- Page 1 TRADITIONAL COOKER HOOD Model: CH-400-BRW/ CH-400-BK • Traditional cooker hood • Suction power: 326.4 m³/h • Color: black/ brown...
-
Page 2: Safety Precautions
120W, 50Hz, 220-240V Thank you for purchasing this product! INTRODUCTION Before using the appliance, please read carefully this instruction manual and keep it for future reference. This instruction manual is designed to provide you with all required instructions related to the installation, use and maintenance of the appliance. - Page 3 120W, 50Hz, 220-240V If this product has arrived damaged please return for change or repair. DO NOT INSTALL THIS APPILANCE IF YOU FOUND IT DANAGED. Children should be supervised to ensure that they do not play with the appliance.
- Page 4 120W, 50Hz, 220-240V Method B 1) Drill 4 holes of Ø 6mm at the bottom of the hanging Cup board. 2) Put the one way valve on the cooker hood, then install the cooker hood on the bottom of the cupboard, tighten the hood with enclosed 6 screws.
-
Page 5: Air Ventilation Setting
120W, 50Hz, 220-240V Notice There are 2 methods for ventilation, including 'horizontal ventilation' and 'vertical ventilation'. Please pay attention to the ventilation method when installation. Horizontal ventilation: As shown in pic. 4A, please use the cover to seal the outlet on the top, then the air can be vented from back. -
Page 6: Operation
120W, 50Hz, 220-240V OPERATION The switch is operated as below (see pic. 6): Press “0”, the motor will be off. Press the button to “low”, “middle” and “high”, the motor will be turned on at “ low”, “middle” and “ high” speed respectively. - Page 7 120W, 50Hz, 220-240V Changing the light *Before changing the lights, make sure that the appliance is plugged off. *Open the filter, see beside picture. *Change the bulb with Max. 2W LED bulb. *Replace the filter to the original position.
-
Page 8: Technical Fiche
120W, 50Hz, 220-240V VIII. TECHNICAL FICHE Suction power: 326.4 m³/h Motor 2x60W Color: White/ black/ brown/ inox Environment friendly disposal You can help protect the environment! Please remember to respect the local regulations: hand in the non-working electrical equipment’s to an appropriate waste disposal center. -
Page 9: Product Fiche
120W, 50Hz, 220-240V Product fiche Trademark Heinner CH-400-BK, CH- Model 400-BRW Annual energy consumption (kWh/year) 56.6 Energy efficiency class Fluid dynamic efficiency 11.6 Fluid dynamic efficiency class Lighting efficiency (lux/W) 35.5 Lighting efficiency class Grease filtering efficiency (%) 75.6...
