Certification
6.2 EMC and Environmental Type Tests
EMC Immunity Type Tests per IEEE 1613
Note
RUGGEDCOM products meet Class 1 requirements for copper Ethernet
configurations and Class 2 for fiber Ethernet configurations. Class 1 allows for
temporary communication loss, while Class 2 requires error-free and interrupted
communications.
Radiated RFI
Fast Transient
Oscillatory
HV Impulse
Oscillatory
Magnetic Field
Environmental Type Tests
60068-2-1
60068-2-2
60068-2-30
46
Description
ESD Enclosure Contact
Enclosure Air
Enclosure Ports
Signal Ports
DC Power Ports
AC Power Ports
Earth Ground Ports
Signal Ports
DC Power Ports
AC Power Ports
Signal Ports
DC Power Ports
AC Power Ports
Dielectric Signal Ports
Strength
DC Power Ports
AC Power Ports
Damped Enclosure Ports
Test
IEC Cold Temperature
IEC Dry Heat
IEC Humidity (Damp
Heat, Cyclic)
Description
Test Ad
Test Bd
Test Db
Test Levels
±2 kV
±4 kV
±8 kV
±4 kV
±8 kV
±15 kV
35 V/m
4 kV @ 2.5 kHz
4 kV
4 kV
4 kV
2.5 kV Common Mode @ 1 MHz
2.5 kV Common
1 kV differential mode @ 1 MHz
2.5 kV Common
1 kV differential mode @ 1 MHz
5 kV (Fail-Safe Relay Output)
5 kV
5 kV
2 kV
2 kV
2 kV
100 A/m
Test Levels
-40 °C (-40 °F), 16 Hours
85 °C (185 °F), 16 Hours
95% (non-condensing),
55 °C (131 °F), 6 cycles
RUGGEDCOM RSG2100P
Installation Manual, 04/2022, C79000-G8976-1041-20
Severity
Level
