For example, the cycle with the total duration of 24
hours means 20 cycles of engine activation for 15 minutes
each as well as 19 stoppage cycles of 1 hour each one
24h00m
P
1
Fig 1. Creaming machine controller handling panel
3.1. Description of buttons – functions of the
controller
Once power supply is connected, the controller performs
self-diagnostics to acknowledge the correct device operation.
Error detection is signalled by the relevant code being
displayed on the LCD screen
If errors have not been detected, the screen display will look
like in Fig. 2.
Fig. 2. Depending on the previous set-ups, the screen
will display previously preset creaming machine
operating time.
The controller possesses several programmes , which
allows to select precisely the total creaming time ranging
from 24 hours to 99 hours as well as 1 hour in special cycle
(for the devices on a de-crystallizer).
Controller handling boils down to the selection of a
programme ( by pressing the "P" button and subsequent
activation of selected programme cycle by pressing the
START button.
In order to select a proper operating time for the creaming
STOP START
2 3
machine, "P" button shall be pressed, as in Fig. 3 and the
device operating time shall be set:
72h, 84h, 96h, 99h).
Cycle execution time
Fig. 3 Selection of
In order to activate the creaming machine stirrer operation,
press START button, as in Fig. 4
Cycle execution time
Rys. 4 Programme activation
The screen of the controller working with activated
creaming cycle specifies the time that has passed since the
cycle activation. (Fig. 5). Additional icon informs about the
stirrer activation mode.
(no icon – stirrer stoppage, visible icon – stirrer rotates)
Czas, jaki upłynął
Time that has passe since
od włączenia cyklu
the creaming machine activation
Fig 5. Activated creaming cycle
STOP button allows to deactivate the programme
performed (Fig.6).
Re-activated programme will operate from the beginning ,
i.e. operating throughout the entire time specified.
Proper termination of the creaming cycle is signalled by an
inscription OK (Fig .7) showed in the display screen
(
24h, 36h, 48h, 60h,
programme.
2:30
P
STOP START
