  6. Operator's manual and parts list

H&S HDII Operator's Manual And Parts List

Hide thumbs Also See for HDII:
Table of Contents

Advertisement

Quick Links

Download this manual
HDII OPERA
HDII OPERA T T T T T OR'S
HDII OPERA
HDII OPERA
HDII OPERA
WARNING
Revision # 2
Starting Serial #310570
H&S MANUFACTURING CO.,INC.
P.O. BOX 768 (715) 387-3414 FAX (715) 384-5463
MANU
MANU
MANU AL
MANU
MANU
P P P P P AR
AR
AR
TS LIST
TS LIST
AR TS LIST
TS LIST
AR
TS LIST
Manufactured By
MARSHFIELD, WISCONSIN 54449
AL
AL
AND
AND
AL AND
AND
AL
AND
READ AND UNDERSTAND THIS MANUAL
BEFORE OPERATING THIS EQUIPMENT.
UNSAFE OPERATION OR MAINTENANCE OF
THIS EQUIPMENT CAN RESULT IN SERIOUS
INJURY OR DEATH.
OR'S
OR'S
OR'S
OR'S
HSMFG1212

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDII and is the answer not in the manual?

Questions and answers

Related Manuals for H&S HDII

Summary of Contents for H&S HDII

  • Page 1 HDII OPERA HDII OPERA T T T T T OR’S HDII OPERA OR’S OR’S OR’S HDII OPERA HDII OPERA OR’S MANU MANU MANU AL AL AND MANU MANU P P P P P AR TS LIST TS LIST AR TS LIST...

  • Page 2: Table Of Contents

    CONTENTS Warranty & Warranty Registration Card ..........1-2 Manufacturers Statement .

  • Page 3: Warranty & Warranty Registration Card

    WARRANTY H&S WARRANTY H&S Manufacturing Co., Inc. (“H&S”) warrants this product to be free from defect in material and workmanship. Except as noted below, this warranty term is twelve (12) months from the date of delivery of the product to the original purchaser by an authorized H&S dealer.

  • Page 4: Manufacturers Statement

    MANUFACTURER’S STATEMENT Your new H&S Rake has been manufactured of the finest quality materials and components. The performance you get from your machine is largely dependent upon how well you read and understand this manual and apply this knowledge. There is a right and a wrong way to do everything. Please do not assume that you know how to operate and maintain your Rake before reading this manual carefully.

  • Page 5: Dealer Pre-Delivery Checklist

    DEALER PRE-DELIVERY CHECK LIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS After the rake has been completely set-up, check to be certain it is in correct operating order before delivering to the customer. The following is a list of points to inspect. Check off each item as you have made the proper adjustments and found the item operating satisfactorily.
  • Page 6 Intentionally Left Blank...

  • Page 7: Dealer Delivery Checklist

    DEALER DELIVERY CHECK LIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS This check list that follows is an important reminder of valuable information that should be passed on to the customer at the time this Rake is delivered. Check off each item as you explain it to the customer.
  • Page 8 Intentionally Left Blank...

  • Page 9: Be Alert Symbol

    SAFETY INFORMATION YOUR SAFETY ALERT! IS INVOLVED. THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE BEST OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR DAMAGE.

  • Page 10: Explanation Of Safety Signs

    SAFETY INFORMATION RECOGNIZE SAFETY INFORMATION This is the safety-alert symbol. When you see this symbol on your machine or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices. UNDERSTAND SIGNAL WORDS A signal word;...

  • Page 11: Safety Decals

    SAFETY IMFORMATION...

  • Page 12: Warning - Owner Must Read And Understand

    TRACTORS This operators manual uses the term “Tractor” when identifying the power source. W A R N I N G TO PREVENT SERIOUS INJURY OR DEATH BEFORE YOU ATTEMPT TO OPERATE THIS EQUIPMENT, READ AND STUDY THE FOLLOWING INFORMATION. IN ADDITION, MAKE SURE THAT EVERY INDIVIDUAL WHO OPERATES OR WORKS WITH THIS EQUIPMENT, WHETHER FAMILY MEMBER OR EMPLOYEE, IS FAMILIAR WITH THESE SAFETY PRECAUTIONS.

  • Page 13: Bolt Torque Chart

    -11-...

  • Page 14: Set-Up & Assembly

    SET-UP & ASSEMBLY NOTE: Determine right or left side of the wheel rake by viewing it from the rear. If instructions or parts lists call for hardened bolts, refer to bolt torque chart. Assemble the rake or check the rake for proper assembly and adjustment. Make sure that all bolts are tightened.

  • Page 15: Transporting

    TRANSPORTING TOWING ON HIGHWAY Follow state and local regulations when towing farm equipment on public highways. Never tow the rake on a public highway at a speed greater than 20 m.p.h. (32 kph). TRANSPORT LOCKS Rake Beam Locks Mounted on the rake beams are self-storing transport locks for rake beam arms. The picture shows the transport lock in the engaged position when the rake is being transported.

  • Page 16: Preparing For Operation

    PREPARING FOR OPERATION 1. Lubricate the rake completely (See the Lubrication Chapter in this Manual). 2. Adjust the tractor hitch (13 to 17 inches above ground) and attach rake to tractor with a hitch pin with a safety locking device. 3.
  • Page 17 PREPARING FOR OPERATION 7. Connect the hydraulic hoses for all rake functions to a double acting valve on the tractor. Check the tractor hydraulic system and determine if tractor is closed or open center system. The rake is factory set-up for closed center (To change to open center, see the instructions below). OPEN CENTER CHANGE If closed center valve is used on a open center tractor it will cause the oil to heat because oil is dumping over relief.

  • Page 18: Operation & Adjustments

    OPERATION & ADJUSTMENTS EMERGENCY SHUTDOWN Stop the tractor engine, remove ignition key, and allow all mechanisms to stop before cleaning or working on the machine. TRANSPORT LOCKS Rake Beam Locks Mounted on the rake beams are self-storing transport locks for rake beam arms. Remove the clip pin and swing the transport lock toward the rake beam.
  • Page 19 OPERATION & ADJUSTMENTS NOTE: TRACTOR HYDRAULIC LEVER MUST BE ENGAGED TO PROVIDE OIL FLOW TO RAKE. CONTROL BOX The control box allows the operator to make many adjustments from the tractor seat. It is set up in three basic areas. The left side has two switches, one (A) for sliding the left center frame in or out, the other switch (B) controls the rake wheel beam angle.
  • Page 20 OPERATION & ADJUSTMENTS RAKE BEAM Rake beams should be adjusted so they are level to slightly up in the front. They can be adjusted by using the rachet jack located near the center of the rake. This adjustment is important to keep rake wheel ground pressure even along the rake beam.

  • Page 21: Optional Equipment

    OPTIONAL EQUIPMENT BALL HITCH The ball hitch is an option that can be added at any time. It allows for smoother operation in the field, by eliminating the distance between the clevis hitch and the tractor drawbar. Simply remove the clevis hitch and replace it with the ball coupler and install a 2-5/16”...

  • Page 22: Lubrication Guide

    There are numerous grease fittings on the HDII Rake. If lubricated properly and often enough, it will prolong the life of your HDII Rake. Grease daily during normal use and before and after storage and after power washing. Use a good grade of high quality grease. Make sure that grease comes out around the shaft on sleeve type bearings.

  • Page 23: Decal Location & Identification

    OR IF HDII RAKE IS REPAINTED, REPLACE DECALS. REMEMBER: DECALS ARE FOR YOUR PROTECTION AND INFORMATION. Listed below are the decals on your HDII Rake. These decals may be ordered individually by part number or by ordering a complete set.

  • Page 24: Trouble Shooting

    TROUBLE SHOOTING WARNING: MAKE SURE THAT THE TRACTOR IS SHUT OFF AND THE RAKE CAN NOT MOVE BEFORE SERVICING THE HDII RAKE. MAINTENANCE AND REPAIR SERVICE WORK TO BE PERFORMED BY A QUALIFIED SERVICE PERSON ONLY. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY...

  • Page 25: Instructions For Ordering Parts - About Improvements

    INSTRUCTIONS FOR ORDERING PARTS All service parts should be ordered through your authorized H&S dealer. They will be able to give you faster service if you will provide them with the following Model & Serial number is located on the left, rear main frame of your unit. All reference to left or right apply to the machine as viewed from the rear.
  • Page 26 FIGURE 1 AXLE UPRIGHTS/TANDEMS -24-...
  • Page 27 FIGURE 1 AXLE UPRIGHTS/TANDEMS DESCRIPTION ITEM PART # 12N24 WHEEL 15 X 8 TIRE & TUBE 9.5L X 15 10 PLY AXLE UPRIGHT HD94 BEAM PIVOT LEFT HD95 HD96 BEAM PIVOT RIGHT HD153 BUSHING BOLT, 5/8" X 7" GR. 5 YBHH20105 UPRIGHT BOTTOM PIVOT HD98...
  • Page 28 FIGURE 2 MAIN FRAME -26-...
  • Page 29 FIGURE 2 MAIN FRAME ITEM PART # DESCRIPTION HITCH CLEVIS HD83 HITCH PIN BFR450 YPHR02010 HAIR PIN, #21-07 HD84 HITCH MOUNT RIGHT HD85 HITCH MOUNT SPACER HITCH MOUNT LEFT HD86 YBHH16160 BOLT, 1/2" X 5-1/2" GR. 5 YWLO16005 WASHER, LOCK, 1/2" YNHX16005 HEX NUT, 1/2"...
  • Page 30 FIGURE 3 RAKE BEAMS -28-...
  • Page 31 FIGURE 3 RAKE BEAMS ITEM PART # DESCRIPTION HD229 RAKE BEAM LEFT A HD110 LIFTING PIPE LEFT HD230 RAKE BEAM RIGHT A HD112 LIFTING PIPE RIGHT HD113 STABILIZER TUBING HD114 TURNBUCKLE YNJM32010 HEX NUT, JAM, 1"-8 HD116 TURNBUCKLE END HD117 RAKE WHEEL HD203 COMPLETE LH RAKE WHEEL...
  • Page 32 FIGURE 3 RAKE BEAMS -30-...
  • Page 33 FIGURE 3 RAKE BEAMS ITEM PART # DESCRIPTION YWFL12005 WASHER, FLAT, 3/8" USS YWLO12005 WASHER, LOCK, 3/8" YNTL12005 HEX NUT, TOP LOCK, 3/8"-16 HD130 LIFTING CYLINDER MOUNT RIGHT HD131 LIFTING CYLINDER MOUNT LEFT HD175 LIFTING PIPE COLLAR HD91 STANDOFF MOUNTING PLATE HD132 CYLINDER MOUNT HD214...
  • Page 34 FIGURE 4 HYDRAULICS -32-...
  • Page 35 FIGURE 4 HYDRAULICS ITEM PART# DESCRIPTION HD135 HYDRAULIC CYLINDER 3" x 8"(SERIAL #315498 AND PRIOR) 56009 HYDRAULIC CYLINDER 3" x 8"(SERIAL #315499 AND FOWARD) HD136 HYDRAULIC CYLINDER 3-1/2" x 60"(SERIAL #315533 AND PROIR) 56014 HYDRAULIC CYLINDER 3-1/2" x 60"(SERIAL #315534 AND FORWARD) 16SV171 HYDRAULIC LIFT CYLINDER 2"...
  • Page 36 FIGURE 5 WIRING -34-...
  • Page 37 FIGURE 5 WIRING DESCRIPTION PART # ITEM S310 RED TAIL LIGHT RUBBER LIGHT MOUNT S308 LIGHT BRACKET HD148 DWM129 YELLOW HAZARD LIGHT HD180 COMPLETE CONTROL BOX W/ HARNESS CONTROL BOX WHIP HD160 MAIN HARNESS HD161 S441 LIGHT MODULE HD149 TAIL LIGHT LOOM FLOOD/WORK LIGHT DWM130 CONTROL BOX DECAL...
  • Page 38 FIGURE 6 HYDRAULIC CYLINDERS -36-...
  • Page 39 FIGURE 6 HYDRAULIC CYLINDERS LIFT CYLINDER/ FRAME WIDTH WING CYLINDER/ 2" X 10" 3" x 8" 3-1/2" x 60" ITEM PART # PART # PART # DESCRIPTION 23N142A CHM138 XR55 CLEVIS CAP(SERIAL #315498 AND PRIOR) 23N143A HD188 HD189 ROD CAP(SERIAL #315498 AND PRIOR) 56174 56176...
  • Page 40 FIGURE 7 HYDRAULIC VALVE PRESSURE PORT Din # 1 RIGHT BEAM OPEN Din # 2 RIGHT BEAM CLOSED Din # 3 LEFT BEAM OPEN LEFT BEAM CLOSED Din # 4 Din # 5 RIGHT WIDTH OUT Din # 6 RIGHT WIDTH IN Din # 7 LEFT WIDTH OUT LEFT WIDTH IN...
  • Page 41 FIGURE 8 MAIN HARNESS -39-...
  • Page 42 FIGURE 9 CONTROL BOX WIRING -40-...
  • Page 43 FIGURE 10 OPEN CENTER CHANGE If closed center valve is used on a open center tractor it will cause the oil to heat because oil is dumping over relief. Instructions for converting valve to open center: Widen left side of rake using left frame width switch on control box (Remember to be moving forward or rearward when doing this).
  • Page 44 FIGURE 11 FRONT RAKE WHEEL EXTENSION -42-...
  • Page 45 FIGURE 11 FRONT RAKE WHEEL EXTENSION ITEM PART # DESCRIPTION HD252 POLE HD251 TURNBUCKLE LONG STUB LEFT HD259 RAKE BEAM LEFT EXTENSION HD260 RAKE BEAM RIGHT EXTENSION HD253 LIFT PIPE HD246 RAKE ARM RIGHT COMPLETE (INCLUDING SPRING ASSEMBLY) (SEE FIGURE 3 FOR DETAIL) HD245 RAKE ARM LEFT COMPLETE (INCLUDING SPRING ASSEMBLY) (SEE FIGURE 3 FOR DETAIL)
  • Page 46 FIGURE 12 RIGHT REAR WHEEL EXTENSION -44-...
  • Page 47 FIGURE 12 RIGHT REAR WHEEL EXTENSION ITEM PART # DESCRIPTION HD244 CYLINDER MOUNT DOUBLE HD242 HOSE HOLDER HD243 CYLINDER MOUNT EXTENSION HD91 STANDOFF MOUNTING PLATE HD132 CYLINDER MOUNT HD113 STABILIZER TUBING HD114 TURNBUCKLE HD116 TURNBUCKLE END HD239 RAKE BEAM REAR EXTENSION HD128 BUSHING HD241...

  • Page 48: Service And Parts Notes

    SERVICE & PARTS NOTES -46-...

  • Page 49: Specifications

    SPECIFICATIONS Wheel Diameter..... .60” 60” 60” 60” Teeth per Wheel........36 (18 sets of 2) Teeth .
  • Page 50 H&S MFG H&S MFG ..CO H&S MFG CO ..H&S MFG H&S MFG products approved for the FEMA FEMA FEMA FEMA FEMA SEAL OF Q SEAL OF Q U U U U U ALITY SEAL OF Q ALITY ALITY...
