6.2.5 L01 OEM Baseboard Reference
L01 reference design
The L01 OEM reference board is a reference design suitable L01 as well as W01 making it
possible to have a single PCB design that can accommodate both OEM modules.
If you require a reference board for the L04 or G01, this design is not suitable as it does
not feature a SIM slot or the double antenna connection. For the G01 or L04 please use
the Universal OEM Baseboard Reference
Features
Suits both L01 or W01 OEM Modules
U.FL connector for the L01's LoRa output.
On-board 2.4GHz antenna for WiFi and Bluetooth, with the ability to switch to a external
antenna via a U.FL connector.
WS2812B RGB LED
3.5-5.5 Input switch mode DC-DC regulator with low current draw during deep sleep
Reset button
Layout
The layout of the L01 baseboard reference is available as a PDF File.
