Technical Specifications

This section details the specifications and operating conditions of the device.
5.1

Power Supply Specifications

The RUGGEDCOM RSG2100P can be equipped with the following power supplies:
Electrical hazard – risk of power supply failure or damage to the device
Make sure power input to the device is within the specified input range. If power
input is too high, damage to the power supply may occur. If power input is too low,
damage to the device may occur.
Note
For specifications on the PoE power supply, refer to
(Page
HI (125/250 VDC)
HI (110/230 VAC)
a
(F) denotes fast-acting fuse
b
(T) denotes time-delay fuse.
c
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1 W less than
fiber optic ports.
d
The HI power supply is the same power supply for both AC and DC.
5.2

PoE Power Supply Specifications

a
(T) denotes time-delay fuse.
RUGGEDCOM RSG2100P
Installation Manual, 04/2022, C79000-G8976-1041-20
NOTICE
33)".
Power
Supply Type
Minimum
24 VDC 10 VDC
48 VDC 36 VDC
d
88 VDC
d
85 VAC
Power
Supply Type
Minimum
48 VDC 37 VDC
Input Range
Maximum
36 VDC
72 VDC
300 VDC
264 VAC
Input Range
Maximum
72 VDC
"PoE Power Supply Specifications
Internal Fuse Maximum Power
ab
Rating Consumption
6.3 A(F)
3.15 A(T)
2 A(T)
2 A(T)
Internal Maximum Power
a
Fuse Rating Consumption
2 A(T)
5
c
28 W
68 W
