- Page 1 Maintenance instructions P2578WA-EN 2021-10 BD Series Spindle For additional product information, visit our website at www.clecoTools.com...
- Page 2 Apex Tool Group reserves the right to modify, supplement, or improve this document or the product with- out prior notice. Trademark Cleco Production Tools is a registered trademark of Apex Brands, Inc. Apex Tool Group 670 Industrial Drive Lexington, SC 29072...
-
Page 3: Table Of Contents
Content About this document ................4 Other documents ......................4 Symbols in the text ......................4 Safety ....................4 Warnings and Notices ..................... 4 Symbols on the Product ....................4 Operator Training ......................5 Personal Protective Equipment ..................5 Maintenance ..................6 Lubricants ........................ -
Page 4: About This Document
Document A symbol combined with the word Warning indicates a hazard with a medium level of P2577SB System manual – BD Series risk which, if not avoided, could result in death or serious injury. P2579MA Assembly instructions – Fixtured Spin-... -
Page 5: Operator Training
Operator Training Personal Protective Equipment The fastening system may only be put into operation, set ► Wear safety shoes. up and maintained by personnel who have been trained The motor can heat up and cause burns during re- and qualified by the Apex Tool Group. moval (max. -
Page 6: Maintenance
Maintenance Maintenance is only permitted byApex Tool Group authorized personnel. Regular maintenance reduces operational inter- ruptions, repair costs and downtimes. Therefore, implement a safety-related maintenance program that takes into ac- count the local regulations for repair and maintenance for all the operating phases of the tool. Note Incorrect calibration data After replacing a component that has an impact on the accuracy of the tool (motor, gear, output drive),... -
Page 7: Removal
Removal ► Loosen and remove plug connectors. ► Remove the complete spindle from the work cell. ► Fix the spindle or component to the wrench flats in a vice. Place in position, do not tighten! ► Turn the cap nut counterclockwise. ►... -
Page 8: Tightening Torques
Tightening torques Attachment – Transducer Size Index Tightening torque Tightening torque Hook wrench Torque wrench Target Setting Order No. Order No. [Nm] [Nm] 55–60 48–53 933336 933340 50–55 43–48 933336 933340 80–90 68–78 933337 933340 40–50 33–43 933337 933340 80–90 68–78 933338 933340... -
Page 9: Recalibration Of Fastener Data
Fastening gear – Motor Size Index Tightening torque Screwdriver Target Order No. [Nm] 2.7-3.3 913947 2.7-3.3 913947 4.9-5.1 Upon request 9-11 920533 4.9-5.1 Upon request 9-11 920533 Recalibration of fastener data The fastener data are defined in the service memory of the spindle and are located in the transducer (i.e., also offset at- tachment and angle drive attachment) and motor. - Page 10 POWER TOOLS SALES & SERVICE CENTERS Please note that all locations may not service all products. Contact the nearest Cleco® Sales & Service Center for the appropriate facility to handle your service requirements. Sales Center Service Center NORTH AMERICA | SOUTH AMERICA...
