OPERATOR'S MANUAL
MODEL #92001i-EU
1900W RATED PORTAbLE INvERTER GENERATOR
ENGLISH
+44 (0)1942 715 407
or visit championpowerequipment.co.uk
SAvE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure
to do so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
Made in China - REV 20220531
Advertisement
Table of Contents
Related Manuals for Champion Global Power Equipment 92001i-EU
Summary of Contents for Champion Global Power Equipment 92001i-EU
- Page 1 OPERATOR'S MANUAL MODEL #92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR ENGLISH +44 (0)1942 715 407 or visit championpowerequipment.co.uk SAvE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do so could result in serious injury. This manual should remain with the product.
-
Page 2: Safety Definitions
INTRODUCTION 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR INTRODUCTION SAFETY DEFINITIONS Congratulations on your purchase of a Champion Power The purpose of safety symbols is to attract your attention to Equipment (CPE) product. CPE designs, builds, and supports possible dangers. The safety symbols, and their explanations, deserve your careful attention and understanding. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR IMPORTANT SAFETY INSTRUCTIONS DANGER Operate equipment with guards in place. DANGER Rotating parts can entangle hands, feet, hair, clothing and/ Generator exhaust contains carbon monoxide, a colorless, or accessories. Traumatic amputation or severe laceration odorless, poisonous gas. - Page 4 IMPORTANT SAFETY INSTRUCTIONS 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR WARNING CAUTION Spark from removed spark plug wire can result in fire or Start the generator and allow the engine to stabilize before electrical shock. connecting electrical loads. Connect electrical equipment in the off position, and then When servicing the generator: turn them on for operation.
-
Page 5: Fuel Safety
IMPORTANT SAFETY INSTRUCTIONS 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Fuel Safety DO NOT move or tip the generator during operation. DO NOT tip the generator or allow fuel or oil to spill. DANGER When transporting or servicing the generator: GASOLINE AND GASOLINE VAPORS ARE HIGHLY Make certain that the fuel valve is in the OFF position and the FLAMMABLE AND EXPLOSIVE. -
Page 6: Safety Symbols
IMPORTANT SAFETY INSTRUCTIONS 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Safety Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product. -
Page 7: Operation Symbols
IMPORTANT SAFETY INSTRUCTIONS 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Operation Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product. -
Page 8: Quickstart Label Symbols
IMPORTANT SAFETY INSTRUCTIONS 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Quickstart Label Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product. -
Page 9: Controls And Features
CONTROLS AND FEATURES 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR CONTROLS AND FEATURES Read this operator’s manual before operating your generator. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Generator 1. Carrying Handle – Used to lift or carry the unit. -
Page 10: Control Panel
CONTROLS AND FEATURES 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Control Panel 1. Parallel Outlets – Used for parallel operation (parallel kit RECEPTACLES sold separately). (2×) 220V AC, 16A 2. Ground Terminal – Consult an electrician for local May be used to supply power for grounding regulations. -
Page 11: Parts Included
CONTROLS AND FEATURES 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Parts Included Accessories Engine Oil ........500ml/16.9 fl.oz Oil Funnel .. - Page 12 ASSEMbLY 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR ASSEMbLY Your generator requires some assembly. This unit ships from our factory without oil. It must be properly serviced with fuel and oil before operation. If you have any questions regarding the assembly of your generator, call our Technical Support Team at +44 (0)1942 715 407.
- Page 13 ASSEMbLY 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR CAUTION CAUTION This engine is equipped with a low oil shut-off and will stop Use unleaded gasoline with a minimum octane rating of 85 when the oil level in the crankcase falls below the threshold and an ethanol content of 10% or less by volume.
-
Page 14: Operation
OPERATION 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Grounding next to walls or buildings, or in any other location that will not allow for adequate cooling of the generator and/or the muffler. Your generator must be properly connected to an appropriate DO NOT contain generators during operation. -
Page 15: Starting The Engine
OPERATION 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Starting the Engine 6. Pull the recoil cord slowly until resistance is felt and then pull rapidly. 1. Make certain the generator is on a flat, level surface. 2. Disconnect all electrical loads from the generator. Never start or stop the generator with electrical devices plugged in or turned on. -
Page 16: Connecting Electrical Loads
OPERATION 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR needed to start some electric driven equipment. Following NOTICE the steps listed under “Power Management” will guarantee that only one device will be starting at a time. If the engine starts but does not continue to run make certain that the generator is on a flat, level surface. -
Page 17: Parallel Operation
NEVER operate any 12VDC load when it is plugged into the Parallel Operation socket. The Champion model 92001i-EU is parallel ready and can be Prolonged exposure to engine exhaust can cause serious operated in parallel with another Champion unit to increase injury or death. -
Page 18: Moving The Generator
OPERATION 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Moving the Generator WARNING – ALWAYS turn the generator off and ensure the fuel valve is Operation using the alternative main jet at elevations lower closed. than the recommended minimum altitude can damage the –... -
Page 19: Cleaning The Generator
OPERATION 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Cleaning the Generator 5. Add oil according to Add Engine Oil in Assembly section. DO NOT OVERFILL. Oil not included for routine CAUTION maintenance. 6. Reinstall the maintenance cover. DO NOT spray generator directly with water. - Page 20 OPERATION 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR 7. Refer to the spark plug types in Specifications when replacing the plug. 8. Firmly re-install the plug. 9. Attach the spark plug cable to the spark plug. 10. Reinstall the spark plug access cap and maintenance cover.
-
Page 21: Short Term Storage (Up To 30 Days)
STORAGE 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Short Term Storage (up to 30 days) EVERY 8 HOURS OR PRIOR TO EACH USE Gasoline in the gasoline tank has a maximum shelf life of up to — Check oil level 1 year with the addition of properly formulated fuel stabilizers —... -
Page 22: Long Term Storage (More Than 1 Year)
STORAGE 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Long Term Storage (more than 1 year) Removing from Storage For storage over 1 year, the gasoline tank and carburetor must If the generator has been improperly stored for a long period be completely drained of gasoline. -
Page 23: Specifications
SPECIFICATIONS 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR SPECIFICATIONS Oil Specifications DO NOT OVERFILL. Generator Specifications Type ........*See following chart Generator Model ........ -
Page 24: Warranty
WARRANTY* 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR WARRANTY* warranty and is not required to be performed at a facility or by a person authorized by CPE. CHAMPION POWER EQUIPMENT 3 YEAR LIMITED WARRANTY Other Exclusions This warranty excludes: Warranty Qualifications –... -
Page 25: Parts Diagram
92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Parts Diagram... -
Page 26: Parts List
92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Parts List Part Number Description Qty. Part Number Description Qty. 35 100090871 100010946-0001 Screw M4 x 10 Calmp 2, Ø9.7 x 8 36 100009020 Fuel Strainer 100095857-0005 Bolt M4 x 18 37 100072874 Rear Air Guide... - Page 27 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Part Number Description Qty. Rectifier Bridge, 67 100716268-0001 Capacitance Vibration Mount, 68 100072715-0001 Support Housing Assembly, 69 100088546 Bottom, Black 70 100072711 Housing, Bottom, Black 71 100072994-0001 Step Nut M6 72 100072710-0001 Rubber Damper...
-
Page 28: Engine Parts Diagram
92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Engine Parts Diagram... -
Page 29: Engine Parts List
92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Engine Parts List Part Number Description Qty. Part Number Description Qty. Big Flange Bolt M6 x 18 36 100159354 Valve Intake 100033099-0008 37 100075036 Lifter, Valve 100097810 Spark Plug(E6RTC) 38 100075040 Piston Ring Set... - Page 30 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Part Number Description Qty. 72 100011571-0002 Big Flange Bolt M6 x 14 73 100131964 Fuel Bowl Mounting Bolt 74 100131960 Fuel Bowl O-Ring 100163552 Main Jet Standard Main Jet Altitude 1000- 100163549 2000m Main Jet Altitude 2000-...
-
Page 31: Wiring Diagram
92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR Wiring Diagram... -
Page 32: Ec Declaration Of Conformity
WARRANTY* 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR EC DECLARATION OF CONFORMITY CHAMPION POWER EQUIPMENT, INC. 12039 SMITH AVENUE, SANTA FE SPRINGS, CA 90670, USA Hereby declare that the following Appliance complies with the appropriate basic safety and health requirements of the EC Directives (see item 3 &... - Page 33 WARRANTY* 92001i-EU 1900W RATED PORTAbLE INvERTER GENERATOR 5. Responsible for documentation: CHAMPION POWER EQUIPMENT, INC. Address: 12039 SMITH AVENUE, SANTA FE SPRINGS, CA 90670, USA 6. Person responsible for compiling the technical files established within the EU Name, Surname: Winch Solutions LTD...
- Page 34 Champion Power Equipment Europe Service & Technical Contacts United Kingdom: Germany: France: BPE Holdings BPE Solutions Deutschland GmbH BPE Solutions France SAS Unit 17-18 Altrottstraße 31 3 Boulevard de Belfort Bradley Hall Trading Estate D-69190 Walldorf 59000 Lille Bradley Lane, Standish Germany France Wigan, WN6 0XQ, UK...
