USB-5203 User's Guide
Sensor Category
Disabled (Note 1)
Thermocouple
Semiconductor sensor
RTD and thermistor
Note 1: The factory default configuration is Disabled. In Disabled mode, analog inputs are disconnected from
the terminal blocks and all of the A/D inputs are internally grounded. This mode also disables each of
the current excitation sources.

Compatible sensors

Parameter
Thermocouple
RTD
Thermistor
Semiconductor / IC

Accuracy

Thermocouple measurement accuracy

Thermocouple measurement accuracy specifications include linearization, cold-junction compensation and
system noise. These specs are for one year, or 3000 operating hours, whichever comes first, and for operation of
the device between 15 °C and 35 °C. For measurements outside this range, add ±0.5° to the maximum error
shown. There are CJC sensors on each side of the module. The accuracy listed above assumes the screw
terminals are at the same temperature as the CJC sensor. Errors shown do not include inherent thermocouple
error. Please contact your thermocouple supplier for details on the actual thermocouple error.
Thermocouples must be connected to the device such that they are floating with respect to GND (pins 9, 19, 28,
38). The device GND pins are isolated from earth ground, so connecting thermocouple sensors to voltages
referenced to earth ground is permissible as long as the isolation between the GND pins and earth ground is
maintained.
When thermocouples are attached to conductive surfaces, the voltage differential between multiple
thermocouples must remain within ±1.4 V. For best results, MCC recommends using insulated or ungrounded
thermocouples when possible.
Table 2. Channel configuration specifications
Conditions
J, K, S, R, B, E, T, or N
2-wire input configuration with a single sensor per channel pair
2-wire input configuration with two sensors per channel pair
3-wire configuration with a single sensor per channel pair
4-wire input configuration with a single sensor per channel pair
4-wire input configuration with two sensors per channel pair
Table 3. Compatible sensor type specifications
Specification (°C)
J: –210 to 1200
K: –270 to 1372
R: –50 to 1768
S: –50 to 1768
T: –270 to 400
N: –270 to 1300
E: –270 to 1000
B: 0 to 1820
100 Ω PT (DIN 43760: 0.00385 ohms/ohm/°C)
100 Ω PT (SAMA: 0.003911 ohms/ohm/°C)
100 Ω PT (ITS-90/IEC751:0.0038505 ohms/ohm/°C)
Standard 2,252 Ω through 30,000 Ω
LM35, TMP35 or equivalent
23
Specifications
Max number of
sensors (all channels
configured alike)
8 differential channels
8 differential channels
4 differential channels
8 differential channels
4 differential channels
4 differential channels
8 differential channels
