Owner's Manual and Assembly Instructions
Model #: W418, W418AC-R, W418AC-R-F
Read and understand the entire manual before assembly and operation. The vehicle must be
assembled by an adult who has read and understands the instructions.
Made in China.
Styles and colors may vary. Do not return to store. Call 1-888-982-9309 for assistance and
replacement parts.
IMPORTANT:
Save this manual with your sales receipt.
6V Porsche 918

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6V Porsche 918 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rollplay 6V Porsche 918

Summary of Contents for Rollplay 6V Porsche 918

  • Page 1 6V Porsche 918 ® Owner’s Manual and Assembly Instructions Model #: W418, W418AC-R, W418AC-R-F Read and understand the entire manual before assembly and operation. The vehicle must be assembled by an adult who has read and understands the instructions. Made in China.
  • Page 3 Introduction Thank you for purchasing this Rollplay vehicle. We hope the rider enjoys it for miles to come. Please read this instruction guide carefully before assembling and operating the vehicle. Please have your model number and serial number ready before calling. Please have proof of purchase.
  • Page 4 Call Customer Service if you need assistance or replacement parts. Please have your model number and serial number ready before calling. Please have proof of purchase. Keep your sales receipt or register your product at www.rollplay.com as we may require proof of purchase. 1-888-982-9309 Read this entire manual to ensure proper assembly and safe operation of the vehicle.

  • Page 5: Table Of Contents

    Table of Contents Safety ............6-7 Parts ............8 Charging Instructions ......9 Assemble the Front Wheels ....10 Assemble the Left Rear Wheel ....11 Assemble the Right Rear Wheel ..... 12 Assemble the Speedometer .....13 Attach the Steering Wheel ...... 14 Assemble the Windshield ......
  • Page 6 Safety WARNING: SAFETY RIDING RULES The user must follow all safety rules and guidelines, or serious injury or death may occur to the user. • Always use common sense and safe practices when using the vehicle. The user must be at least 3 years old and weigh no more than 35 kg (77 lbs). •...

  • Page 7: Safety

    Safety (Continued) WARNING: BATTERY SAFETY • Battery posts, terminals and related accessories contain lead and lead compound (asic) chemicals known to the state of California to cause cancer, reproductive harm, and are toxic and corrosive. DO NOT open the battery. •...

  • Page 8: Parts

    Parts 9. Mirrors 1. Manual 17. Inner wheel spacer 10. Speedometer 2. Battery 18. Steering wheel nut 11. Large washers (3 + 1 extra) 3. Charger 19. Steering wheel screw 12. Rear wheels (2) 4. Car body 20. MP3 cable 13.

  • Page 9: Charging Instructions

    Charging Instructions YOU MUST CHARGE THE BATTERY FOR 24 HOURS BEFORE THE FIRST USE! ONLY AN ADULT SHOULD HANDLE THE BATTERY AND CHARGER. To Charge the Battery: Seat 1. Ensure the car is stopped and the power switch is turned off. 2.

  • Page 10: Assemble The Front Wheels

    Assemble the Front Wheels Correct Snap Pin Installation Small washer Small washer Snap pin Front wheel wheel cover 1. Slide the small washer onto the front axle. 2. Slide the front wheel onto the front axle. 3. Slide the small washer onto the front axle. 4.

  • Page 11: Assemble The Left Rear Wheel

    Assemble the Left Rear Wheel Rear wheel Large washer Large washer Snap pin Inner wheel spacer Wheel cover Left Rear Wheel: 1. Slide the large washer onto the rear axle, then slide the inner wheel spacer onto the axle. 2. Slide the left rear wheel onto the left rear axle, the side with the gear teeth faces inward.

  • Page 12: Assemble The Right Rear Wheel

    Assemble the Right Rear Wheel Large washer Wheel cover Snap pin Rear wheel Right Rear Wheel: 1. Slide the right rear wheel onto right rear wheel axle. The side with gear teeth faces inward. (Note: the gear teeth must engage with the gear box.) 2.

  • Page 13: Assemble The Speedometer

    Assemble the Speedometer 1. Plug the speedometer connector (A) into the dashboard connector (B). 2. Carefully slide the wires into the hole on the dashboard. 3. Snap the speedometer into the dashboard.

  • Page 14: Attach The Steering Wheel

    Attach the Steering Wheel 1. Locate the steering wheel screw and nut from blister pack. 2. Plug the steering wheel connector (C) into the dashboard connector (D). Carefully slide the wires into the steering column. 3. Insert the steering wheel into the steering rod, and align the holes on the steering wheel with the holes on the steering rod.

  • Page 15: Assemble The Windshield

    Assemble the Windshield 1. Align the windshield with the slots between the dashboard and the body. 2. Push lightly on the windshield until it clicks into place.

  • Page 16: Attach The Mirrors

    Attach the Mirrors 1. Insert the left mirror into the slot on the left door near the windshield. 2. Insert the mirror until it snaps into place. 3. Repeat steps 1-2 for the right mirror.

  • Page 17: Assemble The Seat

    Assemble the Seat Seat Seat release button 1. Insert the two hooks on the back of the seat into the slots on the car body. Push down on the seat until it clicks into place. 2. Press the seat release button to unlock the seat.

  • Page 18: Operation Instructions

    Operating Instructions Sound Buttons Shifter Battery Life MP3 Jack Tuning lndicator Reset Volume Dial Power lndicator Button Pedal Power Switch • Push the power switch to turn on the car. The power indicator light will turn on when the car is on. Press the power switch again to turn off the car.

  • Page 19: Maintenance

    Maintenance Important Battery and Charger Information • Only an adult who has read and understands the safety warnings may handle and operate the battery and battery charger. Keep away from children. • time. • Recharge the battery immediately after each use. Charge for at least 8-12 hours, but no more than 20 hours.

  • Page 20: General Care

    General Care • Regularly inspect all vehicle parts to ensure they are in good working condition. • Regularly inspect the charger, cord, plug, and other related parts for damage. • Remove any damaged parts and immediately contact Customer Service for replacement parts. See Service and Repairs on Page 24 for more information.

  • Page 21: Troubleshooting Guide

    Troubleshooting Guide Completely read through the manual and troubleshooting guide before contacting Customer Service. Problem Potential Cause Solution Vehicle does not run Battery is low Recharge the battery Thermal fuse tripped Reset fuse Snap pins are loose Tighten snap pins Loose wires or loose Ensure the battery connectors connectors...
  • Page 22 Problem Potential Cause Solution Vehicle needs a push to Loose wires or loose Ensure the battery connectors start connectors are securely attached. If wires are loose, contact Customer Service for repairs “Dead spot” on motor A “dead spot” means electricity is not being delivered to the terminal.

  • Page 23: Fcc Information

    FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 24: Service And Repairs

    Hours: 9 AM - 5 PM (CST), Monday - Friday 888-982-9309 Phone: 1- Email: customerservice@rollplay.com Web: www.rollplay.com For a list of available replacement parts, please visit www.rollplay.com. WE WILL REQUIRE PROOF OF PURCHASE. Please save your sales receipt or register your product at www.rollplay.com.

  • Page 25: Warranty

    This warranty does not cover, and is not intended to exclude any liability on the part of Rollplay, whether under this warranty or implied by law for any indirect or consequential damages for breach of warranty. Some states may not allow the exclusion or limitation so this limitation may not apply to you.

  • Page 26: Product Registration

    Product Registration First Name: Last Name: Title: Address: City: State: Zip Code: Email: Phone: Date of Purchase: Product Name: Model Number: Serial Number: Retailer Place of Purchase: Questions or comments? Contact us at www.rollplay.com or 1-888-982-9309...
