Owner's Manual and Assembly Instructions
Model #: W403
Read and understand the entire manual before assembly and operation. The vehicle must be
assembled by an adult who has read and understands the instructions.
Made in China.
Styles and colors may vary. Do not return your product to the store.
Contact Rollplay Customer Service with questions. Call 1-888-982-9309 for assistance and
replacement parts.
IMPORTANT: Save this manual with your sales
receipt.
25701716 04/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLEX KART XL PEDAL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rollplay FLEX KART XL PEDAL

Summary of Contents for Rollplay FLEX KART XL PEDAL

  • Page 1 Made in China. Styles and colors may vary. Do not return your product to the store. Contact Rollplay Customer Service with questions. Call 1-888-982-9309 for assistance and replacement parts. IMPORTANT: Save this manual with your sales receipt.
  • Page 2 Introduction Thank you for purchasing this Rollplay vehicle. We hope the rider enjoys it for miles to come. Please read this instruction guide carefully before assembling and operating the vehicle. Please contact Rollplay Customer Service with any questions. Have your model number and serial number ready before calling.
  • Page 3 E-mail Customer Service if you need assistance or replacement parts. Please have your model number and serial number ready before calling. Keep your sales receipt and register your product at www.rollplay.com, as we require proof of purchase. customerservice@rollplay.com 1-888-982-9309 Read this entire manual prior to assembly to ensure safe operation of the vehicle.

  • Page 4: Table Of Contents

    Table of Contents Safety Parts Unfolding the Frame Drive Wheel Assembly Driven Wheel Assembly Wheel Cover Assembly Seat Assembly and Adjustment Operating the Vehicle Folding General Care Troubleshooting Guide Warranty Product Registration...

  • Page 5: Safety

    Safety WARNING: SAFETY RIDING RULES The user must follow all safety rules and guidelines, or serious injury or death may occur. NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when child is on the vehicle. Direct adult supervision is REQUIRED. •...

  • Page 6: Parts

    Parts Not Included: Phillips screwdriver 1. Manual 5. Driven Wheels (x3) 2. Steering Wheel 6. Drive Wheel 3. Seat 7. Wheel Covers (x4) 4. Vehicle Body 8. Wrench (x1)

  • Page 7: Unfolding The Frame

    Unfolding the Frame Click A. Lift up front of the kart, press both the round button  and the rectangular button  at the same time. B. While pressing both buttons, lift up on the steering column  until it “clicks”...

  • Page 8: Drive Wheel Assembly

    Drive Wheel Assembly A. Remove the nut and washer on the axle with the wrench provided. Set aside for later use. B. Slide the drive wheel onto the axle as shown then insert the washer and tighten the nut. Note: The drive wheel has a square axle hole while the driven wheels have a round one, to match with the ends of the axles.

  • Page 9: Driven Wheel Assembly

    Driven Wheel Assembly For each driven wheel: A. Remove the nut and small washer on the axle with the wrench provided. Leave the large washer on the axle. B. Slide the wheel onto the axle as shown then insert the washer and tighten the nut.

  • Page 10: Wheel Cover Assembly

    Wheel Cover Assembly A. Align the tabs on the wheel cover to slots on the wheel and press it into place. B. Repeat to install other wheel covers.

  • Page 11: Seat Assembly And Adjustment

    Seat Installation and Adjustment Click Pull the spring-operated seat release knob  outwards, align the clamping hook at the bottom of the seat with the seat slide chute . Push the seat onto the chute and then release the seat release knob.  Continue pushing seat toward back until you hear the first “click”.

  • Page 12: Operating The Vehicle

    Operating the Vehicle Backward Forward The pedal can be used to move the vehicle forward and backward as shown. Push the pedal in the desired direction to operate the vehicle.

  • Page 13: Folding

    Folding Click A. Lift up front of the kart, press both the round button  and the rectangular button  at the same time. B. While pressing both buttons, fold the steering column  down. You will hear a “click” sound to indicate the steering column is locked into the folded position.

  • Page 14: General Care

    General Care • Regularly inspect all vehicle parts to ensure they are in good working condition. • Remove any damaged parts and immediately contact Customer Service. • See Page 2 for more information. • DO NOT operate the vehicle if there are any damaged parts. •...

  • Page 15: Warranty

    • This warranty does not cover, and is not intended to exclude any liability on the part of Rollplay, whether under this warranty or implied by law for any indirect or consequential damages for breach of warranty. Some states may not allow the exclusion or limitation, so this limitation may not apply to you.

  • Page 16: Product Registration

    Email: _____________________________________ Phone: ___________________________ Date of Purchase: ________________________ The following product information is on the cover of the owner’s manual. Product Name: _________________________ Model Number: __________________________ Serial Number: _________________________ Place of Purchase: _______________________ Questions or comments? Contact us at www.rollplay.com or 1-888-982-9309...

This manual is also suitable for:

W403

Table of Contents
