- Page 1 ASSEMBLY INSTRUCTIONS : 30 IN MADRID STOOL Description : S-403 Item No. ITEM NO.: S-403 Printed in Vietnam REVISED SEPT 10, 2018 - 1 -...
- Page 2 Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: S-403 Printed in Vietnam REVISED SEPT 10, 2018 - 2 -...
- Page 3 Long Screw (M6 x 80mm) (M4 x 50mm) Short Screw Lock Washer (M4 x 35mm) (6.5 x11mm) Flat Washer Allen Key (6.5 x19mm) (M4 x 30mm x 110mm) ITEM NO.: S-403 Printed in Vietnam REVISED SEPT 10, 2018 - 3 -...
- Page 4 Attach front stretcher (F) to front legs (D) with screws (4), and then attach side stretchers (E) to front and back legs with screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: S-403 Printed in Vietnam REVISED SEPT 10, 2018...
- Page 5 STEP 3 Attach the seat (C) to top of the seat frame (B) with screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: S-403 Printed in Vietnam REVISED SEPT 10, 2018 - 5 -...
