Baby Amelie-
2 Door Robe
Assembly Instructions
247/9873
- Please keep for future reference
Dimensions
Width - 93 cm
Depth - 57 cm
Height - 160 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 08456 400 800
Issue 1 - 02/05/14
Advertisement
Related Manuals for Argos Amelie 247/9873
Summary of Contents for Argos Amelie 247/9873
- Page 1 Baby Amelie- 2 Door Robe Assembly Instructions 247/9873 - Please keep for future reference Dimensions Width - 93 cm Depth - 57 cm Height - 160 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 02/05/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly . Check you have all the This product has been produced We do not from natural timber; you may recommend the components and tools listed on pages 2 and 3. - Page 3 Components - Panels Please check you have all the panels listed below 8 Bottom frame x 1 (76x6 cm) 9 Back rail x 1 (76x4.5 cm) 22 Large back rail x 1 (76x9 cm) Back panel x 2 (133.5x39.4 cm) Drawer left side x 1 (40x10.5 cm) 24 "H"...
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Fitting Wooden Dowels: Insert dowels into holes in the indicated parts. Fitting metal dowel Screw metal dowel into top frame and side panels Note: Insert metal dowels as far as shown. Do not over tighten. Fixing hinge plates: Fix hinge plates in the pre drilled holes on side panels...
- Page 6 Assembly Instructions Step 2 Fixing hinge: Fix hinge in the pre drilled holes on doors using screws Fix knob using bolts Step 3 2 3 4 Parts are labelled for easier identification. Attach left side panel to left front foot and left back foot using screws Attach right side panel...
- Page 7 Assembly Instructions Step 4 Fixing runners: Fix runners in the pre drilled holes on side panel using screws Attention: Make sure runners are positioned as shown.
- Page 8 Assembly Instructions Step 5 Assembly the cabinet Fit base panel and front rail to the right side panel shown. Insert 4 locking nuts into base panel and front rail where shown. Use a screwdriver to turn locking nuts clockwise to lock.
- Page 9 Assembly Instructions Step 7 a) Fit left side panel to the bottom frame , back rail front rail , base panel large back rail Make sure dowels are fitted into their holes at the same time. Insert 6 locking nuts into bottom frame and back rail...
- Page 10 Assembly Instructions Step 9 Attaching top frame Fit top frame to the top panel Insert 3 locking nuts into top panel where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten. Step 10 Fixing back panel With help, carefully turn the cabinet upright.
- Page 11 Assembly Instructions Step 11 Drawer assembly A) Attach drawer sides in the drawer front using Finished side screws to face inside B) Slide drawer bottom in to slots on drawer sides Make sure finished side face inside the drawer. Fit drawer support to drawer front , as shown.
- Page 12 Assembly Instructions Step 12 Insert hanging rail to the supports as shown. Step 13 Hanging doors: With help, slot door hinges on to plates and tighten screw. Hinge plates must be inserted in the screw at the back of hinge...
- Page 13 Assembly Instructions Step 14 In case of uneven floor, use plastic wedge to level the product before adjusting doors. Door adjustment: 1- To move left or right, loosen screw shown and move doors to suit. Re-tighten screws. 2- To move doors in or out, loosen screw shown and move doors to suit.
- Page 14 Assembly Instructions Step 15 Insert drawers Hook the wheels of the runner on the back of the drawers over the wheels of the runners on the left and right sides, then hold the drawers level and slide backwards into position. Step 16 Adjusting drawers Loosen the screws in the...
- Page 15 Assembly Instructions Step 17 Adjusting drawers To move drawers left or right: loosen the screws in the runners, adjust the drawers to suit and once drawers are aligned retighten. Step 18 Fixing wall strap Fix strap to top of furniture using washer and screw With help, move furniture into...
- Page 16 A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
