HOMCOM A91-186 Using Instruction page 9

2. The main frame group (1) is docked with the front support frame (2), and the screws (3)
are fixedly locked with the nuts (5) and the spacers (4), and then the pins (6) are inserted.
05
04
02
3. Insert the elbow pad (13) into the square tube of the front support frame (2) and lock it
with the M16 spring pin (14). The buckle at the end of the drawstring is fastened to the
retaining ring of the front leg tube(18).
13
02
01
06
03
14
EN-4
