OPERATOR'S MANUAL
MODEL #100745
2000W DUAL FUEL INVERTER GENERATOR
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com
or visit championpowerequipment.com
SAVE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do
so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
This product meets the requirements of the PGMA (Portable Generator Manufacturers' Association) standard ANSI/PGMA G300-2015 (Safety and Performance of
Portable Generators).
Made in China - REV 20200226
Champion Power Equipment, Inc., Santa Fe Springs, CA USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 100745 and is the answer not in the manual?

Questions and answers

Related Manuals for Champion Global Power Equipment 100745

Summary of Contents for Champion Global Power Equipment 100745

  • Page 1 OPERATOR'S MANUAL MODEL #100745 2000W DUAL FUEL INVERTER GENERATOR REGISTER YOUR PRODUCT ONLINE at championpowerequipment.com or visit championpowerequipment.com SAVE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do so could result in serious injury.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 100745 - 2000W DUAL FUEL INVERTER GENERATOR TABLE OF CONTENTS Maintenance ..........Cleaning the Generator ..........

  • Page 3: Introduction

    INTRODUCTION 100745 - 2000W DUAL FUEL INVERTER GENERATOR SAFETY DEFINITIONS INTRODUCTION Congratulations on your purchase of a Champion Power Equipment The purpose of safety symbols is to attract your attention to (CPE) product. CPE designs, builds, and supports all of our possible dangers.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR IMPORTANT SAFETY INSTRUCTIONS DANGER Operate equipment with guards in place. DANGER Rotating parts can entangle hands, feet, hair, clothing and/or Generator exhaust contains carbon monoxide, a colorless, accessories. Traumatic amputation or severe laceration can odorless, poisonous gas.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR WARNING CAUTION Spark from removed spark plug wire can result in fire or Start the generator and allow the engine to stabilize before electrical shock. connecting electrical loads. Connect electrical equipment in the off position, and then turn When servicing the generator: them on for operation.

  • Page 6: Fuel Safety

    IMPORTANT SAFETY INSTRUCTIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Fuel Safety DO NOT pump gasoline directly into the generator at the gas station. Use an approved container to transfer the fuel to the generator. DANGER DO NOT overfill the gasoline tank.

  • Page 7: Safety And Dataplate Labels

    IMPORTANT SAFETY INSTRUCTIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Safety and Dataplate Labels These labels warn you of potential hazards that can cause serious injury. Read them carefully. If a label comes off or becomes hard to read, contact Technical Support Team for possible replacement.

  • Page 8: Safety Symbols

    IMPORTANT SAFETY INSTRUCTIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Safety Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product.

  • Page 9: Operation Symbols

    IMPORTANT SAFETY INSTRUCTIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Operation Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product.

  • Page 10: Quickstart Label Symbols

    IMPORTANT SAFETY INSTRUCTIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Quickstart Label Symbols Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to more safely operate the product.

  • Page 11: Controls And Features

    CONTROLS AND FEATURES 100745 - 2000W DUAL FUEL INVERTER GENERATOR CONTROLS AND FEATURES Read this operator’s manual before operating your generator. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Generator 1.

  • Page 12: Power Panel

    CONTROLS AND FEATURES 100745 - 2000W DUAL FUEL INVERTER GENERATOR Power Panel 100% 00:00 REMAINING REMAINING RESTANT RESTANT 1. Power Output – Percentage of available power from 6. AC Overload Reset Button – Used to re-energize receptacles generator being used.

  • Page 13: Control Panel

    CONTROLS AND FEATURES 100745 - 2000W DUAL FUEL INVERTER GENERATOR Control Panel Parts Included 1. Ground Terminal – Consult an electrician for local grounding regulations. Accessories 2. Circuit Breakers (Push Reset) – Protects the generator Oil Funnel ............against electrical overloads.

  • Page 14: Assembly

    ASSEMBLY 100745 - 2000W DUAL FUEL INVERTER GENERATOR ASSEMBLY Your generator requires some assembly. It must be properly serviced with fuel and oil before operation. If you have any questions regarding the assembly of your generator, call our Technical Support Team at 1-877-338-0999.

  • Page 15: Add Fuel: Gasoline

    ASSEMBLY 100745 - 2000W DUAL FUEL INVERTER GENERATOR NOTICE NOTICE Synthetic oil may be used after the 5 hour initial break-in The generator engine works well with 10% or less ethanol period. Using synthetic oil does not increase the recommended blend gasoline.

  • Page 16: Grounding

    OPERATION 100745 - 2000W DUAL FUEL INVERTER GENERATOR Grounding 7. Check all connections for leaks by wetting the fittings with a solution of soap and water. Bubbles which appear or bubbles Your generator must be properly connected to an appropriate which grow indicate that a leak exists.

  • Page 17: Surge Protection

    OPERATION 100745 - 2000W DUAL FUEL INVERTER GENERATOR location that will not allow for adequate cooling of the generator 3. Turn the fuel cap vent lever to the “ON” position. and/or the muffler. DO NOT contain generators during operation. Allow generators to properly cool before transport or storage.

  • Page 18: Starting The Engine: Propane (Lpg)

    OPERATION 100745 - 2000W DUAL FUEL INVERTER GENERATOR 6. Move the EZ Start dial to the “RUN” position. NOTICE For gasoline restarts with hot engine in hot ambient > 86°F (30°C): Rotate the EZ Start dial to 75% of the full choke position for only one pull of the recoil cord.

  • Page 19: Connecting Electrical Loads

    OPERATION 100745 - 2000W DUAL FUEL INVERTER GENERATOR Connecting Electrical Loads 1. Start the generator with no electrical load attached. 2. Allow the engine to run for several minutes to get up to Let the engine stabilize and warm up for a few minutes after temperature.

  • Page 20: Parallel Operation

    100745 - 2000W DUAL FUEL INVERTER GENERATOR Parallel Operation WARNING The Champion model 100745 is parallel ready and can be Do not operate a device while it is plugged in to the 12V DC operated in parallel with another Champion unit to increase outlet.

  • Page 21: Moving The Generator

    MAINTENANCE 100745 - 2000W DUAL FUEL INVERTER GENERATOR The owner/operator is responsible for all periodic maintenance. NOTICE Complete all scheduled maintenance in a timely manner. If the generator will not be used for a period of two (2) weeks Correct any issue before operating the generator.

  • Page 22: Cleaning And Adjusting The Spark Plug

    MAINTENANCE 100745 - 2000W DUAL FUEL INVERTER GENERATOR Cleaning and Adjusting the Spark Plug 3. Remove the foam element. 4. Wash in liquid detergent and water. Squeeze thoroughly dry in 1. Remove the maintenance cover. a clean cloth. 5. Saturate in clean engine oil.

  • Page 23: Replacing Fuel Light Batteries

    MAINTENANCE 100745 - 2000W DUAL FUEL INVERTER GENERATOR Replacing Fuel Light Batteries 1. Use a small screwdriver to disassemble the upper cover. 5. Insert the small spring back into the pocket of the upper cover and press the upper cover into place to complete the installation.

  • Page 24: Storage

    STORAGE 100745 - 2000W DUAL FUEL INVERTER GENERATOR Short Term Storage (up to 30 days) EVERY 8 HOURS OR PRIOR TO EACH USE Gasoline in the gasoline tank has a maximum shelf life of up to 1 Check oil level year with the addition of properly formulated fuel stabilizers and Clean around air intake and muffler...

  • Page 25: Long Term Storage (More Than 1 Year)

    STORAGE 100745 - 2000W DUAL FUEL INVERTER GENERATOR Removing from Storage 6. After fuel has run out and the engine has stopped, allow the engine to cool. If the generator has been improperly stored for a long period of 7. Remove maintenance cover.

  • Page 26: Specifications

    SPECIFICATIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR SPECIFICATIONS Recommended Engine Oil Type 10W-30 Generator Specifications 5W-30 10W-40 Generator Model ......... .. 100745 5W-30 Synthetic Start Type .

  • Page 27: Parts Diagram

    SPECIFICATIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Parts Diagram...

  • Page 28: Parts List

    SPECIFICATIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Parts List Part Number Description Qty. Part Number Description Qty. 38 88.070011.01 1.818.0514.3 Screw M5 × 14, Green Pipe, Fuel Tank to Valve 39 111.070300.01 Fuel Filter, Wire Mesh 62.200200.00 Cover, Left, black 40 2.06.018...
  • Page 29 SPECIFICATIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Part Number Description Qty. 75 2.06.048 Clamp Ø15.7 76 62.070012.00 Pipe 220 mm 77 2.06.019 Hose Clamp Ø15 78 62.070037.00 Support, Inlet Connection 79 1.6170.03 Hexagon Nut M3 8Amp Circuit Breaker, 80 5.1200.908...

  • Page 30: Engine Parts Diagram

    SPECIFICATIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Engine Parts Diagram...

  • Page 31: Engine Parts List

    SPECIFICATIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Engine Parts List Part Number Description Qty. Part Number Description Qty. 43 81.090004.00 62.190006.00 Rubber Sleeve, End Cover Pipe, Air Cleaner 44 81.090003.00 Joint, Breather Pipe 1.5789.0512 Flange Bolt M5 × 12 Pressure Plate, 62.190002.01...
  • Page 32 SPECIFICATIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Part Number Description Qty. 84 62.081100.00 Muffler Protector, Side 85 81.081003.00 Fastening Insert Piece 86 81.100001.00 Gasket, Exhaust Pipe 87 81.081002.00 Rubber Seal Sleeve 88 62.101100.00 Muffler Assembly 89 1.6175.06.3 Nut M6 90 81.101300.00...

  • Page 33: Wiring Diagram

    SPECIFICATIONS 100745 - 2000W DUAL FUEL INVERTER GENERATOR Wiring Diagram...

  • Page 34: Troubleshooting

    TROUBLESHOOTING 100745 - 2000W DUAL FUEL INVERTER GENERATOR TROUBLESHOOTING Problem Cause Solution No fuel. Add fuel. Faulty spark plug. Clean and adjust spark plug or replace. Fill crankcase to the proper level. Low oil level. Place generator on a flat, level surface.

  • Page 35: Warranty

    WARRANTY 100745 - 2000W DUAL FUEL INVERTER GENERATOR WARRANTY* Other Exclusions This warranty excludes: CHAMPION POWER EQUIPMENT – Cosmetic defects such as paint, decals, etc. 3 YEAR LIMITED WARRANTY – Wear items such as filter elements, o-rings, etc. Warranty Qualifications –...
  • Page 36 CHAMPION POWER EQUIPMENT, INC. (CPE) AND THE UNITED STATES ENVIRONMENT PROTECTION AGENCY (U.S. EPA) EMISSION CONTROL SYSTEM WARRANTY Your Champion Power Equipment (CPE) engine complies with U.S. EPA emission regulations. YOUR WARRANTY RIGHTS AND OBLIGATIONS: The US EPA AND CPE are pleased to explain the Federal Emission Control Systems Warranty on your 2020 small off-road engine (SORE) and engine powered equipment.
  • Page 37 EMISSION CONTROL SYSTEM WARRANTY The following are specific provisions relative to your Emission Control System (ECS) Warranty Coverage. 1. APPLICABILITY: This warranty shall apply to 1997 and later model year small off-road engines (SORE). The ECS Warranty Period shall begin on the date the new engine or equipment is delivered to its original, end-use purchaser, and shall continue for 24 consecutive months thereafter.
  • Page 38 EMISSION-RELATED PARTS INCLUDE THE FOLLOWING: (using those portions of the list applicable to the engine) Systems covered by this Parts Description warranty Fuel Metering System Fuel regulator, Carburetor and internal parts Air Induction System Air cleaner, Intake manifold Ignition System Spark plug and parts, Magneto ignition system Exhaust System Exhaust manifold, catalytic converter...
