1.1.2 LoPy4
LoPy4
Basic connection
Exp Board 2.0
Exp Board 3.0
Pysense/Pytrack/Pyscan
USB UART Adapter
WiFi
Look for the reset button on the module (located at a corner of the board, next to the
LED).
Locate the USB connector on the expansion board.
Insert the LoPy4 module on the the expansion board with the reset button pointing
towards the USB connector. It should firmly click into place and the pins should now no
longer be visible.
Before connecting your module to an Expansion Board 3.0, you should update the
firmware on the Expansion Board 3.0. Instructions on how to do this can be found here.
Look for the reset button on the module (located at a corner of the board, next to the
LED).
26
