- Page 1 ASSEMBLY INSTRUCTIONS : 24 IN AVA SWIVEL STOOL Description : S-132SW Item No. ITEM NO.: S-132SW Printed in Vietnam ISSUED MAY 16, 2017 - 1 -...
- Page 2 Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: S-132SW Printed in Vietnam ISSUED MAY 16, 2017 - 2 -...
- Page 3 (M6 x 30mm) (M6 x 40mm) Long bolt Wood Screw (M6 x 80mm) (M4 x 35mm) Lock Washer Flat Washer ()6.5 x 11mm) ()6.5 x 19mm) Allen Key (M4x30mmx110mm) ITEM NO.: S-132SW Printed in Vietnam ISSUED MAY 16, 2017 - 3 -...
- Page 4 Attach the leg (C) to the leg (D) with bolts (2), and washers (5) and (6) as shown below. Tighten with Allen key (7). Place stretchers (E) between legs (C) and (D), and attach with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: S-132SW Printed in Vietnam ISSUED MAY 16, 2017 - 4 -...
- Page 5 (5) and (6) as shown below. Tighten with Allen key (7). STEP 4 Attach the seat (F) to top of the seat frame (B) with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: S-132SW Printed in Vietnam ISSUED MAY 16, 2017...
