-ring 4. Remove the oil filter cartridge with 5. Apply a thin coat of clean engine 6.
  • Page 77 Periodic maintenance and adjustment 11. Stop the engine, wait a few min- Tightening torque: utes for the oil level to settle, and Oil filter cartridge: then check the oil level one last 17 N·m (1.7 kgf·m, 13 lb·ft) time. NOTICE: Do not operate 7.

  • Page 78: Why Yamalube

    3. Minimum level mark standards. Thus, Yamalube mineral, 3. If the coolant is at or below the If genuine Yamaha coolant is not avail- semisynthetic and synthetic oils have minimum level mark, remove the able, use an ethylene glycol antifreeze their own distinct characters and value.

  • Page 79: Air Filter Element

    EAU33032 Changing the coolant maintenance and lubrication chart. The coolant must be changed at the in- Have a Yamaha dealer replace the air 1 1 1 tervals specified in the periodic mainte- filter element. nance and lubrication chart. Have a Yamaha dealer change the coolant.

  • Page 80: Checking The Engine Idling Speed

    To pre- fied tires. vent this from occurring, have your Yamaha dealer check and adjust the Tire air pressure valve clearance at regular intervals. The tire air pressure should be checked and, if necessary, adjusted before each ride.
  • Page 81 “broken glass fragments in it, or if the sidewall is combined weight of the rider, passen- in” for it to develop its optimal cracked, have a Yamaha dealer re- ger, cargo, and any accessories. characteristics. place the tire immediately.
  • Page 82 2. Tire air valve core surfaces until they have been model by Yamaha. 3. Tire air valve cap with seal “broken in”. Therefore, it is ad- visable...

  • Page 83: Cast Wheels

    Measure the clutch lever free play as clutch does not operate correctly, have note the following points regarding the shown. a Yamaha dealer check the internal specified wheels. clutch mechanism.  The wheel rims should be checked for cracks, bends, warpage or oth- er damage before each ride.

  • Page 84: Checking The Brake Lever Free Play

    Yamaha dealer. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 85: Checking The Front And Rear Brake Pads

    Periodic maintenance and adjustment EAU22393 touches the brake disc, have a Yamaha EAU40262 Checking the front and rear Checking the brake fluid level dealer replace the brake pads as a set. brake pads Before riding, check that the brake fluid is above the minimum level mark.
  • Page 86 If the brake  Use only the specified brake flu- fluid level goes down suddenly, have a Yamaha dealer check the cause before id; otherwise, the rubber seals 8-23...

  • Page 87: Changing The Brake Fluid

    EAU22734 EAU22762 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid every 2 years. In addition, checked before each ride and adjusted have the seals of the master cylinders if necessary.
  • Page 88 To adjust the drive chain slack 3. Tighten the axle nut, then the lock- tion (a). To loosen the drive chain, Consult a Yamaha dealer before ad- nuts to their specified torques. turn the adjusting bolt on each side justing the drive chain slack.

  • Page 89: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment the drive chain moves smoothly. EAU23027 cants for the drive chain, as they Cleaning and lubricating the may contain substances that drive chain could damage the O-rings. [ECA11112] The drive chain must be cleaned and lubricated at the intervals specified in the periodic maintenance and lubrica- tion chart, otherwise it will quickly wear out, especially when riding in dusty or...

  • Page 90: Checking And Lubricating The Cables

    Yamaha dealer at the bricated if necessary. ed if necessary. If a cable is damaged...

  • Page 91: Checking And Lubricating The Brake And Clutch Levers

    The operation of clutch lever should be checked before each ride, and the lever pivot should be lubricated if necessary. The brake lever pivot must be lubricat- ed by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. Clutch lever...

  • Page 92: Checking And Lubricating The Sidestand

    The swingarm pivots must be lubricat- face and hold it in an upright posi- be checked before each ride, and the ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, sidestand pivot and metal-to-metal specified in the periodic maintenance...

  • Page 93: Checking The Steering

    [EWA10752] the periodic maintenance and lubrica- have a Yamaha dealer check or re- 2. Hold the lower ends of the front tion chart. If there is play in the wheel pair it. fork legs and try to move them for- hub or if the wheel does not turn ward and backward.

  • Page 94: Battery

    IES OUT OF THE REACH OF checked and, if necessary, tightened. CHILDREN. Use only the specified genuine EWA10761 YAMAHA battery. Using a different WARNING battery may cause the IMU to fail and  To remove the battery Electrolyte is poisonous and the engine to stall.
  • Page 95 1 1 1 For installation, reverse the removal procedure. To charge the battery Have a Yamaha dealer charge the bat- tery as soon as possible if it seems to have discharged. Keep in mind that the battery tends to discharge more quickly if the vehicle is equipped with optional 1.

  • Page 96: Replacing The Fuses

    Periodic maintenance and adjustment necting the positive lead. EAU91572 [ECA16304] Replacing the fuses 2. If the battery will be stored for more The fuse box is located under the seat. than two months, check it at least (See page 5-25.) once a month and fully charge it if necessary.
  • Page 97 Periodic maintenance and adjustment Specified fuses:  Main fuse: There is a spare fuse on the back 50.0 A side of the fuse box cover. Terminal fuse 1:  Use a fuse puller to remove the 2.0 A fuse. Headlight fuse: 7.5 A 1.

  • Page 98: Vehicle Lights

    If the license plate light does not come 6. Turn the main switch on and turn on, have a Yamaha dealer check the on the electrical circuit in question electrical circuit or replace the bulb.

  • Page 99: Supporting The Motorcycle

    1. Maintenance stand (example) self. However, should your motorcycle require any repair, take it to a Yamaha Since this model is not equipped with a dealer, whose skilled technicians have centerstand, use maintenance stands...

  • Page 100: Troubleshooting Chart

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 101 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 102: Motorcycle Care And Storage

    Be  high-pressure washers of many components. Washing, clean- sure to consult a Yamaha dealer for steam-jet cleaners. Excessive ing, and polishing will also give you a advice on what products to use be- water pressure may cause water chance to inspect the condition of the fore cleaning the vehicle.
  • Page 103 Motorcycle care and storage gasoline, rust removers, brake to do the job. Avoid spraying water 4. Rinse off thoroughly with clean wa- fluid, or antifreeze, etc. directly into the muffler, instrument ter. Be sure to remove all deter- panel, air inlet, or other inner areas gent residues, as they can be such as underseat storage com- harmful to plastic parts.

  • Page 104: Storage

    Motorcycle care and storage operating the vehicle. EWA20660 EAU83472 [EWA20651] Storage WARNING 5. Treat rubber, vinyl, and unpainted Always store the vehicle in a cool, dry plastic parts with a suitable care Contaminants left on the brakes or place. If necessary, protect it against product.
  • Page 105 Motorcycle care and storage perform any outstanding mainte- into the spark plug bore. the tires from becoming degraded nance. c. Install the spark plug cap onto in one spot. 2. Follow all instructions in the Care the spark plug, and then place 9.

  • Page 106: Specifications

    Specifications Dimensions: EAU84806 Starting system: Fuel injection: Electric starter Overall length: Throttle body: Engine oil: 2155 mm (84.8 in) ID mark: Overall width: Recommended brand: B7N1 Drivetrain: 860 mm (33.9 in) Overall height: Gear ratio: 1155 mm (45.5 in) 1st: Seat height: 2.571 (36/14) 810 mm (31.9 in)
  • Page 107 Specifications Loading: Auxiliary light: Maximum load: License plate light: 221 kg (487 lb) 5.0 W (Total weight of rider, passenger, cargo and accessories) Front brake: Type: Hydraulic dual disc brake Rear brake: Type: Hydraulic single disc brake Front suspension: Type: Telescopic fork Rear suspension: Type:...

  • Page 108: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts 1 1 1 from a Yamaha dealer. VEHICLE IDENTIFICATION NUM- 1. Vehicle identification number 1. Engine serial number...

  • Page 109: Diagnostic Connector

    Yamaha dealer. Yamaha will not disclose this data to a third party except in the following cas- es. In addition, Yamaha may provide vehicle data to a contractor in order to outsource services related to the han- dling of vehicle data.

  • Page 110: Motorcycle Noise Regulation (For Australia)

     Where obligated by law TAMPERING WITH NOISE CON-  For use by Yamaha in litigation TROL SYSTEM PROHIBITED:  When the data is not related to an Owners are warned that the law may individual vehicle nor owner prohibit: a.
  • Page 111 Index Display ............5-8 Display, menu screen......5-14 ABS warning light ........5-6 Labels, location........1-1 D-MODE..........4-3 Air filter element........8-16 License plate light ......... 8-35 Drive chain, cleaning and lubricating ..8-26 Auxiliary DC connectors ....... 5-30 Drive chain slack ........8-24 Auxiliary system warning light ....5-8 Main switch/steering lock ......
  • Page 112 Index Stability control indicator light ....5-7 Starting the engine........7-2 Steering, checking ........ 8-30 Stop/Run/Start switch ......5-4 Storage ........... 9-3 Supporting the motorcycle ....8-36 Swingarm pivots, lubricating ....8-29 TCS-MODE..........4-4 Throttle grip, checking and lubricating ........... 8-27 Tires ............
