Summary of Contents for Gold Medal Unifloss Top 3034
- Page 1 Instruction Manual Unifloss Tops Model Series: 3034 and 3035 Base and Floss Unit sold separately. 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2019 Gold Medal Products Co. Part No. 13054...
-
Page 2: Safety Precautions
Unifloss Top Model Series: 3034 and 3035 SAFETY PRECAUTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. - Page 3 007_010914 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 4: Installation Instructions
Unifloss Top Model Series: 3034 and 3035 INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). -
Page 5: Before You Plug In Machine
We recommend this equipment be on a dedicated and protected circuit. Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 6: Lights Switch
Unifloss Top Model Series: 3034 and 3035 OPERATING INSTRUCTIONS Controls and Their Functions (if equipped) LIGHTS SWITCH Two position, ON/OFF switch - supplies power to the exterior display lights and interior cabinet light. FAN SWITCH Two position, ON/OFF switch - supplies power to the exhaust blower. Controls View –... -
Page 7: Care And Cleaning
4. Clean glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No. 2588) is recommended. Ammonia cleaners will damage plastic doors/panels. Only use a non-ammonia cleaner, such as Gold Medal Watchdog Glass Cleaner (Item No. -
Page 8: Maintenance Instructions
Unifloss Top Model Series: 3034 and 3035 MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. -
Page 9: Ordering Spare Parts
Web Page: gmpopcorn.com Replacing Broken Glass Broken glass panels can be easily replaced. Gold Medal Products Co. does not ship glass. It can be obtained from a local glass shop, always purchase tempered glass. GLASS DIMENSIONS (Height x Width x Thickness) 3034 Series: 15 3/16”... - Page 10 Unifloss Top Model Series: 3034 and 3035 3034 and 3034GT Mini Unifloss Top – Parts List 3034 Mini Unifloss Top (Base, Floss Machine and pan shown for reference only, not included with Unifloss Top.) 3036 Base (sold separately, for parts, see Base Parts List section). Part Number Item Part Description...
- Page 11 POWER SUPPLY 24VDC 60W 55586 LED LIGHT 800 LUMENS (cabinet light) 55590 *CAUTION: If supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent, or similarly qualified persons in order to avoid a hazard. gmpopcorn.com Page 11...
- Page 12 Unifloss Top Model Series: 3034 and 3035 3036 Base – Parts List Part Number Item Part Description 3036 SWIVEL CASTER W/O LOCK 37513 NSF SWIVEL CSTR W/LOCK 37514 5/16-18 X 5/8 PH TR M/S (Caster fastener) 46638 WASHER 5/16 INT TOOTH (Caster fastener) 74137 5/16-18 SERRATED LOCK NUT (Caster fastener) 49317...
-
Page 13: Wiring Diagram
Unifloss Top Model Series: 3034 and 3035 Wiring Diagram Model No. 3035-00-000 and 3035-00-001 gmpopcorn.com Page 13... - Page 14 © 2019 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
